TEFCOLD BC25CP Counter Top Chiller

£317.00

+vat

Brand:

SKU: 32443

Energy Arrow

Product summary

  • Fully automatic
  • Fan assisted cooling
  • Lock
  • Adjustable shelves
  • Adjustable feet
  • LED Light canopy with switch
  • LED interior light with switch
  • Self-closing door

Product description

The BC25CP counter top chiller is ideal for the display of cooled drinks. Space is maximised in the cabinet by having a top mounted refrigeration unit meaning there is no internal step in the base of the cabinet. Internal LED lighting helps to showcase your produce, while the LED light canopy is ideal for branding. Great to encourage impulse purchase near till points and is popular for drinks companies to promote their brands.

The TEFCOLD BC25CP is a countertop glass-door chiller holding 22 litres net on two wire shelves, running +2 to +10 °C on R600a with automatic defrost, rated energy class B at 173.7 kWh a year and drawing 75 W from a standard 13 A supply.

SPECIFICATION 46 facts · tap for all External W × D × H332 x 423 x 618 mmWidth332 mmDepth423 mmGross / net weight24 / 19 kgGross weight24 kgVoltage / frequency220-240/50 V/Hz

Identity6

Brand TEFCOLDsite
GTIN / EAN 5708181992514site
Product code 32443site
Sub title Counter Top Chillercatalogue
Type Countertop Glass Door Fridgescatalogue
Warranty 2 year parts & 1 year labour warranty. Exclusions apply (see terms and conditions) – addcatalogue

Size & weight11

Depth 423 mmsite
External (W×D×H) 332 × 423 × 618 mmcatalogue
External W × D × H 332 x 423 x 618 mmsite
Gross / net weight 24 / 19 kgsite
Gross weight 24 kgcatalogue
Height 618 mmsite
Internal (W×D×H) 258 × 270 × 373 mmcatalogue
Internal W × D × H 258 x 270 x 373 mmsite
Packed (W×D×H) 380 × 470 × 640 mmcatalogue
Packed W × D × H 380 x 470 x 640 mmsite
Width 332 mmsite

Capacity4

Display area 0.092 m²site
Doors 1catalogue
Gross volume 25 litrescatalogue
Shelves 2catalogue

Performance8

Climate class 4site
Controller Mechanicalsite
Cooling type Fan assistedsite
Defrost type Automaticsite
Refrigerant R600asite
Refrigerant charge 20 gsite
Temperature range +2 to +10site
Thermometer Nosite

Power & energy6

Annual energy consumption 174 kWh/yearsite
Energy consumption 0.476 kWh/24hsite
Energy efficiency index 19 %site
Input power 75 Wsite
Noise level 44 dB(A)site
Voltage / frequency 220-240/50 V/Hzsite

Build & fittings6

Exterior finish Blacksite
Feet / legs 4 adjustable feetsite
Interior light LEDsite
Lock Yessite
Max load per shelf 196site
Shelf dimensions 250 x 250 mmsite

Other stated facts1

Energy class Bcatalogue
THE WORKING VIEW

Why this countertop glass door fridge earns its place

The TEFCOLD BC25CP is an ultra-compact counter-top chiller with a single hinged, self-closing glass door, built to put chilled stock at eye level where impulse decisions are made. It offers 25 litres gross and 22 litres net across two black wire shelves, inside a black cabinet with a grey coated-aluminium interior. On a till counter or service point it merchandises drinks, snacks or prepared items without taking floor space.

The chiller holds +2 to +10 °C with automatic defrost and a simple mechanical controller. Its energy class B rating at 173.7 kWh a year works out at about £43 a year at 25p/kWh, and it runs at 44 dB — unobtrusive on a front-of-house counter. It is rated climate class 4 for warm, busy rooms.

The cabinet measures 332 × 423 × 618 mm (W×D×H) externally, a footprint narrow enough for most counters, with a 258 × 270 × 373 mm interior. It weighs 24 kg gross, plugs into a standard 13 A / 220–240 V supply drawing 75 W, and cools with R600a hydrocarbon refrigerant on a 20 g charge.

BEFORE YOU BUY

Questions, answered straight

It holds +2 to +10 °C, with automatic defrost and a mechanical controller. That suits chilled drinks, snacks and prepared items.

It is rated energy class B at 173.7 kWh a year, about £43 a year at 25p/kWh, drawing 75 W.

It measures 332 × 423 × 618 mm (W×D×H) externally with a 258 × 270 × 373 mm interior, and weighs 24 kg gross.

25 litres gross and 22 litres net, on two black wire shelves behind one self-closing glass door.

R600a hydrocarbon refrigerant on a 20 g charge, from a standard 13 A / 220–240 V supply.

Yes — it runs at 44 dB and is rated climate class 4 for warm rooms. For servicing or spares call Craven Cooling on 01792 732702.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

Dimensions

Internal Dimension (WxDxH): 258 x 270 x 373 mm
External Dimension (WxDxH): 332 x 423 x 618 mm
Packed Dimension (WxDxH): 380 x 470 x 640 mm

Cooling and Functions

Type of Controller: Mechanical
Type of Cooling: Fan assisted
Type of Defrost: Automatic
Refrigerant: R600a
Refrigerant Charge: 20 g
Thermometer: No

Power and Consumption

Energy Consumption: 0.476 kWh/24h
Temperature Range: +2 to +10 °C
Annual Energy Consumption: 174 kWh/year m³
EEI: 19 %
Input Power: 75 W
Voltage / Frequency: 220-240/50 V/Hz
Noise Level: 44 dB(A)

Measures and Content

Temperature Range: +2 to +10 °C
Climate Class: 4
Gross / Net Weight: 24 / 19 kg
Gross / Net Volume: 25 / 22 l
Total Display Area: 0.092 m² m²

Design and Material

Door Reversible: No
Shelf Color: Black
Shelf Dimensions: 250 x 250 mm
Max load on Shelves: 196 kg/m²
Feet / Legs: 4 adjustable feet
Exterior Finish: Black
Interior Finish: Black
Interior Light: LED
Lock: Yes
If you have any questions about the TEFCOLD BC25CP Counter Top Chiller then please get in touch.
