CombiSteel Ibiza 8x5L Ice Cream Display Freezer 7472.0140

£1,528.36

+vat

- +

SKU: 7472.014

Product summary

Size W/D/H (mm) 1194 x 842 x 1285

Product description

Downloads

SPECIFICATION 25 facts · tap for all Width1194 mmDepth842 mmHeight1285 mmGross / net weight130 kgVoltage / frequency23050Voltage230V / 50Hz

Identity3

Brand CombiSteelcatalogue
GTIN / EAN 7435137862833catalogue
Type Static Cooled Ice Cream Display Freezerscatalogue

Size & weight7

Depth 842 mmsite
External (W×D×H) 1194 × 842 × 1285 mmcatalogue
Gross / net weight 130 kgsite
Height 1285 mmsite
Internal (W×D×H) 1060 × 560 × 688 mmcatalogue
Internal W × D × H 1060x560x688site
Width 1194 mmsite

Capacity2

Capacity 358 Ltrcatalogue
Gross volume 358 litrescatalogue

Performance5

Cooling type R 290site
Defrost type Automaticsite
Max ambient 3030 °Ccatalogue
Maximum ambient 3030site
Temperature range -24/-14site

Power & energy6

Energy consumption 0,15site
Frequency 50 Hzcatalogue
Rated input 150 Wcatalogue
Rated power 15 kWcatalogue
Voltage 230V / 50Hzcatalogue
Voltage / frequency 23050site

Build & fittings2

Insulation 60 mmcatalogue
Interior light Yessite
THE WORKING VIEW

Why this static cooled ice cream display freezer earns its place

The Ibiza 7472.0140 is a scooping ice cream display freezer that sells flavours by sight. It is sized around eight 5-litre pans (358 litres total), so it fits a focused flavour range into a compact serving footprint behind a glass display top while staff scoop to order. That makes it a serving counter, not a storage freezer — a practical way to add a served ice cream point to a café, kiosk or shop without the space a larger display demands.

It is a static-cooled display running at -24 to -14 °C with automatic defrost, so the day-to-day priority is presentation rather than hands-on temperature management. Give it time to pull down to temperature before you load pans, keep the glass top clean and the flavours tidy, and rotate stock so nothing sits too long. The interior light helps customers see the flavours on offer. Run it as a serving cabinet that brings a working range out onto the counter at a scoopable temperature.

It is a floor-standing unit weighing 130 kg, so plan the position before it arrives. It measures 1194 mm wide, 842 mm deep and 1285 mm tall externally, and runs on 230V at 15 kW using R 290 refrigerant. Check these dimensions and the weight against your doorways, the route in and the floor it will stand on. Set it on a level, solid base with clearance around it so warm air is not recirculated. Keep it out of direct sun and clear of ovens, radiators and other heat sources so it is not made to work harder than it needs to.

BEFORE YOU BUY

Questions, answered straight

It is a scooping display freezer — the glass top shows the flavours so customers choose by sight and staff scoop to order. It is sized around eight 5-litre pans (358 litres total). Externally it is 1194 mm wide, 842 mm deep and 1285 mm tall, and weighs 130 kg.

It is a floor-standing display 1194 mm wide, 842 mm deep and 1285 mm tall, weighing 130 kg. Check these dimensions and weight against your counter space, doorways and the route in, and leave clearance around the sides so warm air is not drawn back through it.

It runs at -24 to -14 °C, holding ice cream at a serving temperature rather than for deep storage. The automatic defrost cycles on schedule, so you do not need to manage temperature or defrost manually.

Many operators do. When you bring it back into use, give it time to pull down to temperature before loading pans, keep it out of direct sun and away from heat, and clean the glass and seals before the season starts so it runs efficiently.

It runs on 230V and draws 15 kW during operation. Use the energy label decoder and finance calculator on this page to estimate your annual costs based on your local tariff and operating pattern. Keeping it out of sun and heat and clearing the airflow around it always helps running cost.

Yes — Craven Cooling can advise on siting and delivery, and our team handles servicing and breakdown support. Call 01792 732702 to talk through delivery access, positioning and an ongoing service arrangement.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

CombiSteel Ibiza 8x5L Ice Cream Display Freezer 7472.0140 Product Data

Brand CombiSteel
Dimensions (W×D×H) 1194 × 842 × 1285 mm
Interior Dimensions 1060x560x688
Capacity 358 Ltr
Temperature Range -24/-14
Max. Ambient Temp. 30
Refrigerant R 290
Cooling Static
Defrost Automatic
Electrical Power 0.15 kW
Voltage 230V / 50Hz
Mobile Yes
Insulation 60 mm
Weight 130 kg
If you have any questions about the CombiSteel Ibiza 8x5L Ice Cream Display Freezer 7472.0140 then please get in touch.
