TEFCOLD SOCA90INTB Serve Over Counter

£7,085.00

+vat

Brand:

SKU: 68482

Energy Arrow

Product summary

  • Excellent product visibility
  • Black finish
  • Glass front lifts up for easy cleaning
  • Temperature Class 3M1
  • Ventilated cooling
  • Anti mist front glass
  • LED top light
  • Stainless steel bumper bars
  • Stainless steel rear shelf
  • Can be multiplexed with kit (POA)

Product description

90° corner module for serve over counter

The SOC corner modules offer the opportunity of creating complete counter solutions in combination with other serve over counters from the same range. Choose between 45° or 90° counter displays for your perfect counter installation. Only suitable for use alongside SOCA counters. Avoid opening both front glasses simultaneously.

The TEFCOLD SOCA90INTB is a flat-glass serve-over counter holding a 0 to +4 °C display band across 1.07 m² of serving area, with ventilated cooling, automatic electric defrost, an electronic controller and natural R290 refrigerant.

SPECIFICATION 36 facts · tap for all External W × D × Hx 1120 x 1190 mmDepth1120 mmGross / net weight235 / 190 kgGross weight235 kgVoltage / frequency220-240/50 V/HzInput power315 W

Identity6

Brand TEFCOLDsite
GTIN / EAN 5708181754150site
Product code 68482site
Sub title Serve Over Countercatalogue
Type Fresh Meat Display Fridgescatalogue
Warranty 2 year parts & 1 year labour warranty. Exclusions apply (see terms and conditions) – addcatalogue

Size & weight8

Depth 1120 mmsite
External W × D × H x 1120 x 1190 mmsite
Gross / net weight 235 / 190 kgsite
Gross weight 235 kgcatalogue
Height 1190 mmsite
Internal W × D × H x 900 x 545 mmsite
Packed (W×D×H) 1500 × 1450 × 1400 mmcatalogue
Packed W × D × H 1500 x 1450 x 1400 mmsite

Capacity1

Display area 1.07 m²site

Performance10

Climate class 3site
Controller Electronicsite
Cooling type Ventilatedsite
Defrost type Automatic, electricsite
Max ambient 25 °Ccatalogue
Maximum ambient +25°C, 60% RHsite
Refrigerant R290site
Refrigerant charge 150 gsite
Temperature range 0 to +4site
Thermometer Yessite

Power & energy5

Annual energy consumption 1679 kWh/yearsite
Energy consumption 4.6 kWh/24hsite
Input power 315 Wsite
Noise level 60 dB(A)site
Voltage / frequency 220-240/50 V/Hzsite

Build & fittings3

Exterior finish Black RAL9005site
Feet / legs Adjustable Feetsite
Interior light LEDsite
THE WORKING VIEW

Why this fresh meat display fridge earns its place

The SOCA90INTB is a flat-glass serve-over counter built to merchandise fresh product at a staffed counter. It gives 1.07 m² of chilled display area behind a low flat glass front, holding portioned stock at eye level for over-the-counter service in a deli, butcher's or food-hall setting.

In use it holds a 0 to +4 °C display band, with ventilated cooling to keep temperature even across the deck and automatic electric defrost clearing ice without manual intervention. An electronic controller runs the cycle, and the cabinet is rated to climate class 3, so it holds temperature in warmer, busier rooms. Running noise is 60 dB, and at 1679 kWh a year the counter costs about £420 a year to run at 25p/kWh.

For delivery and siting, the counter weighs 190 kg net and 235 kg gross, so plan a firm floor and a clear route in. It draws 315 W from a 220-240 V / 50 Hz supply and cools on natural, low-GWP R290 refrigerant with a 150 g charge.

BEFORE YOU BUY

Questions, answered straight

It holds a 0 to +4 °C display band. Ventilated cooling keeps the temperature even across the 1.07 m² deck, suited to chilled fresh product on staffed display.

The cabinet uses 1679 kWh a year, which works out at about £420 a year at 25p/kWh. Your actual cost depends on your tariff and how hard the room works it.

Defrost is automatic and electric, so ice is cleared on a cycle without manual intervention. An electronic controller manages the process.

It runs on R290, a natural low-GWP hydrocarbon refrigerant, with a 150 g charge.

Running noise is rated at 60 dB.

Yes. Craven Cooling services the equipment it supplies; call the team on 01792 732702 to arrange servicing or discuss a maintenance plan.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

Dimensions

Internal Dimension (WxDxH): x 900 x 545 mm
External Dimension (WxDxH): x 1120 x 1190 mm
Packed Dimension (WxDxH): 1500 x 1450 x 1400 mm

Cooling and Functions

Type of Controller: Electronic
Type of Cooling: Ventilated
Type of Defrost: Automatic, electric
Refrigerant: R290
Refrigerant Charge: 150 g
Thermometer: Yes

Power and Consumption

Energy Consumption: 4.6 kWh/24h
Temperature Range: 0 to +4 °C
Annual Energy Consumption: 1679 kWh/year m³
Input Power: 315 W
Voltage / Frequency: 220-240/50 V/Hz
Noise Level: 60 dB(A)

Measures and Content

Temperature Range: 0 to +4 °C
Climate Class: 3
Gross / Net Weight: 235 / 190 kg
Gross / Net Volume: / 345 l
Max Ambient: +25°C, 60% RH
Total Display Area: 1.07 m² m²

Design and Material

Feet / Legs: Adjustable Feet
Exterior Finish: Black RAL9005
Interior Finish: Black RAL9005
Interior Light: LED
If you have any questions about the TEFCOLD SOCA90INTB Serve Over Counter then please get in touch.
