TEFCOLD FS80CP Counter Top Chiller

£393.00

+vat

- +

Brand:

SKU: 20001

Energy Arrow

Product summary

  • Fully automatic
  • Fan assisted cooling
  • Lock
  • Adjustable shelves
  • Adjustable feet
  • LED interior light with switch

Product description

A quality counter top display fridge with fan assisted cooling. This unit has an internal light and an illuminated light canopy that is ideal for branding with your logo for advertising to encourage sales. Great for display of bottles, cans or other chilled drinks.

SPECIFICATION 50 facts · tap for all External W × D × H480 x 460 x 840 mmWidth480 mmDepth460 mmGross / net weight43 / 38 kgGross weight43 kgVoltage / frequency220-240/50 V/Hz

Identity6

Brand TEFCOLDsite
GTIN / EAN 5708181002008site
Product code 20001site
Sub title Counter Top Chillercatalogue
Type Countertop Glass Door Fridgescatalogue
Warranty 2 year parts & 1 year labour warranty. Exclusions apply (see terms and conditions) – addcatalogue

Size & weight11

Depth 460 mmsite
External (W×D×H) 480 × 460 × 840 mmcatalogue
External W × D × H 480 x 460 x 840 mmsite
Gross / net weight 43 / 38 kgsite
Gross weight 43 kgcatalogue
Height 840 mmsite
Internal (W×D×H) 410 × 380 × 550 mmcatalogue
Internal W × D × H 410 x 380 x 550 mmsite
Packed (W×D×H) 580 × 600 × 960 mmcatalogue
Packed W × D × H 580 x 600 x 960 mmsite
Width 480 mmsite

Capacity6

330ml bottles 40 pcssite
330ml cans 60 pcssite
500ml cans 48 pcssite
Doors 1catalogue
Gross volume 84 litrescatalogue
Shelves 2catalogue

Performance10

Climate class 3site
Controller Mechanicalsite
Cooling type Fan assistedsite
Defrost type Automaticsite
Max ambient 25 °Ccatalogue
Maximum ambient +25°C, 60% RHsite
Refrigerant R600asite
Refrigerant charge 40 gsite
Temperature range +2 to +10site
Thermometer Yessite

Power & energy6

Annual energy consumption 402 kWh/yearsite
Energy consumption 1.1 kWh/24hsite
Energy efficiency index 41 %site
Input power 85 Wsite
Noise level 42 dB(A)site
Voltage / frequency 220-240/50 V/Hzsite

Build & fittings6

Canopy D-Shapesite
Exterior finish Whitesite
Feet / legs 4 adjustable feetsite
Interior light LEDsite
Max load per shelf 196site
Shelf dimensions 400 x 270 mmsite

Other stated facts1

Energy class Dcatalogue
THE WORKING VIEW

Why this countertop glass door fridge earns its place

The FS80CP is a countertop glass-door chiller built to drive impulse chilled sales in a small space. Behind a single hinged glass door it holds 55 litres net across two white wire shelves, in a white cabinet that sits on a counter or back bar to put drinks and grab-and-go lines at eye level.

It runs +2 to +10 °C under mechanical control, with automatic defrost and a heated, self-closing glass door that clears condensation and pulls itself shut after service. It runs on R600a with a 40 g charge, draws just 85 W and runs at 42 dB. Rated energy use is 401.5 kWh a year at energy class D — about £100 a year at 25p/kWh.

The cabinet measures 480 × 460 × 840 mm (W×D×H) and weighs 43 kg gross, small enough for a counter or back-bar shelf. It runs from a standard 13 amp, 220-240 V supply and is rated climate class 3. Gross volume is 84 litres against 55 litres net.

BEFORE YOU BUY

Questions, answered straight

External dimensions are 480 × 460 × 840 mm (W×D×H) and it weighs 43 kg gross, sized for a counter or back-bar shelf. Allow room above for the door to open.

It runs +2 to +10 °C under mechanical control with automatic defrost, suited to chilled drinks and grab-and-go food. The heated glass door clears condensation for a clear view.

Net volume is 55 litres across two white wire shelves, with a gross volume of 84 litres.

Rated energy use is 401.5 kWh a year, about £100 a year at 25p/kWh, at energy class D. It draws just 85 W.

Yes — it has a hinged, self-closing heated glass door that pulls shut after service and stays condensation-free.

It runs from a standard 13 amp, 220-240 V supply and is rated climate class 3. For servicing advice, call Craven Cooling on 01792 732702.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

Dimensions

Internal Dimension (WxDxH): 410 x 380 x 550 mm
External Dimension (WxDxH): 480 x 460 x 840 mm
Packed Dimension (WxDxH): 580 x 600 x 960 mm

Cooling and Functions

Type of Controller: Mechanical
Type of Cooling: Fan assisted
Type of Defrost: Automatic
Refrigerant: R600a
Refrigerant Charge: 40 g
Thermometer: Yes

Power and Consumption

Energy Consumption: 1.1 kWh/24h
Temperature Range: +2 to +10 °C
Annual Energy Consumption: 402 kWh/year m³
EEI: 41 %
Input Power: 85 W
Voltage / Frequency: 220-240/50 V/Hz
Noise Level: 42 dB(A)

Measures and Content

Cans 330 ml: 60 pcs pcs
Cans 500 ml: 48 pcs pcs
Bottles 330 ml: 40 pcs pcs
Temperature Range: +2 to +10 °C
Climate Class: 3
Gross / Net Weight: 43 / 38 kg
Gross / Net Volume: 84 / 55 l
Max Ambient: +25°C, 60% RH

Design and Material

Door Reversible: Yes
Shelf Color: White
Shelf Dimensions: 400 x 270 mm
Max load on Shelves: 196 kg/m²
Canopy Type: D-Shape
Feet / Legs: 4 adjustable feet
Exterior Finish: White
Interior Finish: White
Interior Light: LED
Lock: Yes
If you have any questions about the TEFCOLD FS80CP Counter Top Chiller then please get in touch.
