TEFCOLD Trojan T14 FGD A Remote Multideck

+vat

This product is currently out of stock and unavailable.

Brand:

SKU: 68185

Energy Arrow

Product summary

  • Colour is anthracite RAL7016
  • Requires remote refrigeration system (not supplied)
  • Frameless glass doors for great product visibility
  • Adjustable shelves, max weight 160kg/sq metre
  • Shelves can be flat or angled to 7° or 14°
  • Solid 40 mm endwalls with mirrored interior
  • Horizontal LED lighting
  • Digital controller and temperature display
  • EPOS Ticket strips & shelf risers
  • Extraction rate 650w/per metre
  • Can be multiplexed with kit (POA)
  • Also available in an extended height version

Product description

Remote Multideck

A great remote multideck option ideal for maximising your display space and product visibility whilst reducing the impact of heat and noise. Available in 4 sizes. This unit is multiplexable with a kit to allow you to create a larger display size. It requires an additional remote refrigeration system. Trojans offer a large display area with high-capacity vertical merchandising. Ideal for an extensive range of chilled products with even temperature distribution across all shelving levels. What’s more, the LED illumination enhances product presentation, whilst the energy-efficient operation and modular construction allows for seamless continuous line-ups. 2 year parts warranty only.

The TEFCOLD Trojan T14 FGD A is a remote full-glass-door multideck offering 1.83 m² of chilled display, rated energy class C with an EEI of 23.3% and using 2,514.8 kWh a year — about £629 a year at 25p/kWh — running off a remote condensing unit rather than a built-in compressor.

SPECIFICATION 38 facts · tap for all External W × D × H1334 x 784 x 2076 mmWidth1334 mmDepth784 mmGross / net weight278 / 260 kgGross weight278 kgVoltage / frequency220-240/50 V/Hz

Identity6

Brand TEFCOLDsite
GTIN / EAN 5708181753344site
Product code 68185site
Sub title Remote Multideckcatalogue
Type Tefcold Trojancatalogue
Warranty 2 year parts & 1 year labour warranty. Exclusions apply (see terms and conditions) – addcatalogue

Size & weight11

Depth 784 mmsite
External (W×D×H) 1334 × 784 × 2076 mmcatalogue
External W × D × H 1334 x 784 x 2076 mmsite
Gross / net weight 278 / 260 kgsite
Gross weight 278 kgcatalogue
Height 2076 mmsite
Internal (W×D×H) 1250 × 450 × 1578 mmcatalogue
Internal W × D × H 1250 x 450 x 1578 mmsite
Packed (W×D×H) 1450 × 850 × 2390 mmcatalogue
Packed W × D × H 1450 x 850 x 2390 mmsite
Width 1334 mmsite

Capacity3

Display area 1.83 m²site
Doors 2catalogue
Shelves 5catalogue

Performance7

Climate class 3site
Defrost type Automaticsite
Max ambient 25 °Ccatalogue
Maximum ambient +25°C, 60% RHsite
Refrigerant R449asite
Refrigerant charge REMOTE gsite
Temperature range -1 to +5site

Power & energy4

Annual energy consumption 2515 kWh/yearsite
Energy consumption 6.89 kWh/24hsite
Energy efficiency index 23.3 %site
Voltage / frequency 220-240/50 V/Hzsite

Build & fittings3

Exterior finish Anthracite RAL7016site
Reversible doors Nosite
Shelf dimensions 5 x 450 mmsite

Other stated facts1

Energy class Ccatalogue
THE WORKING VIEW

Why this tefcold trojan earns its place

The Trojan T14 FGD A is a full-glass-door remote multideck built to merchandise chilled stock behind doors. It presents 1.83 m² of glass-fronted display, keeping product in clear view while the doors hold the cold in rather than spilling it into the aisle the way an open-front cabinet does. It suits a compact chilled run — grab-and-go, drinks or pre-packed lines — where the display needs to look sharp and stay tidy.

Because it is a remote cabinet, the refrigeration is done by a separate condensing unit sited away from the shop floor, so there is no compressor heat or noise at the display itself. On energy it is rated class C with an efficiency index of 23.3%, and it draws 2,514.8 kWh a year — about £629 a year at 25p per kWh, though your actual figure moves with your tariff and door traffic.

Being remote, the cabinet is not plug-and-play: it connects to a remote condensing unit through pipework that a refrigeration engineer should size and install. That makes it a fit for sites already running a central refrigeration pack, or planning one, rather than a standalone socket install. Our team can specify the cabinet against your existing plant and handle installation and commissioning.

BEFORE YOU BUY

Questions, answered straight

It is a remote multideck, so it does not have a built-in compressor. It connects to a separate remote condensing unit through pipework, which a refrigeration engineer should size, install and commission.

It is rated energy class C with an EEI of 23.3% and uses 2,514.8 kWh a year, which is about £629 a year at 25p per kWh. The real figure depends on your electricity tariff and how often the doors are opened.

The cabinet presents 1.83 m² of glass-door display area for chilled stock. Full glass doors keep that display looking full while holding temperature between customers.

Glass doors hold the cold inside the cabinet rather than letting it spill into the aisle, which keeps the display tidy and the product clearly on show. This T14 is a full-glass-door (FGD) format.

Yes. We supply Tefcold remote cabinets across the UK and can specify this one against your condensing plant. Call our service team on 01792 732702 to arrange installation, commissioning or servicing.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

Dimensions

Internal Dimension (WxDxH): 1250 x 450 x 1578 mm
External Dimension (WxDxH): 1334 x 784 x 2076 mm
Packed Dimension (WxDxH): 1450 x 850 x 2390 mm

Cooling and Functions

Type of Defrost: Automatic
Refrigerant: R449a
Refrigerant Charge: REMOTE g

Power and Consumption

Energy Consumption: 6.89 kWh/24h
Temperature Range: -1 to +5 °C
Annual Energy Consumption: 2515 kWh/year m³
EEI: 23.3 %
Voltage / Frequency: 220-240/50 V/Hz

Measures and Content

Temperature Range: -1 to +5 °C
Climate Class: 3
Gross / Net Weight: 278 / 260 kg
Gross / Net Volume: / l
Max Ambient: +25°C, 60% RH
Total Display Area: 1.83 m² m²

Design and Material

Door Reversible: No
Shelf Color: Anthracite
Shelf Dimensions: 5 x 450 mm
Exterior Finish: Anthracite RAL7016
Interior Finish: Anthracite RAL7016
If you have any questions about the TEFCOLD Trojan T14 FGD A Remote Multideck then please get in touch.
