CombiSteel 700 Series Refrigerated Counter 4 Door Energy Line 7489.5510

£1,968.00

+vat

Brand:

SKU: 7489.551

Product summary

Size W/D/H (mm) 2330 x 700 x 850

Product description

This Refrigerated Counter 4 Doors Energy Line is a four-door refrigerated prep counter that puts chilled storage and a stainless worktop in one back-bar unit, keeping ingredients to hand at the pass while doubling as a work surface.

Downloads

SPECIFICATION 28 facts · tap for all Width2330 mmDepth700 mmHeight850 mmGross / net weight205 kgVoltage / frequency23050Voltage230V / 50Hz

Identity4

Brand CombiSteelcatalogue
GTIN / EAN 7422242935965catalogue
Range / series Energy Linecatalogue
Type Four Door Counter Fridgescatalogue

Size & weight5

Depth 700 mmsite
External (W×D×H) 2330 × 700 × 850 mmcatalogue
Gross / net weight 205 kgsite
Height 850 mmsite
Width 2330 mmsite

Capacity5

Capacity 632 Ltrcatalogue
Doors 4catalogue
Gastronorm size 1/1catalogue
Gross volume 632 litrescatalogue
Shelves 2catalogue

Performance5

Cooling type R 290site
Defrost type Automaticsite
Max ambient 4343 °Ccatalogue
Maximum ambient 4343site
Temperature range -2/+8site

Power & energy7

Energy consumption 0,308site
Frequency 50 Hzcatalogue
Noise level 4040site
Rated input 308 Wcatalogue
Rated power 308 kWcatalogue
Voltage 230V / 50Hzcatalogue
Voltage / frequency 23050site

Build & fittings2

Exterior finish Stainless steel 430site
Insulation 50 mmcatalogue
THE WORKING VIEW

Why this four door counter fridge earns its place

This Refrigerated Counter 4 Doors is a four-door refrigerated prep counter from the Energy Line range in a 2330 mm footprint. It combines under-counter chilled storage holding 632 litres at -2 to +8 °C with a full-length stainless steel top, so a single unit gives you both a cold store for service stock and a worktop to prep and plate on.

In service it keeps four separate door sections of chilled stock directly under the worktop, so cooks reach down for ingredients instead of crossing the kitchen to a walk-in. Built from stainless steel 430 with 50 mm insulation, the counter format holds everything at working height and turns the top into usable prep and plating space. At 40 dB(A) it stays quiet through a busy shift.

It is a floor-standing counter 850 mm tall and 700 mm deep, built to sit along a back wall or bench line at 205 kg and run from a standard mains supply. Craven Cooling delivers and services the range nationwide — it is a long, heavy unit, so it is worth checking the wall run and your doorway access before it is brought in.

BEFORE YOU BUY

Questions, answered straight

A counter keeps 632 litres of chilled storage low and under a worktop, so it doubles as prep space and sits right in the service line. An upright gives more height but takes floor space and does not give you a surface to work on.

It is 2330 mm wide on the floor, so measure both the run of wall it needs and the access route in. Check doorway widths, corridors and any tight corners before delivery — it weighs 205 kg as one piece. Our team can advise on the route.

The four door sections give separate chilled compartments for service stock, prep and ingredients at -2 to +8 °C, kept under the worktop for quick access during service. Split the storage to match your section's menu.

Yes. The stainless steel top is designed to be worked on, so you can prep and plate straight on the counter while stock stays chilled underneath.

Craven Cooling supplies, delivers and services the range across the UK. If it needs attention, call 01792 732702 and we will sort a visit.

It is built for commercial kitchens, keeping four sections of stock cold at working height and within reach at the pass so cooks are not leaving the line during service. The quiet 40 dB(A) operation does not dominate the kitchen noise.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

CombiSteel 700 Series Refrigerated Counter 4 Door Energy Line 7489.5510 Product Data

Brand CombiSteel
Type Energy Line
Dimensions (W×D×H) 2330 × 700 × 850 mm
Capacity 632 Ltr
GN Capacity 1/1
Material Stainless steel 430
Temperature Range -2/+8
Max. Ambient Temp. 43
Refrigerant R 290
Cooling Ventilated
Defrost Automatic
Number of Doors 4
Number of Grids/Shelves 2
Electrical Power 0.308 kW
Voltage 230V / 50Hz
Noise Level 40 dB
Insulation 50 mm
Weight 205 kg
If you have any questions about the CombiSteel 700 Series Refrigerated Counter 4 Door Energy Line 7489.5510 then please get in touch.
