TEFCOLD IC402SCE-SO Scoop Ice Cream Freezer

£726.00

+vat

Brand:

SKU: 71508

Energy Arrow

Product summary

  • Curved glass canopy
  • LED interior light
  • Angled sliding lids with lock
  • Castors with brake
  • Storage under baskets
  • Great branding possibilities
  • Accepts plastic napoli size tubs. Stainless napoli pans not required
  • Climate class 5 for high performance in warm surroundings

Product description

Scoop ice cream freezer with canopy

The IC-SCE-SO canopy range is an ideal way to add scooping ice cream sales to your business even if you are on a budget. This is one of our most popular ranges. A curved glass canopy with an attractive sloping display for scooping tubs means your customers get a good view of the ice cream in the unit (baskets which fit 5 litre tubs, with the option for 4 ltr baskets/tubs if required). Flat glass sliding lids (with lock) allow access to the ice cream for serving and help insulate the unit when not in use.

The TEFCOLD IC402SCE-SO is a static-cooled scoop ice cream display freezer holding 352 litres at -24 to -14 °C, finished in white with a mechanical controller and R290 refrigerant, drawing 320 W from a standard 13-amp supply.

SPECIFICATION 44 facts · tap for all External W × D × H1300 x 615 x 1295 mmWidth1300 mmDepth615 mmGross / net weight132 / 122 kgGross weight132 kgVoltage / frequency220-240/50 V/Hz

Identity6

Brand TEFCOLDsite
GTIN / EAN 5708181760854site
Product code 71508site
Sub title Scoop Ice Cream Freezercatalogue
Type Static Cooled Ice Cream Display Freezerscatalogue
Warranty 2 year parts & 1 year labour warranty. Exclusions apply (see terms and conditions) – addcatalogue

Size & weight11

Depth 615 mmsite
External (W×D×H) 1300 × 615 × 1295 mmcatalogue
External W × D × H 1300 x 615 x 1295 mmsite
Gross / net weight 132 / 122 kgsite
Gross weight 132 kgcatalogue
Height 1295 mmsite
Internal (W×D×H) 1180 × 495 × 710 mmcatalogue
Internal W × D × H 1180 x 495 x 710 mmsite
Packed (W×D×H) 1400 × 750 × 1210 mmcatalogue
Packed W × D × H 1400 x 750 x 1210 mmsite
Width 1300 mmsite

Capacity3

Gross volume 352 litrescatalogue
Serving capacity 9 Plastic Tubs (5L) / 7 Napoli Pans (5L) / 12 Plastic Tubs (4L)site
Under-counter storage 19 Plastic Tubs (5L) / 15 Napoli Pans (5L) / 19 Plastic Tubs (4L)site

Performance10

Climate class 5site
Controller Mechanicalsite
Cooling type Staticsite
Defrost type Manualsite
Max ambient 40 °Ccatalogue
Maximum ambient +40°C, 40% RHsite
Refrigerant R290site
Refrigerant charge 105 gsite
Temperature range -24 to -14site
Thermometer Yessite

Power & energy6

Annual energy consumption 1039.885 kWh/yearsite
Energy consumption 2.849 kWh/24hsite
Energy efficiency index 43 %site
Input power 320 Wsite
Noise level 45 dB(A)site
Voltage / frequency 220-240/50 V/Hzsite

Build & fittings3

Castors 4 wheels, 2 with brakesite
Exterior finish Whitesite
Interior light LEDsite

Other stated facts1

Energy class Dcatalogue
THE WORKING VIEW

Why this static cooled ice cream display freezer earns its place

The IC402SCE-SO is a scoop ice cream freezer built for front-of-shop serving, where tubs are kept firm and on show for staff to scoop to order. The white cabinet holds 352 litres of gross volume across the well, giving room for a working range of flavours behind the glass. It is a display-and-serve format rather than back-of-house storage.

Cooling is static and the cabinet runs at -24 to -14 °C, the band that keeps scooping ice cream at a workable consistency. Defrost is manual and the controls are mechanical, so temperature is set and held without a digital menu. Running noise is 45 dB, and the freezer carries climate class 5, built to keep temperature reliably in warm shop-floor conditions. At 827.8 kWh a year that works out at about £207 a year at 25p/kWh.

The cabinet is finished in white outside with white painted steel inside, and uses R290 refrigerant with a 105 g charge. It draws 320 W and runs from a standard 13-amp supply, so no special electrical work is needed. At 132 kg gross it is a two-person lift into position; plan the delivery route and final siting before it arrives.

BEFORE YOU BUY

Questions, answered straight

The IC402SCE-SO holds -24 to -14 °C, the band that keeps scooping ice cream at a firm but workable consistency. Cooling is static and the controls are mechanical.

It is rated at 827.8 kWh a year, which is about £207 a year at 25p/kWh. Energy class is D.

No. It draws 320 W and runs from a standard 13-amp supply, so it plugs into an ordinary socket. R290 is the refrigerant, with a 105 g charge.

Running noise is 45 dB, which is quiet enough for a customer-facing serving area.

No, defrost is manual. You clear the ice periodically by hand, which is normal for a static-cooled scoop freezer of this type.

Yes, our team handles servicing and breakdowns on Tefcold cabinets. Call 01792 732702 to arrange a visit.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

Dimensions

Internal Dimension (WxDxH): 1180 x 495 x 710 mm
External Dimension (WxDxH): 1300 x 615 x 1295 mm
Packed Dimension (WxDxH): 1400 x 750 x 1210 mm

Cooling and Functions

Type of Controller: Mechanical
Type of Cooling: Static
Type of Defrost: Manual
Refrigerant: R290
Refrigerant Charge: 105 g
Thermometer: Yes

Power and Consumption

Energy Consumption: 2.849 kWh/24h
Temperature Range: -24 to -14 °C
Annual Energy Consumption: 1039.885 kWh/year m³
EEI: 43 %
Input Power: 320 W
Voltage / Frequency: 220-240/50 V/Hz
Noise Level: 45 dB(A)

Measures and Content

Temperature Range: -24 to -14 °C
Climate Class: 5
Gross / Net Weight: 132 / 122 kg
Gross / Net Volume: 352 / 310 l
Max Ambient: +40°C, 40% RH

Design and Material

Serving Capacity: 9 Plastic Tubs (5L) / 7 Napoli Pans (5L) / 12 Plastic Tubs (4L)
Storage capacity (under): 19 Plastic Tubs (5L) / 15 Napoli Pans (5L) / 19 Plastic Tubs (4L)
Castors: 4 wheels, 2 with brake
Exterior Finish: White
Interior Finish: White
Interior Light: LED
Lock: Yes
If you have any questions about the TEFCOLD IC402SCE-SO Scoop Ice Cream Freezer then please get in touch.
