CombiSteel 700 Series Refrigerated Counter Upstand 4 Door Monoblock Energy Line 7489.5410

£1,911.85

+vat

- +

Brand:

SKU: 7489.541

Product summary

Size W/D/H (mm) 2270 x 700 x 860

Product description

Downloads

SPECIFICATION 29 facts · tap for all Width2270 mmDepth700 mmHeight860 mmGross / net weight205 kgVoltage / frequency23050/60Voltage230V / 50/60Hz

Identity4

Brand CombiSteelcatalogue
GTIN / EAN 6017439293266catalogue
Range / series Pro Linecatalogue
Type Four Door Counter Fridgescatalogue

Size & weight5

Depth 700 mmsite
External (W×D×H) 2270 × 700 × 860 mmcatalogue
Gross / net weight 205 kgsite
Height 860 mmsite
Width 2270 mmsite

Capacity4

Capacity 632 Ltrcatalogue
Gastronorm size 1/1catalogue
Gross volume 632 litrescatalogue
Shelves 4catalogue

Performance6

Controller Digitalcatalogue
Cooling type R 290site
Defrost type Automaticsite
Max ambient 4343 °Ccatalogue
Maximum ambient 4343site
Temperature range -2/+8site

Power & energy7

Energy consumption 0,308site
Frequency 50 Hzcatalogue
Noise level 4040site
Rated input 308 Wcatalogue
Rated power 308 kWcatalogue
Voltage 230V / 50/60Hzcatalogue
Voltage / frequency 23050/60site

Build & fittings2

Exterior finish Stainless steel 430site
Insulation 60 mmcatalogue

Other stated facts1

Mobility Nocatalogue
THE WORKING VIEW

Why this four door counter fridge earns its place

This is a four-door refrigerated counter from the Energy Line range, built to sit under the pass and carry a full section's chilled stock beneath the worktop. Holding 632 litres across four doors, it puts storage and a prep surface in one back-of-house unit, so ingredients stay cold directly where they are portioned and plated. The four doors give you more compartments to zone stock than a shorter counter, which suits longer lines and higher-throughput sections.

The counter uses a monoblock refrigeration unit running at –2 to +8 °C — a single self-contained cooling module — which keeps the working parts grouped for straightforward access when it is serviced. At just 40 dB(A), it is one of the quieter refrigeration units on the line, a useful feature where the kitchen ambience matters. A rear upstand runs along the back of the worktop, so wipe-downs push spills forward rather than behind the unit and the surface stays cleaner through service. The four doors also mean you open only the compartment in use, holding temperatures steady while the line is under pressure.

On fit, this is a floor-standing counter 2.27 m wide, 0.70 m deep and 0.86 m tall, weighing 205 kg. It is meant to run the length of a worktop line, so the deciding factors are your run length and doorway clearance. Check that those dimensions fit your available space before ordering, and leave room at the back and sides for airflow and service access to the monoblock.

BEFORE YOU BUY

Questions, answered straight

It is a four-door counter, so you get more compartments to zone stock by section or service. You open only the door you need, which limits cold loss and holds temperatures steady while the line is busy.

The upstand is a raised lip along the back of the worktop. It stops spills and debris dropping behind the unit during service, so wipe-downs stay quick and the surface behind the prep area stays clean.

The monoblock is a single, self-contained cooling module rather than separate parts spread through the cabinet. It keeps the working components grouped, which makes routine access and servicing more straightforward.

It runs at –2 to +8 °C for chilled storage of prepared ingredients rather than freezing. That range suits most prepped stock — check against your temperature-sensitive items before loading.

It is 2.27 m wide, 0.70 m deep and 0.86 m tall, weighing 205 kg. Measure your run and check those dimensions against your pass height, available width and doorway clearance before ordering.

Keep the condenser clear, the door seals clean and the airflow around the monoblock unobstructed, and book routine servicing before seasonal peaks. Craven Cooling can arrange service and spares on 01792 732702.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

CombiSteel 700 Series Refrigerated Counter Upstand 4 Door Monoblock Energy Line 7489.5410 Product Data

Brand CombiSteel
Type Pro Line
Dimensions (W×D×H) 2270 × 700 × 860 mm
Capacity 632 Ltr
GN Capacity 1/1
Material Stainless steel 430
Temperature Range -2/+8
Max. Ambient Temp. 43
Refrigerant R 290
Cooling Ventilated
Defrost Automatic
Number of Doors 4
Number of Grids/Shelves 4
Electrical Power 0.308 kW
Voltage 230V / 50/60Hz
Mobile No
Lockable No
Noise Level 40 dB
Insulation 60 mm
Weight 205 kg
If you have any questions about the CombiSteel 700 Series Refrigerated Counter Upstand 4 Door Monoblock Energy Line 7489.5410 then please get in touch.
