CombiSteel 700 Series Refrigerated Counter Double Door 2 Drawers Energy Line 7489.5520

£1,711.77

+vat

- +

Brand:

SKU: 7489.552

Product summary

Size W/D/H (mm) 1865 x 700 x 850

Product description

Downloads

SPECIFICATION 27 facts · tap for all Width1865 mmDepth700 mmHeight850 mmGross / net weight175 kgVoltage / frequency23050Voltage230V / 50Hz

Identity4

Brand CombiSteelcatalogue
GTIN / EAN 7422242935989catalogue
Range / series Energy Linecatalogue
Type Triple Door Counter Fridgescatalogue

Size & weight5

Depth 700 mmsite
External (W×D×H) 1865 × 700 × 850 mmcatalogue
Gross / net weight 175 kgsite
Height 850 mmsite
Width 1865 mmsite

Capacity3

Capacity 474 Ltrcatalogue
Gastronorm size 1/1catalogue
Gross volume 474 litrescatalogue

Performance5

Cooling type R 290site
Defrost type Automaticsite
Max ambient 4343 °Ccatalogue
Maximum ambient 4343site
Temperature range -2/+8site

Power & energy7

Energy consumption 0,227site
Frequency 50 Hzcatalogue
Noise level 4040site
Rated input 227 Wcatalogue
Rated power 227 kWcatalogue
Voltage 230V / 50Hzcatalogue
Voltage / frequency 23050site

Build & fittings3

Drawers 2site
Exterior finish Stainless steel 430site
Insulation 50 mmcatalogue
THE WORKING VIEW

Why this triple door counter fridge earns its place

This is a refrigerated prep counter from the Energy Line range, built for the working line rather than front-of-house display. Two full-height hinged doors and two refrigerated drawers sit under a continuous stainless steel top at 1865 mm wide, holding 474 litres at -2 to +8 °C, so cold ingredients stay within reach of the section they feed.

In service the counter holds prepped stock at chilled temperature while the worktop takes the prep. The drawers suit portioned proteins and mise en place a chef pulls repeatedly; the door sections take trays and bulkier stock. Built from stainless steel 430 with 50 mm insulation, the surfaces wipe down between services and stand up to a commercial cleaning routine. At 40 dB(A), the unit stays quiet through a busy shift.

As an under-counter format it sits 850 mm tall and 700 mm deep at working height, lining up with other units in the same range to build a continuous run at 175 kg per unit. Plan the door and drawer swing against your gangway, and leave the specified clearance for the refrigeration to breathe. For dimensions, supply and servicing, check the spec table or talk the install through with our team before you order.

BEFORE YOU BUY

Questions, answered straight

It is built as an under-counter unit in this range at 1865 mm wide, 700 mm deep and 850 mm tall, so it sits at working height and lines up with other counters in the same series to form a continuous run. Check the full dimensions against your space and gangway before ordering.

The two drawers suit portioned proteins and mise en place a chef reaches for repeatedly, while the two hinged door sections take trays and bulkier stock. It keeps fast-moving items separated from bulk storage in one 474-litre body.

Refrigerated counters in this range work to Gastronorm sizing, so pans drop in and swap out cleanly. Confirm the exact pan fit for this model on the spec table against your menu.

It is a chilled prep counter holding ingredients at -2 to +8 °C during service, not a freezer. That temperature range suits most prepped proteins, garde manger items and portioned stock through a shift.

Running cost depends on your kitchen's ambient, how hard the doors and drawers are worked and your electricity tariff. The unit draws 227 kW when running. Use our energy label decoder and finance tools to model it against your actual usage.

Stainless steel 430 surfaces wipe down between services and suit a standard commercial cleaning routine. For servicing, breakdown cover or install advice, call our team on 01792 732702.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

CombiSteel 700 Series Refrigerated Counter Double Door 2 Drawers Energy Line 7489.5520 Product Data

Brand CombiSteel
Type Energy Line
Dimensions (W×D×H) 1865 × 700 × 850 mm
Capacity 474 Ltr
GN Capacity 1/1
Material Stainless steel 430
Temperature Range -2/+8
Max. Ambient Temp. 43
Refrigerant R 290
Cooling Ventilated
Defrost Automatic
Number of Doors 2
Number of Grids/Shelves 2
Electrical Power 0.227 kW
Voltage 230V / 50Hz
Noise Level 40 dB
Insulation 50 mm
Weight 175 kg
If you have any questions about the CombiSteel 700 Series Refrigerated Counter Double Door 2 Drawers Energy Line 7489.5520 then please get in touch.
