Williams Reach In Blast Chiller Stainless Steel 23kg J1BC G684

£5,948.37

+vat

Availability: 999 in stock

Brand:

SKU: G684

Product summary

Stainless Steel Finish. 1/1 Gastronorm compatible

Product description

Jade Blast Chiller from Williams Refrigeration. Featuring a choice of temperature controlled cycles (hard, soft or core food temperature). Automatically switches to storage mode at 3C at the end of the cycle.

Blast chills 23kg from +90°C to +3°C in 90 minutes
Self closing doors fitted with easy to clean and replace magnetic balloon gaskets
Easy to use, 1-2-3 state of the art control panel – 3 simple steps to initiate a blast cycle
Clear LED displays for time and food probe temperatures – keeps you in control of any product load
Precision injected, high density polyurethane insulation – provides excellent thermal efficiency with low GWP (Global Warming Potential) and zero ODP (Ozone Depletion Potential)
Designed and engineered to operate efficiently up to a 43°C ambient
Heavy duty, non marking swivel and brake castors
Choice of soft and hard blast chill cycle
Food-safe stainless steel exterior and interior
7x 1/1 GN capacity (pans not included)
Supplied with seven shelves

The Williams Jade J1BC G684 is a stainless steel reach-in blast chiller for 23kg batches, with seven 1/1 GN shelf positions, hard, soft and core-temperature cycles, and automatic chilled storage at the end of the cycle.

Downloads

SPECIFICATION 25 facts · tap for all Width865 mmDepth801 mmHeight1960 mmGross weight175 kgTemperature range+3 to +90 °CCapacity23kg

Identity6

Brand Williamssite
Product code G684site
Range / series Jadecatalogue
Seo name Williams Reach In Blast Chillercatalogue
Type Blast Chillerscatalogue
Warranty 2 Years Parts & Labourcatalogue

Size & weight6

Depth 801 mmcatalogue
External (W×D×H) 1960 × 865 × 801 mmcatalogue
Gross weight 175 kgcatalogue
Height 1960 mmcatalogue
Internal (W×D×H) 1370 × 715 × 560 mmcatalogue
Width 865 mmsite

Capacity5

Capacity 23kgcatalogue
Door type Hingedcatalogue
Doors 1catalogue
Gastronorm size 1/1 GN fullcatalogue
Shelves 7catalogue

Performance2

Refrigerant R452acatalogue
Temperature range +3 to +90 °Ccatalogue

Power & energy1

Fuel type Plugcatalogue

Build & fittings3

Colour Silvercatalogue
Insulation 75 mmcatalogue
Material Stainless Steelcatalogue

Other stated facts2

Mobility Castorscatalogue
Plug notice Yescatalogue
THE WORKING VIEW

Why this blast chiller earns its place

The Williams Jade J1BC G684 is a reach-in blast chiller for kitchens that need a dedicated cook-chill cabinet rather than general chilled storage. Its listed batch capacity is 23kg, giving production kitchens a controlled cabinet for moving cooked food into chilled holding as part of a planned prep routine.

The cabinet is built in stainless steel with a single hinged door, seven shelves and 1/1 GN compatibility. Externally it is listed at 865mm wide, 801mm deep and 1960mm high, with a gross weight of 175kg, so it needs proper delivery access and a permanent back-of-house position rather than a temporary prep-table space.

Williams lists temperature-controlled hard, soft and core food temperature cycles, with the chiller automatically switching to storage mode at 3°C at the end of the cycle. The specification also lists 75mm insulation and R452a refrigerant, placing this firmly in commercial production territory.

BEFORE YOU BUY

Questions, answered straight

The Williams J1BC G684 is listed with a 23kg capacity. That makes it a reach-in blast chiller for batch work rather than casual under-counter storage.

Seven shelves are listed for this model, with 1/1 GN compatibility. That gives the cabinet a clear internal layout for organised tray loading.

The manufacturer description lists hard, soft and core food temperature cycles. It also says the cabinet automatically switches to storage mode at 3°C at the end of the cycle.

It is listed at 865mm wide, 801mm deep and 1960mm high, with a 175kg gross weight. Check route, floor space and service clearance before installation.

Yes. The G684 is listed with a hinged door, which is the standard reach-in access format for this type of cabinet.

The listed exterior finish is stainless steel, with 75mm insulation in the specification. That suits commercial kitchens where the cabinet has to stand up to regular cleaning and heavy daily use.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

Williams Reach In Blast Chiller Stainless Steel 23kg J1BC G684 Product Data

Brand Williams
Type Blast Chillers
Range Jade
Dimensions 1960(H) x 865(W) x 801(D)mm
Capacity 23kg
Material Stainless Steel
Colour / Finish Silver
Temperature Range 90°C to 3°C
Refrigerant R452a
Number of Doors 1
Number of Shelves 7
Fuel / Supply Plug
Warranty 2 Years Parts & Labour
Weight 175kg
Manufacturer Ref J1BC
If you have any questions about the Williams Reach In Blast Chiller Stainless Steel 23kg J1BC G684 then please get in touch.
