Hoshizaki Air-Cooled Ball Ice Maker 26kg/24hr R134a IM-65NE-Q DS547

£5,107.95

+vat

Availability: 999 in stock

- +

Brand:

SKU: DS547

Product summary

Ball Ice. 26kg/24hr Output. Bin Capacity: 17kg

Product description

The IM-65NE-Q (air cooled) is one of our unique special ice type (ball ice) ice makers tailored for the mixologists and cocktail bars that like to differentiate themselves and add to the full cocktail experience with the uniqueness of ice shapes without eliminating the purpose of properly cooling the drink with minimal dilution.

Efficient ice making process due to Hoshizaki’s unique FM auger system. Utilises all water brought into the machine – water consumption is equal to ice production
Stainless steel exterior with integrated door handle provides a hygienic easy-clean finish
Can produce up to 26kg of ice within 24 hours
Automatic flush system to reduce sediment build-up
Closed water circuit offers contamination protection by reducing the number of points at which impurities can enter the ice making process
Removable bin door gasket
Stainless steel with injected polyurethane foam for rigidity and insulation
Built-in water filter
Double hardened stainless steel auger. Combined with carbon bearings, they work optimally in a tough and wet environment which extends product life and reduces maintenance costs
Electronically controlled to ensure an optimised ice making process under varying circumstances without the need for physical adjustments. Quality of ice is always consistent
Easily cleanable air filter allows end users to carry routine cleaning schedules. Extends product life expectancy and reduces the frequency and costs of maintenance call-outs

Downloads

SPECIFICATION 24 facts · tap for all Width633 mmDepth506 mmHeight930 mmGross weight66 kgVoltage220-240VTemperature range+5 to +35 °C

Identity5

Brand Hoshizakisite
Product code DS547site
Seo name Hoshizaki Ice Maker IM65NEQcatalogue
Type Ice Machinescatalogue
Warranty 2 Years Parts & Labourcatalogue

Size & weight5

Depth 506 mmcatalogue
External (W×D×H) 930 × 633 × 506 mmcatalogue
Gross weight 66 kgcatalogue
Height 930 mmcatalogue
Width 633 mmsite

Capacity4

Capacity 17kgcatalogue
Door type Hingedcatalogue
Doors 1catalogue
Product capacity 17catalogue

Performance3

Cooling Aircatalogue
Refrigerant R134acatalogue
Temperature range +5 to +35 °Ccatalogue

Power & energy3

Fuel type Plugcatalogue
Rated input 390 Wcatalogue
Voltage 220-240Vcatalogue

Build & fittings2

Colour Silvercatalogue
Material Stainless Steelcatalogue

Other stated facts2

Mobility Feetcatalogue
Plug notice Yescatalogue
THE WORKING VIEW

Why this ice machine earns its place

The Hoshizaki IM-65NE-Q DS547 is a commercial ball ice maker for sites that need a dedicated ice source for drinks service. It sits in the Ice Cube Machines category and is best read as production equipment rather than a loose ice bin or storage accessory.

The listing identifies this model as air-cooled and fitted with a hinged door, with an internal storage capacity listed as 17kg. That gives operators a self-contained ice-making unit for service areas where consistent access to shaped ice matters.

Use the DS547 where ball ice is part of the serve and a fixed ice machine can be planned into the bar or kitchen layout. Check water supply, drainage, ventilation and service access before ordering, and confirm final installation details against current manufacturer information.

BEFORE YOU BUY

Questions, answered straight

It is listed as a Hoshizaki air-cooled ball ice maker. It sits in the Ice Cube Machines category.

It is an ice maker. The product name identifies it as a Hoshizaki IM-65NE-Q ice maker rather than a storage-only bin.

It is most relevant to drinks service areas. Bars, restaurants, hotels and cold-drinks counters are the natural fit for an ice cube machine.

Check the planned water supply, drainage, ventilation and service access. Final requirements should be confirmed against the current manufacturer information before ordering.

Yes. Call 01792 732702 to discuss the ice machine, expected service pattern and any supporting storage or filtration needed.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

Hoshizaki Air-Cooled Ball Ice Maker 26kg/24hr R134a IM-65NE-Q DS547 Product Data

Brand Hoshizaki
Type Ice Machines
Dimensions 930(H) x 633(W) x 506(D)mm
Capacity 17kg
Material Stainless Steel
Colour / Finish Silver
Temperature Range 5°C to 35°C
Refrigerant R134a
Cooling Air
Number of Doors 1
Power 390 W
Voltage 220-240V
Fuel / Supply Plug
Warranty 2 Years Parts & Labour
Weight 66kg
Manufacturer Ref IM-65NE-Q
If you have any questions about the Hoshizaki Air-Cooled Ball Ice Maker 26kg/24hr R134a IM-65NE-Q DS547 then please get in touch.
