CombiSteel Pizza Counter Double Door 9x 1/3GN Container 7489.5300

£4,428.00

+vat

SKU: 7489.53

Product summary

Size W/D/H (mm) 1790 x 850 x 1360

Product description

Temperatuur in de GN bakken is 0°C

The Pizza Counter 2 Doors is a refrigerated pizza prep station that combines two chilled door sections and a stainless worktop with a refrigerated topping rail for 1/3 GN containers, putting dough storage and topping assembly in one unit. Build pizzas and prepared dishes from a single line — 9 gastronorm pans of chilled toppings overhead and 460 litres of dough and stock below.

Downloads

SPECIFICATION 28 facts · tap for all Width1790 mmDepth850 mmHeight1360 mmGross / net weight237 kgVoltage / frequency23050Voltage230V / 50Hz

Identity3

Brand CombiSteelcatalogue
GTIN / EAN 7435137841852catalogue
Type Double Door Pizza Prep Counterscatalogue

Size & weight5

Depth 850 mmsite
External (W×D×H) 1790 × 850 × 1360 mmcatalogue
Gross / net weight 237 kgsite
Height 1360 mmsite
Width 1790 mmsite

Capacity4

Capacity 460 Ltrcatalogue
Gastronorm size 9X 1/3 GN PANcatalogue
Gross volume 460 litrescatalogue
Shelves 2catalogue

Performance6

Controller Digitalcatalogue
Cooling type R 290site
Defrost Automaticcatalogue
Max ambient 4343 °Ccatalogue
Maximum ambient 4343site
Temperature range -2/+8site

Power & energy6

Energy consumption 0.3site
Frequency 50 Hzcatalogue
Rated input 300 Wcatalogue
Rated power 0.3 kWcatalogue
Voltage 230V / 50Hzcatalogue
Voltage / frequency 23050site

Build & fittings3

Accessories Temperature in the GN containers is 0°Ccatalogue
Exterior finish Stainless steel Aisi 304site
Insulation 50 mmcatalogue

Other stated facts1

Mobility Nocatalogue
THE WORKING VIEW

Why this double door pizza prep counter earns its place

This is a two-door refrigerated pizza prep counter, built for the assembly line rather than display. Below the stainless-steel worktop, two hinged door sections hold dough, cheese and bulk stock at chilled temperature; along the back, a refrigerated topping rail carries 1/3 GN containers so toppings stay cold and to hand while a pizzaiolo builds. The whole unit holds 460 litres chilled, so a team has both the working surface and the backup stock in one footprint.

In service the topping rail keeps garnishes at chilled temperature through a long shift, the stainless top takes the stretching and dressing, and the door sections restock the rail from below. The unit runs at -2 to +8 °C and holds that temperature reliably with automatic defrost, so you don't fuss with the cabinet while the line builds. It is set up for continuous prep across a busy service.

This is a taller format than a plain counter because of the raised topping rail — at 1360 mm high, plan overhead clearance above the line, and the 1790 mm width fits most make-line runs. Leave space at the back for air circulation (850 mm depth), and line it up with your next station. The stainless-steel build and 50 mm insulation keep it durable through daily service and cleaning.

BEFORE YOU BUY

Questions, answered straight

The rail along the back holds 1/3 GN containers of prepared toppings at chilled temperature, so they stay cold and within reach while you build. The exact number and layout of pans is on the spec table.

The two hinged door sections give chilled under-counter storage for dough, cheese and bulk ingredients, restocking the topping rail from below. It keeps a full prep station in one body.

It is a floor-standing prep counter that lines up with a make line, but the raised topping rail makes it taller than a plain counter. Check the full dimensions on the spec table against your overhead clearance and gangway.

Both the topping rail and the storage below hold ingredients at -2 to +8 °C — chilled fridge temperature for service, not frozen. The unit manages that band automatically with no defrost fiddling, so toppings stay cold through the shift.

The stainless surfaces and removable GN containers lift out for cleaning between services and suit a standard commercial hygiene routine. Confirm the container configuration on the spec table.

Yes — for delivery, siting and servicing on a pizza prep counter, call our team on 01792 732702.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

CombiSteel Pizza Counter Double Door 9x 1/3GN Container 7489.5300 Product Data

Brand CombiSteel
Dimensions (W×D×H) 1790 × 850 × 1360 mm
Capacity 460 Ltr
GN Capacity 9X 1/3 GN PAN
Material Stainless steel Aisi 304
Temperature Range -2/+8
Max. Ambient Temp. 43
Refrigerant R 290
Cooling Ventilated
Defrost Automatic
Number of Doors 2
Number of Grids/Shelves 2
Electrical Power 0.3 kW
Voltage 230V / 50Hz
Mobile No
Lockable No
Insulation 50 mm
Weight 237 kg
If you have any questions about the CombiSteel Pizza Counter Double Door 9x 1/3GN Container 7489.5300 then please get in touch.
