Williams Jade Undermount Freezer 523Ltr LJ500U-SS FD355

£2,406.62

+vat

Availability: 999 in stock

- +

Brand:

SKU: FD355

Product summary

Stainless Steel Exterior & Interior. 1 Door

Product description

Complementing the exisitng Williams Jade range of cabinets, this new model offers even greater choice of storage.

Foodsafe, easy-clean stainless steel exterior and interior
Full length integral easy-grab door handle
Radiused, easy clean, interior based corners
Precision injected, high density 80mm polyurethane insulation with low GWP and zero ODP
Heavy duty, non-marking swivel castors with brakes
CoolSmart Controller with electro-mechanical buttons. IP55 rated display.
Designed and engineered to operate efficiently up to 43°C ambient
Self closing, barrel locked door with magnetic ballon door gasket with 100% tight seal
Anti-tilt trayslides with removable racking system
Air cooled condensing unit
Defrost water is vaporised using recycled heat from compressor
High performance helium leak testing

Downloads

SPECIFICATION 34 facts · tap for all Width727 mmDepth837 mmHeight1940 mmGross weight129 kgVoltage230VTemperature range-22 to -18 °C

Identity6

Brand Williamssite
Model ref LJ500U HC R3catalogue
Product code FD355site
Range / series Jadecatalogue
Type Upright Freezerscatalogue
Warranty 2 Years Parts & Labourcatalogue

Size & weight6

Depth 837 mmcatalogue
External (W×D×H) 1940 × 727 × 837 mmcatalogue
Gross weight 129 kgcatalogue
Height 1940 mmcatalogue
Internal (W×D×H) 1332 × 567 × 660 mmcatalogue
Width 727 mmsite

Capacity6

Capacity 523Ltrcatalogue
Doors 1catalogue
Gastronorm size 2/1 GN doublecatalogue
Net volume 439 litrescatalogue
Product capacity 523catalogue
Shelves 3catalogue

Performance4

Climate class 4catalogue
Cooling Aircatalogue
Refrigerant R290 / GWP 3catalogue
Temperature range -22 to -18 °Ccatalogue

Power & energy3

Fuel type Plugcatalogue
Rated input 385 Wcatalogue
Voltage 230Vcatalogue

Build & fittings2

Colour Silvercatalogue
Material Stainless Steelcatalogue

Other stated facts7

EEI 67.06 %catalogue
Energy (24h) 6.68 kWh/24hcatalogue
Energy class Dcatalogue
Energy consumption 2439 kWh/yearcatalogue
Indoor / outdoor Cabinetcatalogue
Mobility Castorscatalogue
Plug notice Yescatalogue
THE WORKING VIEW

Why this upright freezer earns its place

The Williams Jade LJ500U-SS is an undermount freezer built to extend the Jade cabinet range with a larger line-side frozen storage option. It is for kitchens that want service stock close to the bench, rather than sending staff back to the walk-in or bulk freezer for every portion.

Capacity is the strong point here: 439 litres net, with three shelves sized for 2/1 GN. That gives a bigger frozen reserve than a small counter base, while the single-door layout keeps it straightforward for batch stock, frozen prep, desserts, fries or labelled service backups.

The freezer holds a -18 to -22 °C operating range, with air cooling, climate class 4 performance and R290 refrigerant with GWP 3. The stainless steel cabinet is a commercial back-of-house build, running from a 230V supply with a 385 W rated input.

BEFORE YOU BUY

Questions, answered straight

It is a commercial freezer. The stated operating band is -18 to -22 °C, with air cooling and R290 refrigerant.

It is sold as an undermount unit, but fit should be confirmed from a measured aperture rather than assumed. Ask Craven Cooling to check siting, ventilation and access before ordering.

It has 439 litres of net frozen capacity, with three shelves and 2/1 GN compatibility. The listed product capacity is 523Ltr, but net volume is the figure to use for usable storage planning.

It is energy class D with stated consumption of 2439 kWh/year, or 6.85 kWh/24h. Put the annual kWh figure into the energy label decoder with your tariff for an estimated running cost.

The warranty is listed as two years parts and labour, and Craven Cooling services what it sells across the UK. Call 01792 732702 to book a visit or set up a maintenance plan.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

Williams Jade Undermount Freezer 523Ltr LJ500U-SS FD355 Product Data

Brand Williams
Type Upright Freezers
Range Jade
Dimensions 1940(H) x 727(W) x 837(D)mm
Capacity 523Ltr
Material Stainless Steel
Colour / Finish Silver
Temperature Range -18°C to -22°C
Refrigerant R290 / GWP 3
Cooling Air
Number of Doors 1
Number of Shelves 3
Energy Rating D
Annual Energy Use 2439kWh/annum
Power 385W
Voltage 230V
Fuel / Supply Plug
Warranty 2 Years Parts & Labour
Weight 129kg
Manufacturer Ref LJ500U-SS
If you have any questions about the Williams Jade Undermount Freezer 523Ltr LJ500U-SS FD355 then please get in touch.
