CombiSteel Refrigerated Counter Top 4x 1/3GN 7450.0015

£398.00

+vat

Brand:

SKU: 7450.0015

Product summary

Size W/D/H (mm) x x

Product description

The Combisteel 7450.0015 is a refrigerated countertop glass topping unit that holds four 1/3-size gastronorm pans chilled under a glass canopy, keeping prepared toppings and cold ingredients at service temperature on a compact prep or garnish line. Four 1/3 GN pans of core toppings and cold prep held visible, chilled and within reach on a compact 1200 mm counter-top, cutting fridge walks and fitting tight prep lines.

Downloads

SPECIFICATION 23 facts · tap for all Width1200 mmDepth395 mmHeight435 mmGross / net weight48 kgVoltage / frequency23050Voltage230V / 50Hz

Identity3

Brand CombiSteelcatalogue
GTIN / EAN 7435137889878catalogue
Type Glass Topping Unitscatalogue

Size & weight5

Depth 395 mmsite
External (W×D×H) 1200 × 395 × 435 mmcatalogue
Gross / net weight 48 kgsite
Height 435 mmsite
Width 1200 mmsite

Capacity1

Gastronorm size 4 x 1/3catalogue

Performance3

Cooling type R 600 Asite
Defrost type Automaticsite
Temperature range +2 / +8site

Power & energy7

Energy consumption 0,34site
Frequency 50 Hzcatalogue
Noise level 4040site
Rated input 340 Wcatalogue
Rated power 34 kWcatalogue
Voltage 230V / 50Hzcatalogue
Voltage / frequency 23050site

Build & fittings4

Accessories 3x long GN bar, 4x short GN barcatalogue
Colour Stainless steelcatalogue
Exterior finish Stainless steel 18/8site
Interior finish Stainless steel 201site
THE WORKING VIEW

Why this glass topping unit earns its place

A refrigerated glass topping unit built to hold four 1/3-size gastronorm pans chilled on the counter, right where dishes get built. The 1/3 pans are the deeper, larger format, so this is the unit for holding a good quantity of a smaller number of ingredients — the workhorse toppings and cold prep a section leans on all service — under a glass canopy and within arm's reach of whoever's plating. At 1200 mm wide and 435 mm tall, it's compact enough to fit on a prep pass or service station without dominating the line.

In service it's a self-contained chilled well: load the pans, drop the glass guard and it holds temperature at +2 to +8 °C through the shift. The canopy keeps ingredients covered and on show while limiting the warm air getting in, and the compact 1200 × 395 mm footprint means it earns its place on a tight line rather than claiming floor space. Stainless steel construction stands up to daily washing and the busy splashes of service. Pans lift out at the end of service for cleaning and the well underneath wipes down.

It's a self-contained countertop unit running on a standard 230V supply, so it sits on existing worktop rather than being built in — give it a level, solid surface with clearance around the sides for airflow and a socket within reach. At 48 kg, it's solid enough to sit firmly without rocking. Because it sits on top of the counter, work out the finished working height before it goes in so staff aren't reaching over it all shift. Combisteel build, supplied through Craven Cooling with servicing backup.

BEFORE YOU BUY

Questions, answered straight

It's a refrigerated well that sits on the counter and holds gastronorm pans of prepared ingredients chilled at the point of service, under a glass canopy. Toppings stay covered, visible and at temperature so staff build dishes straight off the line.

It's configured for four 1/3-size gastronorm pans. The 1/3 format is deeper and larger, so it suits holding a good quantity of a smaller number of core ingredients.

No. It's a self-contained countertop unit that sits on an existing worktop. Give it a level surface, clearance around the sides for airflow, and a socket within reach.

Yes. The gastronorm pans lift out to be washed separately and the well underneath wipes down. It also makes swapping ingredients between services quick.

Its compact countertop footprint is aimed at tight prep and garnish lines where a full prep counter won't fit but you still want cold ingredients to hand. Keeping prep chilled on the counter cuts trips to the fridge.

Craven Cooling supplies and supports the unit, and the service desk can help on 01792 732702. Keeping the airflow clear and the well clean day to day is the best prevention. It runs quiet — 40 dB(A) — so it won't dominate a busy prep line.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

CombiSteel Refrigerated Counter Top 4x 1/3GN 7450.0015 Product Data

Brand CombiSteel
Dimensions (W×D×H) 1200 × 395 × 435 mm
GN Capacity 4 x 1/3
Material Stainless steel 18/8
Interior Material Stainless steel 201
Colour / Finish Stainless steel
Temperature Range +2 / +8
Refrigerant R 600 A
Cooling Static
Defrost Automatic
Electrical Power 0.34 kW
Voltage 230V / 50Hz
Noise Level 40 dB
Weight 48 kg
If you have any questions about the CombiSteel Refrigerated Counter Top 4x 1/3GN 7450.0015 then please get in touch.
