TEFCOLD IC401SCE + CANOPY Scoop Ice Cream Display

£914.00

+vat

- +

Brand:

SKU: 53141

Energy Arrow

Product summary

  • Curved glass canopy
  • Angled sliding lids with lock
  • Storage under baskets
  • Castors with brake
  • Climate class 5 for high performance in warm surroundings
  • Accepts plastic napoli size tubs. Stainless napoli pans not required

Product description

Scoop Ice Cream Display with Baskets and Canopy

The IC401SCE + CANOPY features a curved glass canopy and angled sliding lids with locks for optimal product visibility and security. Perfect for branding, it offers storage under baskets, a digital thermometer, and castors with brakes for easy mobility. With a climate class 5 rating, it excels in high performance even in warm environments. Say goodbye to stainless Napoli pans – this unit accepts plastic Napoli size tubs.

The TEFCOLD IC401SCE is a scoop ice cream display freezer with a clear canopy and a 1180 mm-wide display, running -24 to -14 °C on R290 refrigerant, drawing 141 W from a 13-amp supply, with manual defrost and mechanical control in a white finish.

SPECIFICATION 41 facts · tap for all External W × D × H1300 x 615 x 1295 mmWidth1300 mmDepth615 mmGross / net weight106.2 / 96.2 kgGross weight106.2 kgVoltage / frequency220-240/50 V/Hz

Identity6

Brand TEFCOLDsite
GTIN / EAN 5708181731960site
Product code 53141site
Sub title Scoop Ice Cream Displaycatalogue
Type Static Cooled Ice Cream Display Freezerscatalogue
Warranty 2 year parts & 1 year labour warranty. Exclusions apply (see terms and conditions) – addcatalogue

Size & weight11

Depth 615 mmsite
External (W×D×H) 1300 × 615 × 1295 mmcatalogue
External W × D × H 1300 x 615 x 1295 mmsite
Gross / net weight 106.2 / 96.2 kgsite
Gross weight 106.2 kgcatalogue
Height 1295 mmsite
Internal (W×D×H) 1180 × 495 × 710 mmcatalogue
Internal W × D × H 1180 x 495 x 710 mmsite
Packed (W×D×H) 1400 × 750 × 1200 mmcatalogue
Packed W × D × H 1400 x 750 x 1200 mmsite
Width 1300 mmsite

Capacity3

Gross volume 352 litrescatalogue
Serving capacity 9 Plastic Tubs (5L)site
Under-counter storage 19 Plastic Tubs (5L)site

Performance8

Climate class 5site
Controller Mechanicalsite
Cooling type Staticsite
Defrost type Manualsite
Refrigerant R290site
Refrigerant charge 105 gsite
Temperature range -24 to -14site
Thermometer Yessite

Power & energy6

Annual energy consumption 799 kWh/yearsite
Energy consumption 2.19 kWh/24hsite
Energy efficiency index 43.2 %site
Input power 141 Wsite
Noise level 45 dB(A)site
Voltage / frequency 220-240/50 V/Hzsite

Build & fittings2

Castors 4 wheels, 2 with brakesite
Exterior finish Whitesite

Other stated facts1

Energy class Dcatalogue
THE WORKING VIEW

Why this static cooled ice cream display freezer earns its place

The IC401SCE is a wide scoop ice cream display freezer topped with a clear canopy, built to line up a full row of tubs behind curved glass at the serving point. The 1180 mm internal width gives room for a broad flavour range on show, and the white exterior with white painted steel interior keeps it a clean, wipe-down cabinet for a scooping counter.

In use it holds -24 to -14 °C, the band that keeps ice cream firm enough to scoop rather than setting solid. Defrost is manual, so the cabinet is cleared down on your schedule instead of pausing for an automatic cycle mid-service. Control is mechanical, noise is rated at 45 dB, and it carries climate class 5. On energy class D it uses 799.4 kWh a year, about £200 a year at 25p/kWh.

It draws 141 W and runs from a standard 13-amp supply. Internal dimensions are 1180 × 495 × 710 mm (W×D×H) and it weighs 106.2 kg, worth planning for on delivery and siting. Cooling uses R290 refrigerant with a 105 g charge.

BEFORE YOU BUY

Questions, answered straight

It runs -24 to -14 °C, firm enough to scoop cleanly rather than setting rock-hard. Control is mechanical.

No, defrost is manual. You clear the cabinet down on your own schedule so it never interrupts service for an automatic cycle.

It is energy class D and uses 799.4 kWh a year, about £200 a year at 25p/kWh. The real figure depends on your tariff and how hard the cabinet works.

The internal display is 1180 mm wide (1180 × 495 × 710 mm) and the unit weighs 106.2 kg, so plan the delivery route and siting accordingly.

It draws 141 W and runs from a standard 13-amp supply, so a normal socket is enough.

It uses R290 refrigerant with a 105 g charge and manual defrost. For servicing or spares, call Craven Cooling on 01792 732702.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

Dimensions

Internal Dimension (WxDxH): 1180 x 495 x 710 mm
External Dimension (WxDxH): 1300 x 615 x 1295 mm
Packed Dimension (WxDxH): 1400 x 750 x 1200 mm

Cooling and Functions

Type of Controller: Mechanical
Type of Cooling: Static
Type of Defrost: Manual
Refrigerant: R290
Refrigerant Charge: 105 g
Thermometer: Yes

Power and Consumption

Energy Consumption: 2.19 kWh/24h
Temperature Range: -24 to -14 °C
Annual Energy Consumption: 799 kWh/year m³
EEI: 43.2 %
Input Power: 141 W
Voltage / Frequency: 220-240/50 V/Hz
Noise Level: 45 dB(A)

Measures and Content

Temperature Range: -24 to -14 °C
Climate Class: 5
Gross / Net Weight: 106.2 / 96.2 kg
Gross / Net Volume: 352 / 325 l

Design and Material

Serving Capacity: 9 Plastic Tubs (5L)
Storage capacity (under): 19 Plastic Tubs (5L)
Castors: 4 wheels, 2 with brake
Exterior Finish: White
Interior Finish: White
Lock: Yes
If you have any questions about the TEFCOLD IC401SCE + CANOPY Scoop Ice Cream Display then please get in touch.
