G-Line by TEFCOLD GVC33-150 Gastronorm Topping Shelf

£386.00

+vat

- +

SKU: 30825

Product summary

  • Stainless steel
  • Glass structure for protection of food
  • Accepts GN1/4 pan(s) (not supplied)
  • Digital controller and temperature display
  • Static cooling
  • Adjustable feet

Product description

Topping Shelves for Gastronorm Pans

Elevate your catering business with the GVC Gastronorm Topping Shelfs. Specifically designed for food service, these enhance your operations with advanced features. Options with glass guard ensuring hygiene and visibility. Organise and display toppings at optimal temperatures for quick food prep. Fully automatic, it maintains temperatures from 2°C to 10°C via a static cooling system, preserving freshness. Manual defrost prevents ice build-up.

The G-Line by TEFCOLD GVC33-150 is a gastronorm topping shelf that holds a +2 to +8 °C chilled band across a 1150 mm internal width using static cooling, built in SS201 stainless steel with an electronic controller and R600a refrigerant on a 13 A supply.

SPECIFICATION 38 facts · tap for all External W × D × H1500 x 335 x 448 mmWidth1500 mmDepth335 mmGross / net weight33 / 29 kgGross weight33 kgVoltage / frequency220-240/50 V/Hz

Identity6

Brand G-Line by TEFCOLDsite
GTIN / EAN 5708181365363site
Product code 30825site
Sub title Gastronorm Topping Shelfcatalogue
Type Glass Topping Unitscatalogue
Warranty 2 year parts & 1 year labour warranty. Exclusions apply (see terms and conditions) – addcatalogue

Size & weight11

Depth 335 mmsite
External (W×D×H) 1500 × 335 × 448 mmcatalogue
External W × D × H 1500 x 335 x 448 mmsite
Gross / net weight 33 / 29 kgsite
Gross weight 33 kgcatalogue
Height 448 mmsite
Internal (W×D×H) 1150 × 245 × 150 mmcatalogue
Internal W × D × H 1150 x 245 x 150 mmsite
Packed (W×D×H) 1600 × 375 × 280 mmcatalogue
Packed W × D × H 1600 x 375 x 280 mmsite
Width 1500 mmsite

Capacity3

Capacity item specification 7 x GN1/4 pcscatalogue
GN pan capacity 7 x GN1/4site
Gross volume 42.2 litrescatalogue

Performance9

Controller Electronicsite
Cooling type Staticsite
Defrost type Manualsite
Max ambient 30 °Ccatalogue
Maximum ambient +30°C, 55% RHsite
Refrigerant R600asite
Refrigerant charge 45 gsite
Temperature range +2 to +8site
Thermometer Yessite

Power & energy5

Annual energy consumption 964 kWh/yearsite
Energy consumption 2.64 kWh/24hsite
Input power 110 Wsite
Noise level 40 dB(A)site
Voltage / frequency 220-240/50 V/Hzsite

Build & fittings2

Exterior finish SS201site
Feet / legs Adjustable Feetsite
THE WORKING VIEW

Why this glass topping unit earns its place

The GVC33-150 is a refrigerated topping shelf for the prep line and pass, keeping garnishes, dressings and prepared toppings chilled and within arm's reach while a kitchen builds plates through service. With 1150 mm of internal width it presents a run of ingredients at working height, so front-of-line staff dress covers without walking back to a fridge. It holds a +2 to +8 °C band, which suits topping and garnish work rather than deep cold storage.

Day to day it runs on static cooling under an electronic controller, holding that +2 to +8 °C range steadily through a busy shift. Defrost is manual, so it is switched off and cleared as part of the cleaning routine rather than cycling automatically. At 40 dB it sits quietly in a back-of-house line. On its verified energy figure of 963.6 kWh a year, running cost works out at about £241 a year at 25p/kWh.

Build is stainless steel inside and out (SS201), giving a wipe-down surface that stands up to daily cleaning. The chilled compartment measures 1150 × 245 × 150 mm (W×D×H). It weighs 29 kg net and 33 kg boxed, and plugs into a standard 13 A supply at 220–240 V. Cooling uses R600a refrigerant with a 45 g charge.

BEFORE YOU BUY

Questions, answered straight

It holds a +2 to +8 °C chilled band using static cooling under an electronic controller. That range suits topping, garnish and dressing work at the line rather than long-term cold storage.

The internal compartment measures 1150 × 245 × 150 mm (W×D×H). That gives a 1150 mm run of chilled ingredients at working height along the prep line.

No, defrost is manual. You switch the unit off and clear it as part of your cleaning routine, rather than it running an automatic defrost cycle.

On its verified figure of 963.6 kWh a year, that is about £241 a year at 25p/kWh. Actual cost depends on your tariff and how hard the unit works.

It runs on a standard 13 A supply at 220–240 V and cools with R600a refrigerant (45 g charge). Noise is rated at 40 dB.

Yes. Craven Cooling supports the units it supplies, and you can reach the service team on 01792 732702 to arrange maintenance or a callout.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

Dimensions

Internal Dimension (WxDxH): 1150 x 245 x 150 mm
External Dimension (WxDxH): 1500 x 335 x 448 mm
Packed Dimension (WxDxH): 1600 x 375 x 280 mm

Cooling and Functions

Type of Controller: Electronic
Type of Cooling: Static
Type of Defrost: Manual
Refrigerant: R600a
Refrigerant Charge: 45 g
Thermometer: Yes

Power and Consumption

Energy Consumption: 2.64 kWh/24h
Temperature Range: +2 to +8 °C
Annual Energy Consumption: 964 kWh/year m³
Input Power: 110 W
Voltage / Frequency: 220-240/50 V/Hz
Noise Level: 40 dB(A)

Measures and Content

Capacity GN Pans: 7 x GN1/4 pcs
Temperature Range: +2 to +8 °C
Gross / Net Weight: 33 / 29 kg
Gross / Net Volume: 42.2 / 36.4 l
Max Ambient: +30°C, 55% RH

Design and Material

Feet / Legs: Adjustable Feet
Exterior Finish: SS201
Interior Finish: SS201
If you have any questions about the G-Line by TEFCOLD GVC33-150 Gastronorm Topping Shelf then please get in touch.
