CombiSteel Refrigerated Buffet GN 4/1 7077.0105

£1,959.09

+vat

- +

SKU: 7077.0105

Product summary

Size W/D/H (mm) x x

Product description

Dimensions glass shelf 1360x250mm

The Combisteel Refrigerated Buffet GN 4/1 is a chilled buffet display unit sized to hold four 1/1 gastronorm pans, keeping self-service food cold and presented at the counter.

Downloads

SPECIFICATION 22 facts · tap for all Width1400 mmDepth800 mmHeight850 mmGross / net weight230 kgVoltage / frequency23050Voltage230V / 50Hz

Identity3

Brand CombiSteelcatalogue
GTIN / EAN 6017429634659catalogue
Type Buffet Barcatalogue

Size & weight5

Depth 800 mmsite
External (W×D×H) 1400 × 800 × 850 mmcatalogue
Gross / net weight 230 kgsite
Height 850 mmsite
Width 1400 mmsite

Capacity2

Gastronorm size 4x 1/1 GNcatalogue
Shelves 1catalogue

Performance3

Cooling type R 290site
Defrost type Automaticsite
Temperature range 0/+10site

Power & energy6

Energy consumption 0,507site
Frequency 50 Hzcatalogue
Rated input 507 Wcatalogue
Rated power 507 kWcatalogue
Voltage 230V / 50Hzcatalogue
Voltage / frequency 23050site

Build & fittings3

Accessories Dimensions glass shelf 1360x250mmcatalogue
Colour Browncatalogue
Interior light Yes, LEDsite
THE WORKING VIEW

Why this buffet bar earns its place

The Combisteel Refrigerated Buffet GN 4/1 is a chilled buffet display built around gastronorm sizing — the well takes a GN 4/1 layout, so it drops straight into a kitchen already running standard 1/1 pans. It is the format for self-service and assisted-service food that has to stay cold on show: a breakfast spread, a salad and cold-starter line, a grab-and-chill counter. The counter measures 1400 mm wide by 800 mm deep, so it reads as a solid presence on a servery line without dominating the space.

In service the refrigerated well holds the pans of prepped food at +0 to +10 °C through the session, so front-of-house can top up and rotate without carrying stock back and forth from a fridge. The unit uses R290 refrigerant with automatic defrost and static cooling — no fans running, so it stays quiet in a customer-facing setting. LED interior lighting keeps the food lit for presentation. Because it works to gastronorm, pans lift straight in and out for a swap or a clean-down, which keeps a self-service line moving at the busy stretch.

It is a freestanding buffet unit that weighs 230 kg and connects to a standard 230V mains supply, so it can anchor a fixed servery or move to where the service is that day. Plan a level surface and a clear delivery route, and keep the airflow around the unit clear so it holds temperature under a warm room. Craven Cooling can advise on siting and supply before you buy.

BEFORE YOU BUY

Questions, answered straight

It refers to gastronorm sizing — the well is laid out to hold a GN 4/1 arrangement of standard 1/1 pans. If your kitchen already works to gastronorm, the pans lift straight in and out.

It is a refrigerated buffet unit that keeps prepped food cold and on display at a counter, for self-service or assisted-service lines such as breakfast, salads and cold starters.

Yes. Because it works to gastronorm, pans lift in and out for a top-up, a rotation or a clean-down, which keeps a self-service line moving at the busy stretch.

Yes. It stands at the counter and connects to a standard mains supply, so it can anchor a fixed servery or move to wherever the service is. Plan a level surface and a clear delivery route.

Keep the airflow around the unit clear so it can shed heat, and don't overfill the well past the pan line. The unit holds +0 to +10 °C with automatic defrost, so a well-ventilated position helps it stay in range through service.

Yes. Craven Cooling can advise on servicing and support — call the team on 01792 732702.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

CombiSteel Refrigerated Buffet GN 4/1 7077.0105 Product Data

Brand CombiSteel
Dimensions (W×D×H) 1400 × 800 × 850 mm
GN Capacity 4x 1/1 GN
Colour / Finish Brown
Temperature Range 0/+10
Refrigerant R 290
Cooling Static
Defrost Automatic
Number of Grids/Shelves 1 per deur
Electrical Power 0.507 kW
Voltage 230V / 50Hz
Weight 230 kg
If you have any questions about the CombiSteel Refrigerated Buffet GN 4/1 7077.0105 then please get in touch.
