TEFCOLD EVO1202 SS Patisserie Display Cabinet

£3,640.00 £2,405.00

+vat

Brand:

SKU: 38298

Energy Arrow

Product summary

  • Fully automatic
  • Fan assisted cooling
  • Adjustable feet
  • Interior light with switch
  • Digital controller and temperature display
  • Hinged glass for easy cleaning
  • Individually illuminated glass shelves
  • Glass rear sliding doors

Product description

The stainless steel units of the EVO range feature 4-tier patisserie display cabinets designed to beautifully showcase cakes and desserts. These cabinets boast individually illuminated glass shelves to enhance presentation and rear sliding doors for effortless serving. Fully automated fan-assisted cooling guarantees consistent cooling throughout the cabinet. Adjustable feet ensure stability, and the curved front glass hinges forward for easy cleaning. The pre-built glass design allows quick installation. An interior light with a switch offers optimal illumination, and the digital controller with a temperature display ensures precise control.

The TEFCOLD EVO1202 SS is a stainless steel patisserie display cabinet with 1.62 m² of display over 3 glass shelves plus a base, served behind 2 sliding glass doors, holding +1 to +10 °C on R290 refrigerant with automatic defrost and rated energy class D.

Sale!

Downloads

SPECIFICATION 40 facts · tap for all External W × D × H1200 x 755 x 1400 mmWidth1200 mmDepth755 mmGross / net weight180 / 155 kgGross weight180 kgVoltage / frequency220-240/50 V/Hz

Manufacturer documents2

Identity6

Brand TEFCOLDsite
GTIN / EAN 5708181999773site
Product code 38298site
Sub title Patisserie Display Cabinetcatalogue
Type Curved Glass Cake Display Fridgescatalogue
Warranty 2 year parts & 1 year labour warranty. Exclusions apply (see terms and conditions) – addcatalogue

Size & weight11

Depth 755 mmsite
External (W×D×H) 1200 × 755 × 1400 mmcatalogue
External W × D × H 1200 x 755 x 1400 mmsite
Gross / net weight 180 / 155 kgsite
Gross weight 180 kgcatalogue
Height 1400 mmsite
Internal (W×D×H) 1155 × 502 × 790 mmcatalogue
Internal W × D × H 1155 x 502 x 790 mmsite
Packed (W×D×H) 1300 × 840 × 1580 mmcatalogue
Packed W × D × H 1300 x 840 x 1580 mmsite
Width 1200 mmsite

Capacity3

Display area 1.62 m²site
Doors 2catalogue
Gross volume 440 litrescatalogue

Performance9

Climate class 3site
Controller Electronicsite
Defrost type Automaticsite
Max ambient 25 °Ccatalogue
Maximum ambient +25°C, 60% RHsite
Refrigerant R290site
Refrigerant charge 140 gsite
Temperature range +1 to +10site
Thermometer Yessite

Power & energy6

Annual energy consumption 2915 kWh/yearsite
Energy consumption 7.99 kWh/24hsite
Energy efficiency index 36.6 %site
Input power 475 Wsite
Noise level 44 dB(A)site
Voltage / frequency 220-240/50 V/Hzsite

Build & fittings2

Exterior finish Stainless steelsite
Interior light LEDsite

Other stated facts1

Energy class Dcatalogue
THE WORKING VIEW

Why this curved glass cake display fridge earns its place

The TEFCOLD EVO1202 SS is a refrigerated patisserie display cabinet in stainless steel, built to present cakes, desserts and cold patisserie at eye level. It offers 1.62 m² of display area over 3 glass shelves plus a base, with 2 sliding glass doors on the serving side for stock access.

It holds a chilled band from +1 to +10 °C, controlled electronically with automatic defrost. The cabinet sits in climate class 3, runs at 44 dB, and carries an energy class D rating of 2916.3 kWh a year — about £729 a year at 25p/kWh, reflecting the large glazed display area. Cooling uses natural R290 refrigerant with a 140 g charge.

Inside, the display space measures 1155 × 502 × 790 mm (W×D×H) and the cabinet weighs 180 kg gross, so a firm, level floor and mechanical handling are worth planning for. It runs from a standard 13 A supply, drawing 475 W.

BEFORE YOU BUY

Questions, answered straight

It provides 1.62 m² of display area across 3 glass shelves plus a base. The interior measures 1155 × 502 × 790 mm (W×D×H).

It runs a chilled band from +1 to +10 °C under electronic control, suited to cakes, desserts and cold patisserie. Defrost is automatic.

It is rated energy class D at 2916.3 kWh a year, which is about £729 a year at 25p/kWh. The large glazed display area drives that figure, so factor it into your running costs.

It runs from a standard 13 A supply and draws 475 W, so a normal socket is enough.

It uses natural R290 with a 140 g charge, paired with automatic defrost so there is no manual defrosting to schedule.

Yes. Craven Cooling covers servicing and breakdowns on commercial refrigeration — call 01792 732702 to arrange a visit or talk through a fault.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

Dimensions

Internal Dimension (WxDxH): 1155 x 502 x 790 mm
External Dimension (WxDxH): 1200 x 755 x 1400 mm
Packed Dimension (WxDxH): 1300 x 840 x 1580 mm

Cooling and Functions

Type of Controller: Electronic
Type of Defrost: Automatic
Refrigerant: R290
Refrigerant Charge: 140 g
Thermometer: Yes

Power and Consumption

Energy Consumption: 7.99 kWh/24h
Temperature Range: +1 to +10 °C
Annual Energy Consumption: 2915 kWh/year m³
EEI: 36.6 %
Input Power: 475 W
Voltage / Frequency: 220-240/50 V/Hz
Noise Level: 44 dB(A)

Measures and Content

Temperature Range: +1 to +10 °C
Climate Class: 3
Gross / Net Weight: 180 / 155 kg
Gross / Net Volume: 440 / l
Max Ambient: +25°C, 60% RH
Total Display Area: 1.62 m² m²

Design and Material

Exterior Finish: Stainless steel
Interior Finish: Stainless steel
Interior Light: LED
If you have any questions about the TEFCOLD EVO1202 SS Patisserie Display Cabinet then please get in touch.
