ISA ISABELLA 13LX Scoop Ice Cream Display

£3,615.00

+vat

- +

Brand:

SKU: 20307

Energy Arrow

Product summary

  • Fully automatic
  • Curved glass canopy
  • Accepts Napoli pans (not supplied)
  • Static cooling
  • LED interior light with switch
  • Easy access understorage
  • Digital controller and temperature display
  • Rear night curtain to maintain temperature
  • Castors

Product description

13 scoop static cooled display with understorage

The Isabella range is a spacious ice cream scooping cabinet with 10 or 13 pan options. Its curved glass design creates an eye catching display to delight your customers, and the rear serving shelf helps with fast service. Built-in refrigerated under storage means you can easily restock the display with fresh ice cream when busy without leaving the cabinet. The cabinet comes with castors for easy mobility and an internal LED light showcases your gelato or ice cream in the perfect light.

Downloads

SPECIFICATION 39 facts · tap for all External W × D × H1647 x 906 x 1372 mmWidth1647 mmDepth906 mmGross / net weight223 / 192 kgGross weight223 kgVoltage / frequency220-240/50 V/Hz

Manufacturer documents2

Identity6

Brand ISAsite
GTIN / EAN 7025101321004site
Product code 20307site
Sub title Scoop Ice Cream Displaycatalogue
Type Ventilated Cooled Ice Cream Display Freezerscatalogue
Warranty 2 year parts & 1 year labour warranty. Exclusions apply (see terms and conditions) – addcatalogue

Size & weight10

Depth 906 mmsite
External (W×D×H) 1647 × 906 × 1372 mmcatalogue
External W × D × H 1647 x 906 x 1372 mmsite
Gross / net weight 223 / 192 kgsite
Gross weight 223 kgcatalogue
Height 1372 mmsite
Internal W × D × H mmsite
Packed (W×D×H) 1748 × 978 × 1450 mmcatalogue
Packed W × D × H 1748 x 978 x 1450 mmsite
Width 1647 mmsite

Capacity3

Display area 0.77 m²site
Serving capacity / 13 Napoli Pans (5L)site
Under-counter storage / 14 Napoli Pans (5L)site

Performance10

Climate class 4site
Controller Electronicsite
Cooling type Staticsite
Defrost type Automatic, hot gassite
Max ambient 30 °Ccatalogue
Maximum ambient +30°C, 55% RHsite
Refrigerant R290site
Refrigerant charge 135 / 45 gsite
Temperature range -16 to -14site
Thermometer Yessite

Power & energy5

Annual energy consumption 4322 kWh/yearsite
Energy consumption 11.84 kWh/24hsite
Input power 1240 Wsite
Noise level 57 dB(A)site
Voltage / frequency 220-240/50 V/Hzsite

Build & fittings2

Exterior finish Greysite
Interior light LEDsite

Other stated facts1

Energy class Ccatalogue
THE WORKING VIEW

Why this ventilated cooled ice cream display freezer earns its place

The ISABELLA 13LX is a scoop ice cream display that puts a 0.77 m² presentation area behind a curved front, sized for parlours and cafés running a fuller flavour line-up. The grey exterior and white interior give a clean serving face, keeping tubs on show and ready to scoop through service.

It holds a scooping band of -16 to -14 °C on static cooling, managed by an electronic controller with hot-gas automatic defrost, so the display clears frost without a manual routine. It draws 1240 W and is rated energy class C at 4321.6 kWh a year — about £1080 a year at 25p/kWh. Sound output is 57 dB and it carries a climate class 4 rating.

The external footprint is 1647 × 906 × 1372 mm (W×D×H), and it ships packed at 1748 × 978 × 1450 mm, so check the delivery route against the crated size. Net weight is 192 kg (223 kg gross), so it needs a firm level floor and equipment to position. It runs on a 220-240 V/50 Hz, 13 A supply and uses R290 refrigerant.

BEFORE YOU BUY

Questions, answered straight

The cabinet measures 1647 × 906 × 1372 mm (W×D×H) and ships crated at 1748 × 978 × 1450 mm. Check your access route against the packed size and plan for the 223 kg gross weight.

It runs a scooping band of -16 to -14 °C on static cooling, managed by an electronic controller. Defrost is automatic using hot gas, so there is no manual routine.

The display area is 0.77 m², sized for a fuller flavour range than a compact counter unit. It is finished in grey outside and white inside.

It is rated energy class C at 4321.6 kWh a year, which is about £1080 a year at 25p/kWh. It draws 1240 W and uses R290 refrigerant.

It runs on a standard 220-240 V/50 Hz single-phase supply and draws 13 A, so a normal socket circuit is enough. Sound output is 57 dB.

Yes. Our service team covers commercial refrigeration across the UK and can be reached on 01792 732702 to arrange maintenance or a callout.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

Dimensions

Internal Dimension (WxDxH): mm
External Dimension (WxDxH): 1647 x 906 x 1372 mm
Packed Dimension (WxDxH): 1748 x 978 x 1450 mm

Cooling and Functions

Type of Controller: Electronic
Type of Cooling: Static
Type of Defrost: Automatic, hot gas
Refrigerant: R290
Refrigerant Charge: 135 / 45 g
Thermometer: Yes

Power and Consumption

Energy Consumption: 11.84 kWh/24h
Temperature Range: -16 to -14 °C
Annual Energy Consumption: 4322 kWh/year m³
Input Power: 1240 W
Voltage / Frequency: 220-240/50 V/Hz
Noise Level: 57 dB(A)

Measures and Content

Temperature Range: -16 to -14 °C
Climate Class: 4
Gross / Net Weight: 223 / 192 kg
Gross / Net Volume: / l
Max Ambient: +30°C, 55% RH
Total Display Area: 0.77 m² m²

Design and Material

Serving Capacity: / 13 Napoli Pans (5L)
Storage capacity (under): / 14 Napoli Pans (5L)
Exterior Finish: Grey
Interior Finish: Grey
Interior Light: LED
If you have any questions about the ISA ISABELLA 13LX Scoop Ice Cream Display then please get in touch.
