TEFCOLD EVO1502 SS Patisserie Display Cabinet

£3,937.00 £2,639.00

+vat

Brand:

SKU: 38306

Energy Arrow

Product summary

  • Fully automatic
  • Fan assisted cooling
  • Adjustable feet
  • Interior light with switch
  • Digital controller and temperature display
  • Hinged glass for easy cleaning
  • Individually illuminated glass shelves
  • Glass rear sliding doors

Product description

The stainless steel units of the EVO range feature 4-tier patisserie display cabinets designed to beautifully showcase cakes and desserts. These cabinets boast individually illuminated glass shelves to enhance presentation. Fully automated fan-assisted cooling guarantees consistent cooling throughout the cabinet. Adjustable feet ensure stability, and the curved front glass hinges forward for easy cleaning. The pre-built glass design allows quick installation. An interior light with a switch offers optimal illumination, and the digital controller with a temperature display ensures precise control.

The TEFCOLD EVO1502 SS is a stainless steel curved-glass patisserie display cabinet holding +1 to +10 °C across 2.05 m² of display on three glass shelves behind two sliding glass doors, running on a standard 13 amp supply.

Sale!

Downloads

SPECIFICATION 40 facts · tap for all External W × D × H1500 x 755 x 1400 mmWidth1500 mmDepth755 mmGross / net weight197 / 170 kgGross weight197 kgVoltage / frequency220-240/50 V/Hz

Manufacturer documents2

Identity6

Brand TEFCOLDsite
GTIN / EAN 5708181999810site
Product code 38306site
Sub title Patisserie Display Cabinetcatalogue
Type Curved Glass Cake Display Fridgescatalogue
Warranty 2 year parts & 1 year labour warranty. Exclusions apply (see terms and conditions) – addcatalogue

Size & weight11

Depth 755 mmsite
External (W×D×H) 1500 × 755 × 1400 mmcatalogue
External W × D × H 1500 x 755 x 1400 mmsite
Gross / net weight 197 / 170 kgsite
Gross weight 197 kgcatalogue
Height 1400 mmsite
Internal (W×D×H) 1455 × 502 × 790 mmcatalogue
Internal W × D × H 1455 x 502 x 790 mmsite
Packed (W×D×H) 1600 × 840 × 1580 mmcatalogue
Packed W × D × H 1600 x 840 x 1580 mmsite
Width 1500 mmsite

Capacity3

Display area 2.05 m²site
Doors 2catalogue
Gross volume 740 litrescatalogue

Performance9

Climate class 3site
Controller Electronicsite
Defrost type Automaticsite
Max ambient 25 °Ccatalogue
Maximum ambient +25°C, 60% RHsite
Refrigerant R290site
Refrigerant charge 145 gsite
Temperature range +1 to +10site
Thermometer Yessite

Power & energy6

Annual energy consumption 4163 kWh/yearsite
Energy consumption 11.4 kWh/24hsite
Energy efficiency index 51.2 %site
Input power 750 Wsite
Noise level 44 dB(A)site
Voltage / frequency 220-240/50 V/Hzsite

Build & fittings2

Exterior finish Stainless steelsite
Interior light LEDsite

Other stated facts1

Energy class Ecatalogue
THE WORKING VIEW

Why this curved glass cake display fridge earns its place

The EVO1502 SS is the stainless steel version of TEFCOLD's curved-glass patisserie display cabinet, built to merchandise cakes and pastries behind a panoramic glass front. Both the exterior and interior are stainless steel, giving a hard-wearing, wipe-clean finish that suits busy production and front-of-house environments. 2.05 m² of display area is arranged over three glass shelves plus the base.

It holds a +1 to +10 °C chilled band under an electronic controller, with automatic defrost clearing ice without staff input. Cooling runs on R290 refrigerant with a 145 g charge, and the cabinet is rated climate class 3 at a low 44 dB. At energy class E and 4161 kWh a year, running cost is about £1040 a year at 25p/kWh.

Internally the display measures 1455 × 502 × 790 mm (W×D×H) across the three shelves. The cabinet weighs 197 kg gross and connects to a standard 13 amp supply, so no special electrics are required. Two sliding glass doors give staff access from the serving side.

BEFORE YOU BUY

Questions, answered straight

Both the exterior and interior are stainless steel, giving a durable, wipe-clean surface for busy food environments.

It runs a chilled +1 to +10 °C band under an electronic controller, suited to patisserie and deli display rather than deep storage.

At energy class E and 4161 kWh a year, running cost is about £1040 a year at 25p/kWh, before your tariff and door usage are factored in.

There's 2.05 m² of display area over three glass shelves plus the base, with an internal display footprint of 1455 × 502 × 790 mm.

No. It runs from a standard 13 amp supply. It weighs 197 kg gross, so plan the delivery route and final position accordingly.

It uses R290 refrigerant with a 145 g charge and automatic defrost. For servicing or to confirm external dimensions ahead of delivery, call Craven Cooling on 01792 732702.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

Dimensions

Internal Dimension (WxDxH): 1455 x 502 x 790 mm
External Dimension (WxDxH): 1500 x 755 x 1400 mm
Packed Dimension (WxDxH): 1600 x 840 x 1580 mm

Cooling and Functions

Type of Controller: Electronic
Type of Defrost: Automatic
Refrigerant: R290
Refrigerant Charge: 145 g
Thermometer: Yes

Power and Consumption

Energy Consumption: 11.4 kWh/24h
Temperature Range: +1 to +10 °C
Annual Energy Consumption: 4163 kWh/year m³
EEI: 51.2 %
Input Power: 750 W
Voltage / Frequency: 220-240/50 V/Hz
Noise Level: 44 dB(A)

Measures and Content

Temperature Range: +1 to +10 °C
Climate Class: 3
Gross / Net Weight: 197 / 170 kg
Gross / Net Volume: 740 / l
Max Ambient: +25°C, 60% RH
Total Display Area: 2.05 m² m²

Design and Material

Exterior Finish: Stainless steel
Interior Finish: Stainless steel
Interior Light: LED
If you have any questions about the TEFCOLD EVO1502 SS Patisserie Display Cabinet then please get in touch.
