CombiSteel Curacao 10x5L Ice Cream Display Freezer 7472.0105

£1,443.00

+vat

SKU: 7472.0105

Product summary

Size W/D/H (mm) x x

Product description

The Combisteel Ice Cream Display Curacao 7472.0105 is a white static-cooled scooping display freezer for ten 5-litre pans, with 454 litres gross volume, interior lighting and a -22 to -15 °C operating range.

Downloads

SPECIFICATION 26 facts · tap for all Width1447 mmDepth825 mmHeight1257 mmGross / net weight116 kgVoltage / frequency23050Voltage230V / 50Hz

Identity3

Brand CombiSteelcatalogue
GTIN / EAN 7435137797760catalogue
Type Static Cooled Ice Cream Display Freezerscatalogue

Size & weight7

Depth 825 mmsite
External (W×D×H) 1447 × 825 × 1257 mmcatalogue
Gross / net weight 116 kgsite
Height 1257 mmsite
Internal (W×D×H) 1315 × 560 × 687 mmcatalogue
Internal W × D × H 1315x560x687site
Width 1447 mmsite

Capacity2

Capacity 454 Ltrcatalogue
Gross volume 454 litrescatalogue

Performance5

Cooling type R 290site
Defrost type Manualsite
Max ambient 3030 °Ccatalogue
Maximum ambient 3030site
Temperature range -22/-15site

Power & energy6

Energy consumption 0,5site
Frequency 50 Hzcatalogue
Rated input 500 Wcatalogue
Rated power 5 kWcatalogue
Voltage 230V / 50Hzcatalogue
Voltage / frequency 23050site

Build & fittings3

Colour Whitecatalogue
Insulation 60 mmcatalogue
Interior light Yessite
THE WORKING VIEW

Why this static cooled ice cream display freezer earns its place

The Ice Cream Display Curacao is a ten-pan static display freezer for served ice cream counters that need a serious flavour range in a controlled footprint. It is finished in white, holds 454 litres gross, and gives you an internal space of 1315 × 560 × 687 mm for presenting loose ice cream where customers can choose by sight.

The Curacao runs from -22 to -15 °C with static cooling and interior lighting. In practice that means a display built for scooping service, not a hidden reserve freezer: the product stays on show, staff work from the cabinet, and the customer sees the decision before they ask. Static cooling keeps the system simple and avoids fan-blown air across the tub surfaces.

For installation, check both the serving space and the route in. The cabinet is 1447 mm wide, 825 mm deep and 1257 mm high, with a 116 kg gross weight, 60 mm insulation, R290 refrigerant and a 230V, 50Hz connection. It uses manual defrost and is specified for up to 30 °C ambient, so give it airflow, keep it out of direct sun and build cleaning and defrosting into the routine.

BEFORE YOU BUY

Questions, answered straight

It is a static-cooled ice cream display freezer for scooping service, sized for ten 5-litre pans. The 454 litre gross volume and 1315 × 560 × 687 mm internal space are for presenting loose ice cream at the counter.

The external dimensions are 1447 mm wide, 825 mm deep and 1257 mm high, and the gross weight is 116 kg. Measure the full delivery route as well as the final serving position.

The supplier states -22 to -15 °C. Let the cabinet pull down before loading, and avoid siting it in direct sun or beside hot equipment if you want stable service through busy periods.

The supplied specification does not include an annual energy figure, so we will not make up a running-cost number. It connects to a 230V, 50Hz supply, and real cost depends on your tariff, ambient conditions and loading pattern.

The supplier lists a 230V, 50Hz connection. Have the socket position and circuit checked before the cabinet is delivered, especially if it will share a counter run with other refrigeration.

Yes, it has interior lighting. Defrost is manual, so schedule defrost and cleaning during quieter periods rather than waiting for ice build-up to affect service.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

CombiSteel Curacao 10x5L Ice Cream Display Freezer 7472.0105 Product Data

Brand CombiSteel
Dimensions (W×D×H) 1447 × 825 × 1257 mm
Interior Dimensions 1315x560x687
Capacity 454 Ltr
Colour / Finish White
Temperature Range -22/-15
Max. Ambient Temp. 30
Refrigerant R 290
Cooling Static
Defrost Manual
Electrical Power 0.5 kW
Voltage 230V / 50Hz
Mobile Yes
Insulation 60 mm
Weight 116 kg
If you have any questions about the CombiSteel Curacao 10x5L Ice Cream Display Freezer 7472.0105 then please get in touch.
