TEFCOLD UF200VS Undercounter Freezer

£522.00

+vat

- +

Brand:

SKU: 33862

Energy Arrow

Product summary

  • Stainless steel cabinet
  • Integrated handle
  • Electronic thermostat
  • Automatic defrost
  • Adjustable shelves
  • Ventilated cooling
  • Lock

Product description

Undercounter fully automatic freezer with auto defrost

The UF-VS range of freezers is the ventilated version of our stainless steel storage freezers. It comes in various sizes. The freezer has an effective ventilated refrigeration system, which ensures an even temperature throughout the cabinet. Set the temperature on the easy-to-use digital thermostat display. You can customise the freezer to fit your needs with adjustable shelves. Defrost happens automatically.

SPECIFICATION 47 facts · tap for all External W × D × H600 x 585 x 855 mmWidth600 mmDepth585 mmGross / net weight52 / 47 kgGross weight52 kgVoltage / frequency220-240/50 V/Hz

Identity6

Brand TEFCOLDsite
GTIN / EAN 5708181994358site
Product code 33862site
Sub title Undercounter Freezercatalogue
Type Commercial Under Counter Freezerscatalogue
Warranty 2 year parts & 1 year labour warranty. Exclusions apply (see terms and conditions) – addcatalogue

Size & weight11

Depth 585 mmsite
External (W×D×H) 600 × 585 × 855 mmcatalogue
External W × D × H 600 x 585 x 855 mmsite
Gross / net weight 52 / 47 kgsite
Gross weight 52 kgcatalogue
Height 855 mmsite
Internal (W×D×H) 484 × 470 × 610 mmcatalogue
Internal W × D × H 484 x 470 x 610 mmsite
Packed (W×D×H) 690 × 650 × 910 mmcatalogue
Packed W × D × H 690 x 650 x 910 mmsite
Width 600 mmsite

Capacity3

Doors 1catalogue
Gross volume 200 litrescatalogue
Shelves 3catalogue

Performance10

Climate class 4site
Controller Electronicsite
Cooling type Ventilatedsite
Defrost type Automaticsite
Max ambient 30 °Ccatalogue
Maximum ambient +30°C, 55% RHsite
Refrigerant R290site
Refrigerant charge 45 gsite
Temperature range -24 to -10site
Thermometer Yessite

Power & energy6

Annual energy consumption 592 kWh/yearsite
Energy consumption 1.62 kWh/24hsite
Energy efficiency index 21.7 %site
Input power 180 Wsite
Noise level 42 dB(A)site
Voltage / frequency 220-240/50 V/Hzsite

Build & fittings6

Castors 2 rollerssite
Exterior finish SS430site
Feet / legs 4 adjustable feetsite
Interior light Nosite
Max load per shelf 110site
Shelf dimensions 490 x 380 mmsite

Other stated facts1

Energy class Acatalogue
THE WORKING VIEW

Why this commercial under counter freezer earns its place

The UF200VS is an undercounter freezer built to sit within a working line, putting frozen stock where the section actually needs it. With 200 litres gross and 120 litres net across three wire shelves behind one solid hinged door, it holds a service's frozen mise en place so nobody walks to a back-of-house freezer mid-service. The SS430 stainless exterior stands up to a commercial kitchen, and the white ABS interior wipes down clean.

It runs a static cooling system under electronic control, holding a -24 to -10 °C band suited to frozen storage. Rated energy class A and climate class 4, it is built to keep temperature in the warm, busy ambient of a commercial kitchen rather than a cool cellar. The three wire shelves let you organise stock by type and rotate it by date without unloading the whole cabinet.

At 600 × 600 × 850 mm (W×D×H) it is sized to slot under a standard commercial worktop, and it ships packed at 690 × 650 × 910 mm, so check that against doorways and lift access on the way in. It runs on a 13 A supply at 220–240 V/50 Hz, plugging into a normal commercial socket. Net weight is 47 kg, 52 kg packed.

BEFORE YOU BUY

Questions, answered straight

It runs at -24 to -10 °C under electronic control, a band suited to frozen storage. Static cooling and climate class 4 mean it holds that temperature in a warm, busy kitchen.

Its external size is 600 × 600 × 850 mm (W×D×H), designed to slot under a standard commercial worktop. It ships packed at 690 × 650 × 910 mm, so check doorways and access before delivery.

200 litres gross and 120 litres net, across three wire shelves behind a single solid hinged door. The shelves let you sort stock by type and rotate by date. Our capacity calculator helps you match litres to your menu.

It runs on a standard 13 A supply at 220–240 V/50 Hz, so it plugs into a normal commercial socket. No special electrical work is needed.

It is rated energy class A with electronic temperature control. To turn that energy label into a pounds-per-year figure on your own tariff, use our energy label decoder.

The white ABS interior and SS430 stainless exterior both wipe down as part of routine cleaning. For servicing or spares, Craven Cooling's team can help — call 01792 732702.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

Dimensions

Internal Dimension (WxDxH): 484 x 470 x 610 mm
External Dimension (WxDxH): 600 x 585 x 855 mm
Packed Dimension (WxDxH): 690 x 650 x 910 mm

Cooling and Functions

Type of Controller: Electronic
Type of Cooling: Ventilated
Type of Defrost: Automatic
Refrigerant: R290
Refrigerant Charge: 45 g
Thermometer: Yes

Power and Consumption

Energy Consumption: 1.62 kWh/24h
Temperature Range: -24 to -10 °C
Annual Energy Consumption: 592 kWh/year m³
EEI: 21.7 %
Input Power: 180 W
Voltage / Frequency: 220-240/50 V/Hz
Noise Level: 42 dB(A)

Measures and Content

Temperature Range: -24 to -10 °C
Climate Class: 4
Gross / Net Weight: 52 / 47 kg
Gross / Net Volume: 200 / 120 l
Max Ambient: +30°C, 55% RH

Design and Material

Door Reversible: Yes
Shelf Color: White
Shelf Dimensions: 490 x 380 mm
Max load on Shelves: 110 kg/m²
Feet / Legs: 4 adjustable feet
Castors: 2 rollers
Exterior Finish: SS430
Interior Finish: SS430
Interior Light: No
Lock: Yes
If you have any questions about the TEFCOLD UF200VS Undercounter Freezer then please get in touch.
