INOMAK Bain Marie with Heated Cupboard 5x GN1/1 MHV718

£1,576.71

+vat

- +

Brand:

SKU: MHV718

Product summary

Size: 1795 x 700 x 860

Product description

  • High gradee AISI 304 stainless steel exterior & interior
  • Open type
  • Wet well accepts GN1/1 upto 150mm deep (not supplied)
  • Digital controller with temperature display
  • Fan assisted
  • Wet well bain marie with easy access drain tap¬†
  • Heater protection against low water level in the tank
  • Robust construction
  • Height adjustable stainless-steel legs
  • Tempered Glass Vitrines

A full-capacity wet bain marie holding five GN1/1 pans with heated storage below, offering the holding depth for high-volume catering without a second dedicated unit.

SPECIFICATION 18 facts · tap for all External W × D × H1795 x 700 x 860Width1795 mmDepth700 mmHeight860 mmGross weight104 kgVoltage / frequency4450w

Manufacturer documents2

Identity4

Brand INOMAKsite
GTIN / EAN 5212016700750site
Product code MHV718site
Type Wet Well Free Standing Bain Mariescatalogue

Size & weight6

Depth 700 mmsite
External (W×D×H) 1795 × 700 × 860 mmcatalogue
External W × D × H 1795 x 700 x 860site
Gross weight 104 kgcatalogue
Height 860 mmsite
Width 1795 mmsite

Performance2

Controller Digital controller with temperature displaysite
Temperature range Bain Marie Max. +90C / Heated Cupboard Max.+72Csite

Power & energy3

Input power 25amp supplysite
Rated input 4450 Wcatalogue
Voltage / frequency 4450wsite

Build & fittings1

Exterior finish Stainless Steelsite
THE WORKING VIEW

Why this wet well free standing bain marie earns its place

The MHV718 is built for kitchens that run with genuine complexity and volume. Five hot-held pans on the pass (GN1/1 standard size, up to 150 mm deep) plus a heated cupboard with capacity for four more pans below means you have real menu depth without overloading a single unit. One service with no down-time swapping stock or waiting for backup portions to heat through.

Everything here is engineered for hard use. AISI 304 stainless steel inside and out resists the corrosion that comes from continuous wet-well operation. Tempered glass sides let customers see what's on offer. A digital controller with fan assistance holds temperature precisely, and the easy-access drain tap means you're not wrestling with the water circuit during service. Height-adjustable legs handle uneven floors and make the space underneath accessible for proper cleaning.

At 1795 mm wide (a substantial pass installation) and 860 mm tall, the MHV718 is the go-to unit for restaurants with serious menu variety, hotels managing multiple sittings, contract caterers servicing different venues, or any kitchen where food consistency across a full service is non-negotiable. The 104 kg weight means professional installation, but that's an asset—this is a unit built to stay put and perform.

BEFORE YOU BUY

Questions, answered straight

A: If you're thinking in terms of menu items rather than portion mass, yes. Five different items on the pass (sauces, veg, starch, proteins in two variants) with the cupboard holding backup means you reload from cold stock, not cycle pans frantically. High-volume kitchens often use one MHV718 per station rather than daisy-chaining smaller units.

A: It's a wet-well unit, so water circulation provides the heat (not direct gas or electric). The digital control and fan run on a standard electrical supply. See the manual for specific water pressure and electrical requirements, or call us on 01792 732702 for installation planning.

A: At 1795 mm, it's a major installation. Most units replace a full section of pass or sit as a dedicated holding station. The legs are height-adjustable for slightly uneven floors, but you should plan the layout in advance.

A: The heater has protection against running dry, so it won't damage itself if you forget a top-up. That said, check the water level daily—it's part of your opening routine. See the manual for the procedure, or contact us on 01792 732702 if you're setting up a new site.

A: Daily: drain the well, wipe and rinse the interior. Weekly: a thorough drain, clean and refill of the water circuit (about 15–20 minutes; the manual walks you through it). Annual professional service is recommended to keep the heating circuit efficient—contact us on 01792 732702 to arrange.

A: Standard GN1/1 pans, 150 mm deep maximum. These are catering industry standard and available from any mainstream supplier; stock and spares are never a problem.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

Dimensions

External Dimension (WxDxH): 1795 x 700 x 860

Cooling and Functions

Type of Controller: Digital controller with temperature display

Power and Consumption

Input Power: 25amp supply
Voltage / Frequency: 4450w

Measures and Content

Design and Material

Exterior Finish: Stainless Steel

INOMAK Bain Marie with Heated Cupboard 5x GN1/1 MHV718 Product Data

If you have any questions about the INOMAK Bain Marie with Heated Cupboard 5x GN1/1 MHV718 then please get in touch.
