TEFCOLD CW4 Buffet Display

£781.00

+vat

Brand:

SKU: 20021

Product summary

  • Static cooling
  • Digital controller and temperature display
  • Stainless steel construction
  • Suitable for building into counters
  • Accepts Gastronorm pans (not supplied)
  • Accepts GN1/1 pan(s) (not supplied)

Product description

The TEFCOLD CW4 is a drop-in buffet display well that recesses into a serving counter, holding +2 to +8 °C over a 1326 mm-wide chilled surface with static cooling and automatic defrost in a stainless steel body.

SPECIFICATION 38 facts · tap for all External W × D × H1436 x 678 x 536 mmWidth1436 mmDepth678 mmGross / net weight80 / 47 kgGross weight80 kgVoltage / frequency220-240/50 V/Hz

Identity6

Brand TEFCOLDsite
GTIN / EAN 5708181361136site
Product code 20021site
Sub title Buffet Displaycatalogue
Type Drop-In Display Fridgescatalogue
Warranty 2 year parts & 1 year labour warranty. Exclusions apply (see terms and conditions) – addcatalogue

Size & weight11

Depth 678 mmsite
External (W×D×H) 1436 × 678 × 536 mmcatalogue
External W × D × H 1436 x 678 x 536 mmsite
Gross / net weight 80 / 47 kgsite
Gross weight 80 kgcatalogue
Height 536 mmsite
Internal (W×D×H) 1326 × 570 × 175 mmcatalogue
Internal W × D × H 1326 x 570 x 175 mmsite
Packed (W×D×H) 1490 × 730 × 680 mmcatalogue
Packed W × D × H 1490 x 730 x 680 mmsite
Width 1436 mmsite

Capacity3

Capacity item specification 4 x GN1/1 pcscatalogue
GN pan capacity 4 x GN1/1site
Gross volume 139 litrescatalogue

Performance9

Controller Electronicsite
Cooling type Staticsite
Defrost type Automaticsite
Max ambient 30 °Ccatalogue
Maximum ambient +30°C, 55% RHsite
Refrigerant R600asite
Refrigerant charge 135 gsite
Temperature range +2 to +8site
Thermometer Yessite

Power & energy5

Annual energy consumption 1051 kWh/yearsite
Energy consumption 2.88 kWh/24hsite
Input power 235 Wsite
Noise level 42 dB(A)site
Voltage / frequency 220-240/50 V/Hzsite

Build & fittings1

Exterior finish Stainless steelsite
THE WORKING VIEW

Why this drop-in display fridge earns its place

The CW4 is a drop-in buffet display built to recess into a serving counter and present chilled food for self-service or assisted lines. The stainless steel well runs 1326 mm across the internal display, giving a long, shallow chilled surface for platters, salads and cold dishes at the pass.

It holds +2 to +8 °C under electronic control with static cooling and automatic defrost. It runs on R600a with a 135 g charge, draws 235 W and runs at 42 dB. Rated energy use is 1051.2 kWh a year — about £263 a year at 25p/kWh.

Externally the body measures 1436 × 678 × 536 mm (W×D×H) and weighs 80 kg gross, dropping into a counter aperture sized to the unit. It runs from a standard 13 amp, 220-240 V supply. The internal display is 1326 × 570 mm with a 175 mm depth, giving 136 litres net against 139 litres gross.

BEFORE YOU BUY

Questions, answered straight

The CW4 recesses into a counter cutout, with the stainless steel well sitting in the worktop. External dimensions are 1436 × 678 × 536 mm (W×D×H); size the aperture to the unit.

It holds +2 to +8 °C under electronic control with static cooling, suited to chilled buffet and self-service food. Automatic defrost clears frost without intervention.

The chilled well is 1326 × 570 mm with a 175 mm depth, giving 136 litres net and 139 litres gross for platters, salads and cold dishes.

Rated energy use is 1051.2 kWh a year, about £263 a year at 25p/kWh. It draws 235 W and runs at 42 dB.

It uses R600a with a 135 g charge. For servicing or install advice, call Craven Cooling on 01792 732702.

It weighs 80 kg gross and 47 kg net, and runs from a standard 13 amp, 220-240 V supply.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

Dimensions

Internal Dimension (WxDxH): 1326 x 570 x 175 mm
External Dimension (WxDxH): 1436 x 678 x 536 mm
Packed Dimension (WxDxH): 1490 x 730 x 680 mm

Cooling and Functions

Type of Controller: Electronic
Type of Cooling: Static
Type of Defrost: Automatic
Refrigerant: R600a
Refrigerant Charge: 135 g
Thermometer: Yes

Power and Consumption

Energy Consumption: 2.88 kWh/24h
Temperature Range: +2 to +8 °C
Annual Energy Consumption: 1051 kWh/year m³
Input Power: 235 W
Voltage / Frequency: 220-240/50 V/Hz
Noise Level: 42 dB(A)

Measures and Content

Capacity GN Pans: 4 x GN1/1 pcs
Temperature Range: +2 to +8 °C
Gross / Net Weight: 80 / 47 kg
Gross / Net Volume: 139 / 136 l
Max Ambient: +30°C, 55% RH

Design and Material

Exterior Finish: Stainless steel
Interior Finish: Stainless steel
If you have any questions about the TEFCOLD CW4 Buffet Display then please get in touch.
