TEFCOLD CK7310X1SP Gastronorm Counter

£1,177.00

+vat

Brand:

SKU: 54307

Energy Arrow

Product summary

  • Fully automatic
  • Controller with Bluetooth and NFC connectivity
  • HACCP compliant data export
  • Adjustable shelves
  • Self-closing doors
  • High quality catering grade 304 stainless steel
  • Accepts Gastronorm pans (not supplied)
  • Splashback
  • 1/1 Gastronorm cupboards
  • Castors, 2 lockable
  • Replaceable door gasket

Product description

Stainless steel counter chiller with GN1/1 shelves

The CK range of counter coolers in SS304 stainless steel is made for professional kitchens and therefore has GN1/1 dimensions. The counters are available in several sizes and you can choose between solid doors or drawers. You furthermore have the choice between models with a tabletop with or without a splashback. They all have ventilated cooling to ensure an even and steady temperature. The controller has Bluetooth for easy monitoring via app.

The TEFCOLD CK7310X1SP is a three-door stainless steel Gastronorm refrigerated counter holding 291 litres net across a -2 to +8 °C band, with ventilated cooling, automatic defrost and A energy class, drawing about £130 a year at 25p/kWh.

SPECIFICATION 42 facts · tap for all External W × D × H1795 x 700 x 960 mmWidth1795 mmDepth700 mmGross / net weight162 / 152 kgGross weight162 kgVoltage / frequency220-240/50 V/Hz

Identity6

Brand TEFCOLDsite
GTIN / EAN 5708181739386site
Product code 54307site
Sub title Gastronorm Countercatalogue
Type Triple Door Counter Fridgescatalogue
Warranty 2 year parts & 1 year labour warranty. Exclusions apply (see terms and conditions) – addcatalogue

Size & weight11

Depth 700 mmsite
External (W×D×H) 1795 × 700 × 960 mmcatalogue
External W × D × H 1795 x 700 x 960 mmsite
Gross / net weight 162 / 152 kgsite
Gross weight 162 kgcatalogue
Height 960 mmsite
Internal (W×D×H) 1234 × 580 × 564 mmcatalogue
Internal W × D × H 1234 x 580 x 564 mmsite
Packed (W×D×H) 1825 × 730 × 1010 mmcatalogue
Packed W × D × H 1825 x 730 x 1010 mmsite
Width 1795 mmsite

Capacity2

Gross volume 368 litrescatalogue
Shelves 3catalogue

Performance8

Climate class 5site
Controller Electronicsite
Cooling type Ventilatedsite
Defrost type Automaticsite
Refrigerant R600asite
Refrigerant charge 95 gsite
Temperature range -2 to +8site
Thermometer Yessite

Power & energy6

Annual energy consumption 518 kWh/yearsite
Energy consumption 1.42 kWh/24hsite
Energy efficiency index 20.4 %site
Input power 300 Wsite
Noise level 38 dB(A)site
Voltage / frequency 220-240/50 V/Hzsite

Build & fittings4

Exterior finish SS304site
Feet / legs 4 adjustable feetsite
Max load per shelf 13site
Reversible doors Nosite

Other stated facts1

Energy class Acatalogue
THE WORKING VIEW

Why this triple door counter fridge earns its place

The TEFCOLD CK7310X1SP is a three-door refrigerated counter built in SS304 stainless steel inside and out, giving you 291 litres of usable chilled storage (368 litres gross) directly under the working surface. It holds a -2 to +8 °C band, so proteins, dairy and prepped mise en place stay at line temperature within arm's reach. Three grey wire shelves split the load across the three sections, and each of the three hinged doors is self-closing, so a busy pass does not leave a cabinet standing open.

Cooling is ventilated, which moves cold air evenly across all three compartments rather than letting warm spots build near the doors, and defrost runs automatically so nobody has to manage it mid-service. The electronic controller holds the setpoint, and at 38 dB the unit stays quiet enough to sit on the line. It is rated climate class 5 for warm kitchen ambients and carries an A energy class, using 518.3 kWh a year — about £130 a year at 25p/kWh.

The counter measures 1795 × 700 × 960 mm externally and weighs 152 kg net, so plan the delivery route and check clearances before it arrives; packed, it ships at 1825 × 730 × 1010 mm. It runs from a standard 13 amp, 220-240 V supply and uses R600a refrigerant with a 95 g charge, so no special electrical provision is needed beyond a dedicated socket.

BEFORE YOU BUY

Questions, answered straight

It offers 291 litres net usable storage from a 368-litre gross cabinet, divided across three sections with a grey wire shelf in each. All of it sits under the 1795 mm-wide worktop line.

The counter holds a -2 to +8 °C band, suitable for chilled proteins, dairy and prepped ingredients. An electronic controller maintains the setpoint and defrost is fully automatic.

Yes. It is rated climate class 5, so it is built to run in warm kitchen ambients, and the ventilated cooling spreads cold air evenly across all three compartments to avoid warm spots.

It carries an A energy class and uses 518.3 kWh a year, which is about £130 a year at 25p/kWh. R600a refrigerant with a 95 g charge keeps the system efficient.

A standard 13 amp, 220-240 V socket. Input power is 300 W, so no special electrical provision is required beyond a dedicated outlet.

The counter is 1795 × 700 × 960 mm and ships packed at 1825 × 730 × 1010 mm, weighing 152 kg net. Measure your access route first; for delivery or servicing advice call Craven Cooling on 01792 732702.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

Dimensions

Internal Dimension (WxDxH): 1234 x 580 x 564 mm
External Dimension (WxDxH): 1795 x 700 x 960 mm
Packed Dimension (WxDxH): 1825 x 730 x 1010 mm

Cooling and Functions

Type of Controller: Electronic
Type of Cooling: Ventilated
Type of Defrost: Automatic
Refrigerant: R600a
Refrigerant Charge: 95 g
Thermometer: Yes

Power and Consumption

Energy Consumption: 1.42 kWh/24h
Temperature Range: -2 to +8 °C
Annual Energy Consumption: 518 kWh/year m³
EEI: 20.4 %
Input Power: 300 W
Voltage / Frequency: 220-240/50 V/Hz
Noise Level: 38 dB(A)

Measures and Content

Temperature Range: -2 to +8 °C
Climate Class: 5
Gross / Net Weight: 162 / 152 kg
Gross / Net Volume: 368 / 291 l

Design and Material

Door Reversible: No
Shelf Color: Grey
Max load on Shelves: 13 kg/m²
Feet / Legs: 4 adjustable feet
Exterior Finish: SS304
Interior Finish: SS304
Lock: No
If you have any questions about the TEFCOLD CK7310X1SP Gastronorm Counter then please get in touch.
