TEFCOLD EVO1802 SS Patisserie Display Cabinet

£3,370.00

+vat

- +

Brand:

SKU: 38309

Energy Arrow

Product summary

  • Fully automatic
  • Fan assisted cooling
  • Adjustable feet
  • Interior light with switch
  • Digital controller and temperature display
  • Hinged glass for easy cleaning
  • Individually illuminated glass shelves
  • Glass rear sliding doors

Product description

The stainless steel units of the EVO range feature 4-tier patisserie display cabinets designed to beautifully showcase cakes and desserts. These cabinets boast individually illuminated glass shelves to enhance presentation. Fully automated fan-assisted cooling guarantees consistent cooling throughout the cabinet. Adjustable feet ensure stability, and the curved front glass hinges forward for easy cleaning. The pre-built glass design allows quick installation. An interior light with a switch offers optimal illumination, and the digital controller with a temperature display ensures precise control.

The Tefcold EVO1802 SS is a stainless steel patisserie display cabinet offering 2.3 m² of chilled display on three glass shelves plus base, held at +1 to +10 °C and served through two sliding glass doors, cooled by R290 with automatic defrost and electronic control.

Downloads

SPECIFICATION 40 facts · tap for all External W × D × H1800 x 755 x 1400 mmWidth1800 mmDepth755 mmGross / net weight255 / 220 kgGross weight255 kgVoltage / frequency220-240/50 V/Hz

Manufacturer documents2

Identity6

Brand TEFCOLDsite
GTIN / EAN 5708181999841site
Product code 38309site
Sub title Patisserie Display Cabinetcatalogue
Type Curved Glass Cake Display Fridgescatalogue
Warranty 2 year parts & 1 year labour warranty. Exclusions apply (see terms and conditions) – addcatalogue

Size & weight11

Depth 755 mmsite
External (W×D×H) 1800 × 755 × 1400 mmcatalogue
External W × D × H 1800 x 755 x 1400 mmsite
Gross / net weight 255 / 220 kgsite
Gross weight 255 kgcatalogue
Height 1400 mmsite
Internal (W×D×H) 1755 × 502 × 790 mmcatalogue
Internal W × D × H 1755 x 502 x 790 mmsite
Packed (W×D×H) 1900 × 840 × 1580 mmcatalogue
Packed W × D × H 1900 x 840 x 1580 mmsite
Width 1800 mmsite

Capacity3

Display area 2.3 m²site
Doors 2catalogue
Gross volume 890 litrescatalogue

Performance9

Climate class 3site
Controller Electronicsite
Defrost type Automaticsite
Max ambient 25 °Ccatalogue
Maximum ambient +25°C, 60% RHsite
Refrigerant R290site
Refrigerant charge 155 gsite
Temperature range +1 to +10site
Thermometer Yessite

Power & energy6

Annual energy consumption 4681 kWh/yearsite
Energy consumption 12.82 kWh/24hsite
Energy efficiency index 56.9 %site
Input power 780 Wsite
Noise level 46 dB(A)site
Voltage / frequency 220-240/50 V/Hzsite

Build & fittings2

Exterior finish Stainless steelsite
Interior light LEDsite

Other stated facts1

Energy class Ecatalogue
THE WORKING VIEW

Why this curved glass cake display fridge earns its place

The Tefcold EVO1802 SS is a stainless steel patisserie display cabinet built for high-volume cake, dessert and deli merchandising. It presents 2.3 m² of chilled display across three glass shelves plus the base deck, with a stainless steel interior and exterior, and it is served from the back through two sliding glass doors so staff can restock without breaking the customer view.

Day to day it holds a +1 to +10 °C band suited to patisserie and prepared chilled foods. Automatic defrost and an electronic controller manage the cycle, and it is rated climate class 3. It uses R290 refrigerant and carries energy class E at 4679.3 kWh a year — about £1170 a year at 25p/kWh, which reflects the size of the glazed display.

The display bay is 1755 mm wide internally (1755 × 502 × 790 mm), and the cabinet weighs 255 kg, so plan a two-person-plus delivery and a solid final position. It runs from a standard 13 A supply drawing 780 W, and holds a 155 g charge of R290. It operates at 46 dB.

BEFORE YOU BUY

Questions, answered straight

A +1 to +10 °C band, suited to patisserie, desserts and prepared chilled foods. It is rated climate class 3.

2.3 m² of display across three glass shelves plus the base deck, with an internal bay 1755 mm wide.

Energy class E at 4679.3 kWh a year, which is about £1170 a year at 25p/kWh. The figure reflects the large glazed display area; actual cost depends on your tariff and siting.

R290, with a 155 g charge. It runs at 46 dB from a standard 13 A supply drawing 780 W.

It weighs 255 kg, so plan a suitable delivery route and a solid, level final position. The display is served through two sliding glass doors.

Yes — our engineers cover commercial refrigeration across the region. Call 01792 732702 to arrange servicing or breakdown support.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

Dimensions

Internal Dimension (WxDxH): 1755 x 502 x 790 mm
External Dimension (WxDxH): 1800 x 755 x 1400 mm
Packed Dimension (WxDxH): 1900 x 840 x 1580 mm

Cooling and Functions

Type of Controller: Electronic
Type of Defrost: Automatic
Refrigerant: R290
Refrigerant Charge: 155 g
Thermometer: Yes

Power and Consumption

Energy Consumption: 12.82 kWh/24h
Temperature Range: +1 to +10 °C
Annual Energy Consumption: 4681 kWh/year m³
EEI: 56.9 %
Input Power: 780 W
Voltage / Frequency: 220-240/50 V/Hz
Noise Level: 46 dB(A)

Measures and Content

Temperature Range: +1 to +10 °C
Climate Class: 3
Gross / Net Weight: 255 / 220 kg
Gross / Net Volume: 890 / l
Max Ambient: +25°C, 60% RH
Total Display Area: 2.3 m² m²

Design and Material

Exterior Finish: Stainless steel
Interior Finish: Stainless steel
Interior Light: LED
If you have any questions about the TEFCOLD EVO1802 SS Patisserie Display Cabinet then please get in touch.
