G-Line by TEFCOLD GVC33-150 S/S Gastronorm Topping Shelf With Lid

£386.00

+vat

- +

SKU: 30826

Product summary

  • Stainless steel
  • Stainless steel lid
  • Accepts GN1/4 pan(s) (not supplied)
  • Digital controller and temperature display
  • Static cooling
  • Adjustable feet
  • Height with lid open 533mm

Product description

Refrigerated Topping Shelf for Gastronorm Pans

Boost your catering business with the GVC Topping Shelfs. Perfectly crafted for food service, these boast advanced features to streamline your operations. Easily organise and display toppings at ideal temperatures for quick prep. Fully automatic, it offers a static cooling system, maintaining 2°C to 8°C to keep ingredients fresh. The manual defrost feature prevents ice build-up. Adjust temperatures with the digital controller.

The G-Line by TEFCOLD GVC33-150 is a stainless steel refrigerated gastronorm topping shelf with lid, holding chilled toppings between +2 and +8 °C via an electronic controller with manual defrost and R600a refrigerant, its internal well measuring 1150 × 245 × 150 mm, costing about £241 a year at 25p/kWh.

SPECIFICATION 38 facts · tap for all External W × D × H1500 x 335 x 288.5 mmWidth1500 mmDepth335 mmGross / net weight33 / 29 kgGross weight33 kgVoltage / frequency220-240/50 V/Hz

Identity6

Brand G-Line by TEFCOLDsite
GTIN / EAN 5708181365370site
Product code 30826site
Sub title Gastronorm Topping Shelf With Lidcatalogue
Type Stainless Lid Topping Unitscatalogue
Warranty 2 year parts & 1 year labour warranty. Exclusions apply (see terms and conditions) – addcatalogue

Size & weight11

Depth 335 mmsite
External (W×D×H) 1500 × 335 × 288 mmcatalogue
External W × D × H 1500 x 335 x 288.5 mmsite
Gross / net weight 33 / 29 kgsite
Gross weight 33 kgcatalogue
Height 288.5 mmsite
Internal (W×D×H) 1150 × 245 × 150 mmcatalogue
Internal W × D × H 1150 x 245 x 150 mmsite
Packed (W×D×H) 1600 × 375 × 330 mmcatalogue
Packed W × D × H 1600 x 375 x 330 mmsite
Width 1500 mmsite

Capacity3

Capacity item specification 7 x GN1/4 pcscatalogue
GN pan capacity 7 x GN1/4site
Gross volume 42.2 litrescatalogue

Performance9

Controller Electronicsite
Cooling type Staticsite
Defrost type Manualsite
Max ambient 30 °Ccatalogue
Maximum ambient +30°C, 55% RHsite
Refrigerant R600asite
Refrigerant charge 45 gsite
Temperature range +2 to +8site
Thermometer Yessite

Power & energy5

Annual energy consumption 964 kWh/yearsite
Energy consumption 2.64 kWh/24hsite
Input power 110 Wsite
Noise level 40 dB(A)site
Voltage / frequency 220-240/50 V/Hzsite

Build & fittings2

Exterior finish SS201site
Feet / legs Adjustable Feetsite
THE WORKING VIEW

Why this stainless lid topping unit earns its place

The G-Line by TEFCOLD GVC33-150 is a refrigerated gastronorm topping shelf that sits along the back of a prep counter to keep garnishes and toppings chilled and to hand through service. It is built in SS201 stainless steel inside and out, wipe-clean and hard-wearing under constant handling, with a lid to cover stock down when the line is closed.

It holds toppings between +2 and +8 °C, managed by an electronic controller, and runs at 40 dB on R600a refrigerant. Defrost is manual, so build it into the cleaning routine. At 963.6 kWh a year the unit works out at about £241 a year at 25p/kWh, so factor it in as an always-on part of the make line.

The refrigerated well measures 1150 × 245 × 150 mm internally, sized to run a row of chilled toppings within reach of the person building each order. It runs from a standard 13 A supply, and the full stainless construction stands up to a wash-down cleaning regime.

BEFORE YOU BUY

Questions, answered straight

Between +2 and +8 °C, managed by an electronic controller. That keeps prepped chilled toppings within a safe holding band during service.

Yes, it is built in SS201 stainless steel inside and out, so it wipes clean and stands up to a regular wash-down routine.

Rated at 963.6 kWh a year, it works out at about £241 a year at 25p/kWh. As an always-on unit, actual cost depends on your tariff and kitchen ambient.

No, defrost is manual, so plan it into your cleaning schedule.

It gives a refrigerated well of 1150 × 245 × 150 mm and runs from a standard 13 A supply on R600a refrigerant at 40 dB.

Yes, our engineers cover commercial refrigeration servicing and repairs. Call 01792 732702 to arrange a visit.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

Dimensions

Internal Dimension (WxDxH): 1150 x 245 x 150 mm
External Dimension (WxDxH): 1500 x 335 x 288.5 mm
Packed Dimension (WxDxH): 1600 x 375 x 330 mm

Cooling and Functions

Type of Controller: Electronic
Type of Cooling: Static
Type of Defrost: Manual
Refrigerant: R600a
Refrigerant Charge: 45 g
Thermometer: Yes

Power and Consumption

Energy Consumption: 2.64 kWh/24h
Temperature Range: +2 to +8 °C
Annual Energy Consumption: 964 kWh/year m³
Input Power: 110 W
Voltage / Frequency: 220-240/50 V/Hz
Noise Level: 40 dB(A)

Measures and Content

Capacity GN Pans: 7 x GN1/4 pcs
Temperature Range: +2 to +8 °C
Gross / Net Weight: 33 / 29 kg
Gross / Net Volume: 42.2 / 36.4 l
Max Ambient: +30°C, 55% RH

Design and Material

Feet / Legs: Adjustable Feet
Exterior Finish: SS201
Interior Finish: SS201
If you have any questions about the G-Line by TEFCOLD GVC33-150 S/S Gastronorm Topping Shelf With Lid then please get in touch.
