CombiSteel 700 Series Refrigerated Counter Single Door 6 Drawers Energy Line 7489.5565

£2,150.83

+vat

- +

Brand:

SKU: 7489.5565

Product summary

Size W/D/H (mm) x x

Product description

Downloads

SPECIFICATION 30 facts · tap for all Width1865 mmDepth700 mmHeight850 mmGross / net weight175 kgVoltage / frequency23050Voltage230V / 50Hz

Identity4

Brand CombiSteelcatalogue
GTIN / EAN 7422242936986catalogue
Range / series Energy Linecatalogue
Type Triple Door Counter Fridgescatalogue

Size & weight5

Depth 700 mmsite
External (W×D×H) 1865 × 700 × 850 mmcatalogue
Gross / net weight 175 kgsite
Height 850 mmsite
Width 1865 mmsite

Capacity5

Capacity 474 Ltrcatalogue
Doors 1catalogue
Gastronorm size 1/1catalogue
Gross volume 474 litrescatalogue
Shelves 2catalogue

Performance5

Cooling type R 290site
Defrost type Automaticsite
Max ambient 4343 °Ccatalogue
Maximum ambient 4343site
Temperature range -2/+8site

Power & energy7

Energy consumption 0,227site
Frequency 50 Hzcatalogue
Noise level 4040site
Rated input 227 Wcatalogue
Rated power 227 kWcatalogue
Voltage 230V / 50Hzcatalogue
Voltage / frequency 23050site

Build & fittings4

Drawers 6site
Exterior finish Stainless steel 430site
Insulation 50 mmcatalogue
Lock Nosite
THE WORKING VIEW

Why this triple door counter fridge earns its place

The Combisteel Refrigerated Counter 1 Door 6 Drawers Energy Line pairs a single door with six drawers in one 474-litre refrigerated prep counter spanning 1865 mm. The door takes bulk trays and taller stock while the six drawers hold portioned mise-en-place, all under one worktop at 850 mm height, matching standard kitchen runs. Built from stainless steel 430 with 50 mm insulation, it holds -2 to +8 °C with automatic defrost and R290 refrigerant, running at a near-silent 40 dB(A).

The mix suits a line that needs both — bulk storage behind the door and section-by-section drawers for prepped ingredients pulled through service. It runs as a chilled refrigerated counter, not a freezer. The ventilated cooling and efficient insulation keep running costs down across long service days; the 175 kg gross weight is manageable for delivery planning without needing specialist equipment.

It's a back-of-house counter for a prep run rather than an under-worktop fit, so measure the 1865 mm × 700 mm run and doorway access first. External dimensions, weight and electrical supply are on the live spec sheet. Craven Cooling handles installation and servicing, with straightforward access for regular condenser cleaning and drawer-seal maintenance.

BEFORE YOU BUY

Questions, answered straight

The unit offers 474 litres total: a single door section for bulk trays and taller stock, and six drawers for portioned mise-en-place. It suits a line that needs both storage types in one counter at 1865 mm × 700 mm.

It spans 1865 mm wide, 700 mm deep, and 850 mm high — matching standard kitchen worktops. Gross weight is 175 kg, so plan your delivery access accordingly without needing specialist equipment.

This is a back-of-house counter for a prep run, not an under-worktop unit. Measure your run and every doorway on the delivery route against the 1865 mm × 700 mm footprint before you commit.

It runs at -2 to +8 °C with automatic defrost, R290 refrigerant, and ventilated cooling at a near-silent 40 dB(A). The 50 mm insulation keeps it efficient across long service hours.

Running cost depends on the unit's energy rating and your electricity tariff. Use our energy label decoder to turn the energy class and annual kWh from the current label into a pounds-per-year figure.

Wipe the stainless steel worktop, cabinet and drawer fronts down daily and keep the door seal and drawer runners clear of grease. For planned servicing or a breakdown, call Craven Cooling on 01792 732702 — we cover installation and ongoing maintenance.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

CombiSteel 700 Series Refrigerated Counter Single Door 6 Drawers Energy Line 7489.5565 Product Data

Brand CombiSteel
Type Energy Line
Dimensions (W×D×H) 1865 × 700 × 850 mm
Capacity 474 Ltr
GN Capacity 1/1
Material Stainless steel 430
Temperature Range -2/+8
Max. Ambient Temp. 43
Refrigerant R 290
Cooling Ventilated
Defrost Automatic
Number of Doors 1
Number of Grids/Shelves 2
Electrical Power 0.227 kW
Voltage 230V / 50Hz
Lockable No
Noise Level 40 dB
Insulation 50 mm
Weight 175 kg
If you have any questions about the CombiSteel 700 Series Refrigerated Counter Single Door 6 Drawers Energy Line 7489.5565 then please get in touch.
