INOMAK 1400mm Wet Well Bain Marie With Heated Cupboard & Double Gantry MHVW-DHG14

£2,143.04

+vat

Brand:

SKU: MHVW-DHG14

Product summary

Size: 1410 x 700 x 1632

Product description

  • Double shelf gantry
  • 1 Halogen heated box mounted to top shelf – 4 Lamps
  • High grade AISI 304 stainless steel exterior & interior
  • Open type
  • Wet well accepts GN1/1 upto 150mm deep (not supplied)
  • Digital controller with temperature display
  • Fan assisted
  • Wet well bain marie with easy access drain tap¬†
  • Heater protection against low water level in the tank
  • Robust construction
  • Height adjustable stainless-steel legs
  • Tempered Glass Vitrines

A 1400mm mid-size double-shelf wet-well bain marie with integrated halogen heating and dual-gantry design, combining visible holding and plate warming for mid-to-large volume kitchens.

SPECIFICATION 17 facts · tap for all External W × D × H1410 x 700 x 1632Width1410 mmDepth700 mmHeight1632 mmVoltage / frequency3850WInput power20amp supply

Manufacturer documents2

Identity4

Brand INOMAKsite
GTIN / EAN 5212016700736site
Product code MHVW-DHG14site
Type Wet Well Free Standing Bain Mariescatalogue

Size & weight5

Depth 700 mmsite
External (W×D×H) 1410 × 700 × 1632 mmcatalogue
External W × D × H 1410 x 700 x 1632site
Height 1632 mmsite
Width 1410 mmsite

Performance2

Controller Digital controller with temperature displaysite
Temperature range Bain Marie Max. +90C / Heated Cupboard Max.+72Csite

Power & energy3

Input power 20amp supplysite
Rated input 3850 Wcatalogue
Voltage / frequency 3850Wsite

Build & fittings1

Exterior finish Stainless Steelsite
THE WORKING VIEW

Why this wet well free standing bain marie earns its place

The MHVW-DHG14 brings the gantry efficiency of a larger unit into a footprint that fits mid-sized kitchens without swallowing the pass. The open-type design gives you immediate access to the wet well below — holding GN1/1 pans up to 150mm deep — whilst the double-shelf gantry supports a heated box mounted on the top shelf. Four halogen lamps in the heated box keep plates and additional holding items warm, with digital temperature control so you're always in command.

Built throughout in high-grade AISI 304 stainless steel with tempered glass vitrines, the MHVW-DHG14 is engineered for hard service. The wet well drains via an easy-access tap and includes low-water protection that cuts the heater if levels drop. Fan assistance ensures even heat distribution. The double-shelf structure creates a natural division between your prepared components below and plate warming above, letting you manage multiple holding tasks without cross-contamination or heat loss.

At 1410mm wide and 1632mm tall, the MHVW-DHG14 delivers substantial holding capacity in a reasonably compact footprint — tall enough to make statement on the pass, wide enough to handle serious volume without dominating a mid-sized kitchen. Height-adjustable stainless-steel legs let you level it anywhere, and the open design makes end-of-service cleaning straightforward.

BEFORE YOU BUY

Questions, answered straight

The wet well holds your prepared components in GN1/1 pans up to 150mm deep — sauces, vegetables, proteins, starches. The heated box on the top shelf (with 4 halogen lamps) is typically used for warming plates and bowls or holding additional items. Both have independent temperature control.

GN1/1 pans up to 150mm deep. The exact number that fit depends on pan size and your arrangement — because it's open-type, you have flexible stacking. Pans are not supplied.

The double-shelf gantry design creates two distinct holding levels stacked vertically. This gives you the holding capacity of a much larger footprint whilst keeping the width manageable at 1410mm.

The open design means there are no enclosed cupboards or hard-to-reach corners. You can wipe down quickly at the end of service, and the stainless-steel construction resists marks and buildup. Refer to the user manual for detailed cleaning guidance.

Built-in heater protection automatically cuts the heating if water levels fall, preventing equipment damage. Always maintain adequate water in the wet well during service.

Height-adjustable stainless-steel legs mean you can access underneath if needed. For detailed servicing or repairs, contact Craven Cooling on 01792 732702.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

Dimensions

External Dimension (WxDxH): 1410 x 700 x 1632

Cooling and Functions

Type of Controller: Digital controller with temperature display

Power and Consumption

Input Power: 20amp supply
Voltage / Frequency: 3850W

Measures and Content

Design and Material

Exterior Finish: Stainless Steel

INOMAK 1400mm Wet Well Bain Marie With Heated Cupboard & Double Gantry MHVW-DHG14 Product Data

If you have any questions about the INOMAK 1400mm Wet Well Bain Marie With Heated Cupboard & Double Gantry MHVW-DHG14 then please get in touch.
