TEFCOLD UF400V Fan Assisted Upright Freezer

£1,063.00 £676.00

+vat

- +

Brand:

SKU: 33865

Energy Arrow

Product summary

  • Integrated handle
  • Electronic thermostat
  • Automatic defrost
  • Adjustable shelves
  • Ventilated cooling
  • Lock
  • Adjustable feet with rollers to rear

Product description

The UF-V range of storage freezers comes in various sizes. The freezer has an effective ventilated refrigeration system, which ensures an even temperature throughout the cabinet. Set the temperature on the easy-to-use digital thermostat display. You can customize the freezer to fit your needs with adjustable shelves. Defrost happens automatically.

Sale!
SPECIFICATION 46 facts · tap for all External W × D × H600 x 585 x 1855 mmWidth600 mmDepth585 mmGross / net weight85 / 80 kgGross weight85 kgVoltage / frequency220-240/50 V/Hz

Identity6

Brand TEFCOLDsite
GTIN / EAN 5708181994389site
Product code 33865site
Sub title Fan Assisted Upright Freezercatalogue
Type Single Door Commercial Upright Freezerscatalogue
Warranty 2 year parts & 1 year labour warranty. Exclusions apply (see terms and conditions) – addcatalogue

Size & weight11

Depth 585 mmsite
External (W×D×H) 600 × 585 × 1855 mmcatalogue
External W × D × H 600 x 585 x 1855 mmsite
Gross / net weight 85 / 80 kgsite
Gross weight 85 kgcatalogue
Height 1855 mmsite
Internal (W×D×H) 484 × 470 × 1620 mmcatalogue
Internal W × D × H 484 x 470 x 1620 mmsite
Packed (W×D×H) 690 × 650 × 2050 mmcatalogue
Packed W × D × H 690 x 650 x 2050 mmsite
Width 600 mmsite

Capacity2

Doors 1catalogue
Gross volume 400 litrescatalogue

Performance10

Climate class 4site
Controller Electronicsite
Cooling type Ventilatedsite
Defrost type Automaticsite
Max ambient 30 °Ccatalogue
Maximum ambient +30°C, 55% RHsite
Refrigerant R290site
Refrigerant charge 80 gsite
Temperature range -24 to -10site
Thermometer Yessite

Power & energy6

Annual energy consumption 2000 kWh/yearsite
Energy consumption 5.48 kWh/24hsite
Energy efficiency index 74.1 %site
Input power 300 Wsite
Noise level 40 dB(A)site
Voltage / frequency 220-240/50 V/Hzsite

Build & fittings6

Castors 2 rollerssite
Exterior finish Whitesite
Feet / legs 4 adjustable feetsite
Interior light Nosite
Max load per shelf 110site
Shelf dimensions 490 x 420 mmsite

Other stated facts1

Energy class Dcatalogue
THE WORKING VIEW

Why this single door commercial upright freezer earns its place

The Tefcold UF400V is a single-door upright commercial freezer built for back-of-house bulk frozen storage. It holds 400 litres gross, 340 litres net, across four white wire shelves — enough to keep a busy kitchen's frozen stock sorted and reachable rather than crammed into a chest. The single hinged solid door and upright format suit a tight service line where floor space is measured in inches.

It holds a frozen band of -24 to -10 °C under an electronic controller, so the set point stays put through service rather than drifting with door traffic. At 40 dB it is quiet enough to sit in or near a working area, and it carries a climate class 4 rating for use in a warm commercial kitchen. Energy class D, with an energy efficiency index of 74.1%.

The cabinet measures 600 × 585 × 1855 mm (W×D×H); at 600 mm wide it clears a standard doorway, and packed at 690 × 650 × 2050 mm it is worth measuring the delivery route and any low door heads before it arrives. It runs from a 220-240 V/50 supply on a 13 amp connection, so it plugs into a standard commercial socket without special wiring. Gross weight is 85 kg.

BEFORE YOU BUY

Questions, answered straight

400 litres gross and 340 litres net, arranged over four white wire shelves. The upright layout keeps stock sorted and reachable rather than buried at the bottom of a chest.

It holds a frozen band of -24 to -10 °C, managed by an electronic controller that keeps the set point steady through service.

The cabinet is 600 mm wide and 1855 mm tall, so it clears a standard doorway. Packed it measures 690 × 650 × 2050 mm, so check the delivery route and any low door heads first.

A standard 220-240 V/50 supply on a 13 amp connection. It plugs into a normal commercial socket with no special wiring.

It runs at 40 dB, quiet enough for a prep area, and sits at energy class D with an energy efficiency index of 74.1%.

Yes — Craven Cooling supports the equipment it sells. For servicing, spares or advice, call the team on 01792 732702.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

Dimensions

Internal Dimension (WxDxH): 484 x 470 x 1620 mm
External Dimension (WxDxH): 600 x 585 x 1855 mm
Packed Dimension (WxDxH): 690 x 650 x 2050 mm

Cooling and Functions

Type of Controller: Electronic
Type of Cooling: Ventilated
Type of Defrost: Automatic
Refrigerant: R290
Refrigerant Charge: 80 g
Thermometer: Yes

Power and Consumption

Energy Consumption: 5.48 kWh/24h
Temperature Range: -24 to -10 °C
Annual Energy Consumption: 2000 kWh/year m³
EEI: 74.1 %
Input Power: 300 W
Voltage / Frequency: 220-240/50 V/Hz
Noise Level: 40 dB(A)

Measures and Content

Temperature Range: -24 to -10 °C
Climate Class: 4
Gross / Net Weight: 85 / 80 kg
Gross / Net Volume: 400 / 340 l
Max Ambient: +30°C, 55% RH

Design and Material

Door Reversible: Yes
Shelf Color: White
Shelf Dimensions: 490 x 420 mm
Max load on Shelves: 110 kg/m²
Feet / Legs: 4 adjustable feet
Castors: 2 rollers
Exterior Finish: White
Interior Finish: White
Interior Light: No
Lock: Yes
If you have any questions about the TEFCOLD UF400V Fan Assisted Upright Freezer then please get in touch.
