CombiSteel 700 Series Refrigerated Counter Single Door and 4 Drawers with Adjustable Feet 7950.5175

+vat

Brand:

SKU: 7950.5175

Product summary

Size W/D/H (mm) x x

Product description

Downloads

SPECIFICATION 31 facts · tap for all External W × D × H1795 x 700 x 850Width1795 mmDepth700 mmHeight850 mmGross / net weight140 kgVoltage / frequency230 volts / hz

Identity4

Brand CombiSteelcatalogue
GTIN / EAN 6017429959905site
Product code 7950.5175site
Type Triple Door Counter Fridgescatalogue

Size & weight8

Depth 700 mmsite
External (W×D×H) 1795 × 700 × 850 mmcatalogue
External W × D × H 1795 x 700 x 850site
Gross / net weight 140 kgsite
Height 850 mmsite
Internal (W×D×H) 1234 × 580 × 564 mmcatalogue
Internal W × D × H 1234x580x564site
Width 1795 mmsite

Capacity3

Capacity 417 Ltrcatalogue
Gastronorm size 1x 1/1catalogue
Gross volume 417 litrescatalogue

Performance6

Controller Digitalcatalogue
Cooling Ventilatedcatalogue
Defrost Automaticcatalogue
Max ambient 43 °Ccatalogue
Refrigerant R 290catalogue
Temperature range 43site

Power & energy4

Rated input 230 Wcatalogue
Rated power 0.23 kWcatalogue
Voltage 230Vcatalogue
Voltage / frequency 230 volts / hzsite

Build & fittings4

Doors 1site
Exterior finish Stainless steel 18/8site
Insulation 60 mmcatalogue
Interior finish Stainless steel 201site

Other stated facts2

Energy consumption 728 kWh/yearcatalogue
Mobility Nocatalogue
THE WORKING VIEW

Why this triple door counter fridge earns its place

The Combisteel 7950.5175 is a refrigerated prep counter built 1795 mm wide and 850 mm tall, sitting 700 mm deep — dimensions that let it fit most kitchen runs without needing a custom worktop. It puts 417 litres of chilled storage directly under the worktop: one hinged door and a bank of four drawers. That keeps prepped ingredients within arm's reach of the person building dishes.

The drawers suit portioned and pan-based prep, letting a chef pull the same components repeatedly through service without opening a full door each time, while the door section holds larger or taller stock. The counter top doubles as prep space, keeping cold storage and work surface in the same footprint. It runs at +2 to +8°C — standard chilled-storage temperature for fresh ingredients.

Stainless steel 18/8 construction with 60 mm insulation wipes down between services. Adjustable feet let the counter be levelled on an uneven kitchen floor and set to a comfortable working height. At 140 kg it is movable but solid—plan the delivery route and get help on site. A single 230V connection feeds it at just 0.23 kW, so most kitchen circuits handle it. Craven Cooling services what it sells — call 01792 732702 for installation or a service visit.

BEFORE YOU BUY

Questions, answered straight

One hinged door section and four drawers. The drawers suit portioned and pan-based components you reach for repeatedly, while the door section takes larger or taller stock.

They let you level the counter on an uneven floor and set it to a comfortable working height, so the worktop sits flush along your line.

Yes. The counter has a worktop over the refrigerated section, so cold storage and prep space share the same footprint.

A refrigerated counter for chilled storage, not a freezer. For frozen prep you would want a dedicated freezer counter.

It's a full-length counter, so measure your doorways and delivery route before it arrives. Our team can advise on access when you order.

Craven Cooling services what it sells. Call 01792 732702 to arrange delivery, installation or a service visit.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

CombiSteel 700 Series Refrigerated Counter Single Door and 4 Drawers with Adjustable Feet 7950.5175 Product Data

Brand CombiSteel
Dimensions (W×D×H) 1795 × 700 × 850 mm
Interior Dimensions 1234x580x564
Capacity 417 Ltr
GN Capacity 1x 1/1
Material Stainless steel 18/8
Interior Material Stainless steel 201
Temperature Range +2 / +8
Max. Ambient Temp. 43
Refrigerant R 290
Cooling Ventilated
Defrost Automatic
Number of Doors 1
Number of Grids/Shelves 1x 1/1GN
Electrical Power 0.23 kW
Voltage 230V
Mobile No
Insulation 60 mm
Weight 140 kg
If you have any questions about the CombiSteel 700 Series Refrigerated Counter Single Door and 4 Drawers with Adjustable Feet 7950.5175 then please get in touch.
