TEFCOLD UF200V Undercounter Freezer

£734.00 £467.00

+vat

- +

Brand:

SKU: 33861

Energy Arrow

Product summary

  • Integrated handle
  • Electronic thermostat
  • Automatic defrost
  • Adjustable shelves
  • Ventilated cooling
  • Lock

Product description

The UF-V range of storage freezers comes in various sizes. The freezer has an effective ventilated refrigeration system, which ensures an even temperature throughout the cabinet. Set the temperature on the easy-to-use digital thermostat display. You can customize the freezer to fit your needs with adjustable shelves. Defrost happens automatically.

Sale!
SPECIFICATION 47 facts · tap for all External W × D × H600 x 585 x 855 mmWidth600 mmDepth585 mmGross / net weight52 / 47 kgGross weight52 kgVoltage / frequency220-240/50 V/Hz

Identity6

Brand TEFCOLDsite
GTIN / EAN 5708181994341site
Product code 33861site
Sub title Undercounter Freezercatalogue
Type Commercial Under Counter Freezerscatalogue
Warranty 2 year parts & 1 year labour warranty. Exclusions apply (see terms and conditions) – addcatalogue

Size & weight11

Depth 585 mmsite
External (W×D×H) 600 × 585 × 855 mmcatalogue
External W × D × H 600 x 585 x 855 mmsite
Gross / net weight 52 / 47 kgsite
Gross weight 52 kgcatalogue
Height 855 mmsite
Internal (W×D×H) 484 × 470 × 610 mmcatalogue
Internal W × D × H 484 x 470 x 610 mmsite
Packed (W×D×H) 690 × 650 × 910 mmcatalogue
Packed W × D × H 690 x 650 x 910 mmsite
Width 600 mmsite

Capacity3

Doors 1catalogue
Gross volume 200 litrescatalogue
Shelves 3catalogue

Performance10

Climate class 4site
Controller Electronicsite
Cooling type Ventilatedsite
Defrost type Automaticsite
Max ambient 30 °Ccatalogue
Maximum ambient +30°C, 55% RHsite
Refrigerant R290site
Refrigerant charge 45 gsite
Temperature range -24 to -10site
Thermometer Yessite

Power & energy6

Annual energy consumption 592 kWh/yearsite
Energy consumption 1.62 kWh/24hsite
Energy efficiency index 21.7 %site
Input power 180 Wsite
Noise level 42 dB(A)site
Voltage / frequency 220-240/50 V/Hzsite

Build & fittings6

Castors 2 rollerssite
Exterior finish Whitesite
Feet / legs 4 adjustable feetsite
Interior light Nosite
Max load per shelf 110site
Shelf dimensions 490 x 380 mmsite

Other stated facts1

Energy class Acatalogue
THE WORKING VIEW

Why this commercial under counter freezer earns its place

The TEFCOLD UF200V is a compact single-door undercounter freezer built to slot into a working line where floor space is tight. It gives 200 litres gross and 120 litres net across three white wire shelves behind one hinged solid door, with a white exterior and a white ABS interior that wipes down cleanly. It is the freezer that adds a station's worth of frozen storage under the counter rather than taking a full upright's footprint.

Day to day it holds -24 to -10 °C on static cooling, managed by an electronic controller. It sits at energy class A with an EEI of 22.0, and carries climate class 4 for warmer kitchen ambients.

The cabinet measures 600 × 600 × 850 mm (W×D×H), so it slides under a standard worktop, and it ships crated at 690 × 650 × 910 mm — check the delivery route first. It runs on a standard 13A supply at 220–240 V, 50 Hz, and weighs 52 kg gross, 47 kg net.

BEFORE YOU BUY

Questions, answered straight

The cabinet measures 600 × 600 × 850 mm (W×D×H), sized to slide under a standard worktop. It ships crated at 690 × 650 × 910 mm, so check the delivery route as well.

It runs -24 to -10 °C on static cooling, managed by an electronic controller, giving a working frozen band for undercounter stock.

It sits at energy class A with an EEI of 22.0, and carries climate class 4 for warmer kitchen ambients.

It gives 200 litres gross and 120 litres net across three white wire shelves behind one solid door.

It runs on a standard 13A supply at 220–240 V, 50 Hz, and weighs 52 kg gross, 47 kg net.

Yes. Our service team covers commercial refrigeration across the region — call 01792 732702 to arrange a visit or discuss a fault.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

Dimensions

Internal Dimension (WxDxH): 484 x 470 x 610 mm
External Dimension (WxDxH): 600 x 585 x 855 mm
Packed Dimension (WxDxH): 690 x 650 x 910 mm

Cooling and Functions

Type of Controller: Electronic
Type of Cooling: Ventilated
Type of Defrost: Automatic
Refrigerant: R290
Refrigerant Charge: 45 g
Thermometer: Yes

Power and Consumption

Energy Consumption: 1.62 kWh/24h
Temperature Range: -24 to -10 °C
Annual Energy Consumption: 592 kWh/year m³
EEI: 21.7 %
Input Power: 180 W
Voltage / Frequency: 220-240/50 V/Hz
Noise Level: 42 dB(A)

Measures and Content

Temperature Range: -24 to -10 °C
Climate Class: 4
Gross / Net Weight: 52 / 47 kg
Gross / Net Volume: 200 / 120 l
Max Ambient: +30°C, 55% RH

Design and Material

Door Reversible: Yes
Shelf Color: White
Shelf Dimensions: 490 x 380 mm
Max load on Shelves: 110 kg/m²
Feet / Legs: 4 adjustable feet
Castors: 2 rollers
Exterior Finish: White
Interior Finish: White
Interior Light: No
Lock: Yes
If you have any questions about the TEFCOLD UF200V Undercounter Freezer then please get in touch.
