TEFCOLD IC302SC-SO Scoop Ice Cream Freezer

£726.00

+vat

Brand:

SKU: 71498

Energy Arrow

Product summary

  • Curved glass canopy
  • LED interior light
  • Great branding possibilities
  • Castors with brake
  • Flat sliding glass lids with lock
  • Accepts plastic napoli size tubs. Stainless napoli pans not required
  • Storage under baskets
  • Climate class 5 for high performance in warm surroundings

Product description

Scoop ice cream freezer with canopy

The IC-SC-SO canopy range is an ideal way to add scooping ice cream sales to your business even if you are on an budget. This is one of our most popular ranges. A curved glass canopy makes an attractive display for scooping tubs (Baskets which fit 5 litre tubs, with the option for 4 ltr baskets/tubs if required). Flat glass sliding lids (with lock) allow access to the ice cream for serving and help insulate the unit when not in use.

The Tefcold IC302SC-SO is a 296-litre-gross scoop ice cream display freezer that holds product at -24 to -14 °C, uses R290 refrigerant, is rated energy class D, and runs at about £166 a year at 25p/kWh.

SPECIFICATION 44 facts · tap for all External W × D × H1010 x 630 x 1250 mmWidth1010 mmDepth630 mmGross / net weight116 / 107 kgGross weight116 kgVoltage / frequency220-240/50 V/Hz

Identity6

Brand TEFCOLDsite
GTIN / EAN 5708181760755site
Product code 71498site
Sub title Scoop Ice Cream Freezercatalogue
Type Static Cooled Ice Cream Display Freezerscatalogue
Warranty 2 year parts & 1 year labour warranty. Exclusions apply (see terms and conditions) – addcatalogue

Size & weight11

Depth 630 mmsite
External (W×D×H) 1010 × 630 × 1250 mmcatalogue
External W × D × H 1010 x 630 x 1250 mmsite
Gross / net weight 116 / 107 kgsite
Gross weight 116 kgcatalogue
Height 1250 mmsite
Internal (W×D×H) 890 × 510 × 655 mmcatalogue
Internal W × D × H 890 x 510 x 655 mmsite
Packed (W×D×H) 1100 × 750 × 960 mmcatalogue
Packed W × D × H 1100 x 750 x 960 mmsite
Width 1010 mmsite

Capacity3

Gross volume 296 litrescatalogue
Serving capacity 7 Plastic Tubs (5L) / 10 Plastic Tubs (4L)site
Under-counter storage 13 Plastic Tubs (5L) / 13 Plastic Tubs (4L)site

Performance10

Climate class 5site
Controller Mechanicalsite
Cooling type Staticsite
Defrost type Manualsite
Max ambient 40 °Ccatalogue
Maximum ambient +40°C, 40% RHsite
Refrigerant R290site
Refrigerant charge 85 gsite
Temperature range -24 to -14site
Thermometer Yessite

Power & energy6

Annual energy consumption 662.475 kWh/yearsite
Energy consumption 1.815 kWh/24hsite
Energy efficiency index 39.4 %site
Input power 300 Wsite
Noise level 45 dB(A)site
Voltage / frequency 220-240/50 V/Hzsite

Build & fittings3

Castors 4 wheels, 2 with brakesite
Exterior finish Whitesite
Interior light LEDsite

Other stated facts1

Energy class Dcatalogue
THE WORKING VIEW

Why this static cooled ice cream display freezer earns its place

The Tefcold IC302SC-SO is a scoop ice cream display freezer with 296 litres of gross capacity and 255 litres of net storage. It is built to present and serve scooping ice cream from a single station, so a parlour, café or seaside kiosk can hold a full range of flavours ready to serve at the counter.

The cabinet holds -24 to -14 °C under a mechanical controller, keeping ice cream at scooping temperature, and draws 300 W. Defrost is manual, so you build a regular clear-down into the routine. Rated energy class D at 662.5 kWh a year, it works out at about £166 a year at 25p/kWh, and it reads at 45 dB.

It runs on R290 refrigerant with an 85 g charge and is rated to climate class 5, so it holds temperature in warm ambient conditions. The exterior is white with a white painted-steel interior; full dimensions, weight and electrical requirements are in the specification table below.

BEFORE YOU BUY

Questions, answered straight

It runs from -24 to -14 °C under a mechanical controller — scooping temperature for ice cream — and draws 300 W.

296 litres gross and 255 litres net, enough to keep a full flavour range ready to serve.

It is rated to climate class 5, so it holds temperature in warm ambient conditions. It uses R290 refrigerant and reads at 45 dB.

It is rated energy class D at 662.5 kWh a year, which is about £166 a year at 25p/kWh. Actual cost depends on your tariff and how often it is opened.

No, defrost is manual, so plan a regular clear-down. The white painted-steel interior wipes clean.

Yes — Craven Cooling services the cabinets we sell. Call the workshop on 01792 732702 to arrange a visit or discuss a fault.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

Dimensions

Internal Dimension (WxDxH): 890 x 510 x 655 mm
External Dimension (WxDxH): 1010 x 630 x 1250 mm
Packed Dimension (WxDxH): 1100 x 750 x 960 mm

Cooling and Functions

Type of Controller: Mechanical
Type of Cooling: Static
Type of Defrost: Manual
Refrigerant: R290
Refrigerant Charge: 85 g
Thermometer: Yes

Power and Consumption

Energy Consumption: 1.815 kWh/24h
Temperature Range: -24 to -14 °C
Annual Energy Consumption: 662.475 kWh/year m³
EEI: 39.4 %
Input Power: 300 W
Voltage / Frequency: 220-240/50 V/Hz
Noise Level: 45 dB(A)

Measures and Content

Temperature Range: -24 to -14 °C
Climate Class: 5
Gross / Net Weight: 116 / 107 kg
Gross / Net Volume: 296 / 255 l
Max Ambient: +40°C, 40% RH

Design and Material

Serving Capacity: 7 Plastic Tubs (5L) / 10 Plastic Tubs (4L)
Storage capacity (under): 13 Plastic Tubs (5L) / 13 Plastic Tubs (4L)
Castors: 4 wheels, 2 with brake
Exterior Finish: White
Interior Finish: White
Interior Light: LED
Lock: Yes
If you have any questions about the TEFCOLD IC302SC-SO Scoop Ice Cream Freezer then please get in touch.
