SIMAG 63kg Self-contained Ice Maker SDH64

£1,512.70

+vat

Brand:

SKU: SDH64

Product summary

Size: 485 x 575 x 905

Product description

  • High grade 441 stainless steel bodywork – scotch brite
  • Air cooled water cooled available POA
  • Vertical pump
  • Main switch onoff
  • Built in cleaning system
  • Easily accessible components
  • Low power and water consumption
  • Optimum ratio between ice production and bin capacity
  • Makes hollow, thimble shaped cubes

The SIMAG SDH64 is a self-contained ice maker for hollow thimble-shaped cubes, with a 485 x 575 x 905 mm footprint and R290 refrigerant.

Downloads

SPECIFICATION 15 facts · tap for all External W × D × H485 x 575 x 905Width485 mmDepth575 mmHeight905 mmGross weight48 kgVoltage / frequency580W

Manufacturer documents1

Identity3

Brand SIMAGsite
Product code SDH64site
Type Ice Cube Machinescatalogue

Size & weight6

Depth 575 mmsite
External (W×D×H) 485 × 575 × 905 mmcatalogue
External W × D × H 485 x 575 x 905site
Gross weight 48 kgcatalogue
Height 905 mmsite
Width 485 mmsite

Performance1

Refrigerant R290site

Power & energy3

Input power 13amp supplysite
Rated input 580 Wcatalogue
Voltage / frequency 580Wsite

Build & fittings1

Exterior finish Stainless Steelsite
THE WORKING VIEW

Why this ice cube machine earns its place

The SIMAG SDH64 sits in the upper end of the brand's self-contained hollow-cube range, giving bars, hotels and busy service counters a machine built around steady ice production and simple daily use. It makes hollow, thimble-shaped cubes: a familiar service cube for cold drinks where good displacement, quick chilling and easy scooping all matter.

This model is designed as a compact commercial unit rather than a remote-bin system. The 485 x 575 x 905 mm footprint keeps it manageable for back-bar or back-of-house siting, while the manufacturer notes an optimum ratio between ice production and bin capacity so the machine is matched for real service use, not just headline output.

SIMAG's build details are service-minded. The bodywork is high grade 441 stainless steel with a scotch brite finish, components are easily accessible, and a built-in cleaning system helps keep routine care straightforward. A vertical pump, main on/off switch and air-cooled operation are all part of the standard working package.

BEFORE YOU BUY

Questions, answered straight

It makes hollow, thimble-shaped cubes, which are widely used for drinks service.

Size it against your covers, peak drinks service and storage needs; Craven can help match the machine to the site before ordering.

The SDH64 measures 485 x 575 x 905 mm (W x D x H).

Yes. The manufacturer lists it as air cooled, with a water-cooled option available by enquiry.

Yes. SIMAG lists a built-in cleaning system and easily accessible components.

The verified refrigerant for this model is R290.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

Dimensions

External Dimension (WxDxH): 485 x 575 x 905

Cooling and Functions

Refrigerant: R290

Power and Consumption

Input Power: 13amp supply
Voltage / Frequency: 580W

Measures and Content

Design and Material

Exterior Finish: Stainless Steel

SIMAG 63kg Self-contained Ice Maker SDH64 Product Data

If you have any questions about the SIMAG 63kg Self-contained Ice Maker SDH64 then please get in touch.
