CombiSteel Refrigerated Counter Double Door Energy Line Equipped with Evaporator 7450.5100

£605.22

+vat

- +

Brand:

SKU: 7450.51

Product summary

Size W/D/H (mm) 903 x 700 x 870

Product description

Downloads

SPECIFICATION 34 facts · tap for all Width903 mmDepth700 mmHeight870 mmGross / net weight83 kgGross weight72 kgVoltage / frequency23050

Identity4

Brand CombiSteelcatalogue
GTIN / EAN 6153302790750catalogue
Range / series Energy Linecatalogue
Type Double Door Counter Fridgescatalogue

Size & weight8

Depth 700 mmsite
External (W×D×H) 903 × 700 × 870 mmcatalogue
Gross / net weight 83 kgsite
Gross weight 72 kgcatalogue
Height 870 mmsite
Internal (W×D×H) 810 × 585 × 456 mmcatalogue
Internal W × D × H 810x585x456site
Width 903 mmsite

Capacity3

Capacity 257 Ltrcatalogue
Gross volume 257 litrescatalogue
Shelves 2catalogue

Performance6

Controller Digitalcatalogue
Cooling type R 600 Asite
Defrost type Automaticsite
Max ambient 3030 °Ccatalogue
Maximum ambient 3030site
Temperature range +2/+8site

Power & energy6

Energy consumption 0,155site
Frequency 50 Hzcatalogue
Rated input 155 Wcatalogue
Rated power 155 kWcatalogue
Voltage 230V / 50Hzcatalogue
Voltage / frequency 23050site

Build & fittings6

Colour Stainless steelcatalogue
Exterior finish Stainless steel Aisi 201site
Insulation 45 mmcatalogue
Interior finish Stainless steel 201site
Lock Nosite
Temperature display Yes, digitalcatalogue

Other stated facts1

Energy (24h) 82 kWh/24hcatalogue
THE WORKING VIEW

Why this double door counter fridge earns its place

This is a two-door refrigerated counter built for the working line of a commercial kitchen. In a 903 × 700 × 870 mm footprint it gives 257 litres of gross chilled capacity, with an 810 × 585 × 456 mm internal space under the worktop. That makes it a compact service-line counter rather than a long bench run: ingredients stay within reach without sending staff back to an upright or cold room.

Day to day, the two doors give separate access to each side of the cabinet, so a section can split prep by use, course or station. Ventilated R600a cooling, automatic defrost and a digital controller hold the cabinet in the +2 to +8 °C chilled band, while 45 mm insulation helps the counter recover after regular door openings. The stainless steel AISI 201 body gives a wipe-clean working surface above the cold storage.

For siting, plan for its 83 kg gross weight and leave ventilation clearance around the refrigeration so it can breathe in ambient temperatures up to 30 °C. It runs from a 230 V, 50 Hz supply; the supplier's power figure should be checked before electrical planning. Measure the 903 mm width and 700 mm depth against your doorway and the gap on the line before delivery, and ask Craven Cooling to confirm the fit if access is tight.

BEFORE YOU BUY

Questions, answered straight

It measures 903 mm wide, 700 mm deep and 870 mm high, with 257 litres gross capacity and an internal space of 810 × 585 × 456 mm. Check the width and depth against your service line and doorway before ordering.

It is supplied as a counter with integrated refrigeration, ventilated R600a cooling, automatic defrost and a digital controller. Allow ventilation clearance around the unit so the refrigeration can breathe, especially in ambient temperatures up to 30 °C.

Yes. It is a stainless steel AISI 201 counter, so the top works for prep boards, pans and service work while chilled stock sits in the cabinet below.

The supplier-stated operating range is +2 to +8 °C, controlled digitally with ventilated cooling and automatic defrost. It is a chilled counter, not a freezer.

No. This model is listed as non-lockable, so choose it for supervised kitchen storage rather than areas where chilled stock needs to be secured.

Yes. Craven Cooling supports the equipment we supply and can arrange servicing and breakdown cover across the UK. Call the team on 01792 732702 to set it up.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

CombiSteel Refrigerated Counter Double Door Energy Line Equipped with Evaporator 7450.5100 Product Data

Brand CombiSteel
Type Energy Line
Dimensions (W×D×H) 903 × 700 × 870 mm
Interior Dimensions 810x585x456
Capacity 257 Ltr
Material Stainless steel Aisi 201
Interior Material Stainless steel 201
Colour / Finish Stainless steel
Temperature Range +2/+8
Max. Ambient Temp. 30
Refrigerant R 600 A
Cooling Ventilated
Defrost Automatic
Number of Doors 2
Number of Grids/Shelves 2x 335×530 / 2x 570×323
Electrical Power 0.155 kW
Energy Use 0.82 kWh/24h
Voltage 230V / 50Hz
Mobile No
Lockable No
Insulation 45 mm
Weight 72 kg
If you have any questions about the CombiSteel Refrigerated Counter Double Door Energy Line Equipped with Evaporator 7450.5100 then please get in touch.
