Atosa YBF9242GR Slimline Triple Door Freezer

£2,124.63

+vat

Brand:

SKU: YBF9242GR

Product summary

The Atosa YBF9242GR Triple Door Freezer is a heavy duty slimline unit, ideal for kitchens where space is restricted. This product is made of high grade stainless steel, both internally and externally. Its self-closing and stay open doors increase usability for a busy kitchen.

Product description

  • Heavy Duty Top Mounted Compressor Unit
  • High Grade Stainless Steel Construction Interior
  • High Grade Stainless Steel Construction Exterior
  • Easy to clean interior with rounded corner design
  • Pre-installed castors
  • Easy to clean black plastic door handle
  • Slimline design ? reduced footprint
  • Standard safety door lock
  • Self-closing and stay open door
  • Climate Class 4
  • Magnetic door gaskets
  • Pre-installed shelves

Triple-door slimline glass freezer with stainless steel construction and self-closing doors—three separate compartments in one compact unit for high-volume frozen display with efficient restocking.

Downloads

SPECIFICATION 24 facts · tap for all Gross weight190 kgNet weight180 kgVoltage220/50/1Temperature range-22 to -17 °CMaterialS/S Int + ExtProduct codeYBF9242GR

Manufacturer documents1

Identity3

Brand Atosasite
Product code YBF9242GRsite
Type Triple Door Upright Glass Door Freezerscatalogue

Size & weight5

External (W×D×H) 1800 × 745 × 1945 mmcatalogue
Gross weight 190 kgcatalogue
Internal (W×D×H) 1700 × 540 × 1380 mmcatalogue
Net weight 180 kgcatalogue
Packed (W×D×H) 1840 × 774 × 2050 mmcatalogue

Capacity3

Gross volume 1390 litrescatalogue
Shelf dimensions 525 x 530 / 510 x 530 shelfcatalogue
Shelves 9catalogue

Performance6

Climate class 4catalogue
Cooling Ventilatedcatalogue
Defrost Electric Defrostcatalogue
Interior light Yescatalogue
Refrigerant R290hc / 150gcatalogue
Temperature range -22 to -17 °Ccatalogue

Power & energy3

Rated input 800 Wcatalogue
Supply 4 Acatalogue
Voltage 220/50/1catalogue

Build & fittings1

Material S/S Int + Extcatalogue

Other stated facts2

Energy consumption 4307 kWh/yearcatalogue
Energy rating Dcatalogue
THE WORKING VIEW

Why this triple door upright glass door freezer earns its place

This triple-door layout solves a real problem: you need frozen storage and impulse display, but you don't have the depth of a standard three-door unit. The slimline profile keeps the footprint tight while three independent doors let you stock, chill, and restock without moving everything at once.

Each door is a separate sealed compartment with its own magnetic gasket—no cold bridging, no frost migration between sections. The self-closing mechanism on each door holds open for restocking, then closes reliably when released. Every door locks independently with a standard safety lock, so you can isolate sections during service or if a seal needs checking.

Stainless steel runs throughout the interior and exterior, chosen for durability and speed of cleaning. The rounded-corner design inside means product debris doesn't accumulate in tight junctions; a quick wipe keeps hygiene tight. The black plastic door handles are easy to grip and designed to stay clean—no fingerprint traps that collect bacteria.

BEFORE YOU BUY

Questions, answered straight

Yes. Each door seals and locks independently, so you can operate or service one compartment without disturbing the others. Each has its own magnetic gasket and self-closing mechanism.

The slimline depth reduces total volume compared to standard three-door units. For exact capacity and shelf configuration, check the specification sheet or contact our service team on 01792

Slimline design reduces depth, but confirm your doorway width and the cabinet's dimensions before ordering. Contact us on 01792 732702 to verify fit for your space.

Each door operates independently with its own self-closing mechanism. You can hold one door open for restocking while the others stay sealed, preventing heat loss to the other compartments.

The self-closing and locking mechanisms are standard; no special servicing is required. For any adjustments or repairs, contact our service team on 01792 732702.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

Atosa YBF9242GR Slimline Triple Door Freezer Product Data

Model YBF9242GR
Exterior Dimension (WxDxH) mm 1800 x 745 x 1945
Interior Dimension (WxDxH) mm 1700 x 540 x 1380
Packing Dimension (WxDxH) mm 1840 x 774 x 2050
Shelf Dimensions mm 525 x 530 / 510 x 530 shelf
Shelf Quantity 9
Shelf Loading Capacity (Kg Pc) 40
Capacity (Litre) 1390
Net Weight (Kgs) 180
Gross Weight (Kgs) 190
Voltage (V/HZ/PH) 220/50/1
Power (Watts) 800
Electrical Current (Amps) 4
KWh/annum 4307
Energy Efficiency Class D
Climate Class 4
Defrost Method Electric Defrost
Refrigerant Type / Amount R290hc / 150g
Cooling Method Ventilated
Inner Temperature (ºC) -22ºC to -17ºC
Insulation Polyurethane foam
Foaming Material C5H10
Castors 6 (3 Braked on front)
Material External / Internal S/S Int + Ext
Lighting Yes
Door lock Yes
If you have any questions about the Atosa YBF9242GR Slimline Triple Door Freezer then please get in touch.
