TEFCOLD CRNF1230 Freezer Room

£5,384.00

+vat

Brand:

SKU: 66833

Product summary

  • Plug-In – ready after assembly
  • Many customisation possibilities
  • Easy access to products
  • Freezing unit
  • Easy assembly
  • 120 mm panel insulation
  • Anti-slip floor in SS304 stainless steel
  • Alarm kit as accessory
  • Shelves available as accessory
  • Ramp available as accessory for easy access

Product description

Ideal, cost-effective, efficient storage with the freezer rooms range

The CRNF freezer room range is ideal for a variety of settings including restaurants, cafes, delis and retail stores. They’re the perfect solution for creating an efficient, optimised freezing space and are highly cost-effective. The modular panel rooms provide easy assembly, simplifying the set-up process significantly. Choose from a variety of sizes to get the perfect fit for your business. These are also available in a cool room version too.

The Tefcold CRNF1230 is a modular walk-in freezer room holding -20 to -10 °C across a 960 × 2760 × 1960 mm internal space, running on a standard 13 A supply with an R290 hydrocarbon system, automatic hot-gas defrost and electronic control.

SPECIFICATION 37 facts · tap for all External W × D × H1200 x 3000 x 2200 mmWidth1200 mmDepth3000 mmGross / net weight550 / 520 kgGross weight550 kgVoltage / frequency220-240/50 V/Hz

Identity6

Brand TEFCOLDsite
GTIN / EAN 5708181750633site
Product code 66833site
Sub title Freezer Roomcatalogue
Type Walk-in Freezerscatalogue
Warranty 2 year parts & 1 year labour warranty. Exclusions apply (see terms and conditions) – addcatalogue

Size & weight11

Depth 3000 mmsite
External (W×D×H) 1200 × 3000 × 2200 mmcatalogue
External W × D × H 1200 x 3000 x 2200 mmsite
Gross / net weight 550 / 520 kgsite
Gross weight 550 kgcatalogue
Height 2200 mmsite
Internal (W×D×H) 960 × 2760 × 1960 mmcatalogue
Internal W × D × H 960 x 2760 x 1960 mmsite
Packed (W×D×H) 2200 × 1900 × 2400 mmcatalogue
Packed W × D × H 2200 x 1900 x 2400 mmsite
Width 1200 mmsite

Capacity2

Doors 1catalogue
Internal volume 5.19site

Performance6

Controller Electronicsite
Defrost type Automatic, hot gassite
Refrigerant R290site
Refrigerant charge 150 gsite
Temperature range -20 to -10site
Thermometer Yessite

Power & energy5

Annual energy consumption 9864 kWh/yearsite
Energy consumption 27.02 kWh/24hsite
Input power 1510 Wsite
Noise level 60 dB(A)site
Voltage / frequency 220-240/50 V/Hzsite

Build & fittings4

Exterior finish Whitesite
Interior light LEDsite
Max floor load 2000 kg/m²site
Wall thickness 120site
THE WORKING VIEW

Why this walk-in freezer earns its place

The CRNF1230 is a walk-in freezer room that gives a commercial kitchen dedicated sub-zero storage without a custom cold-room build. The internal working space is 960 × 2760 × 1960 mm (W×D×H), a walk-in bay for bulk frozen stock, and a single hinged solid door 580 mm wide by 1765 mm high takes trolleys and stacked cases. It holds -20 to -10 °C for long-term frozen holding.

Cooling is managed by an electronic controller that keeps the room in the -20 to -10 °C band, and defrost is automatic using hot gas, so ice is cleared without staff switching the room off or scraping it down. The system draws 1510 W and runs at 60 dB. At 9864 kWh a year that works out at about £2466 a year at 25p/kWh — worth factoring into where you site it and how hard it is worked.

It runs from a standard 13 A supply at 220-240 V/50 Hz, so no dedicated power spur is needed. The refrigeration uses R290 hydrocarbon refrigerant with a 150 g charge, and the room carries a white finish inside and out. Gross weight is 550 kg (520 kg net) and it arrives as modular panels, so plan your doorway access and delivery route — the 580 mm door leaf sets the tightest point.

BEFORE YOU BUY

Questions, answered straight

It holds -20 to -10 °C, suitable for long-term frozen storage. The band is maintained by an electronic controller.

No. It runs from a standard 13 A supply at 220-240 V/50 Hz, which is a normal commercial socket rather than a dedicated power spur.

It's rated at 9864 kWh a year, which is about £2466 a year at 25p/kWh. Actual cost depends on your tariff, ambient conditions and how often the door is opened.

Defrost is automatic and uses hot gas, so ice is cleared without staff having to switch the room off or scrape it down.

It uses R290, a hydrocarbon refrigerant, with a 150 g charge. Cooling is run by an electronic controller.

Yes. The room weighs 550 kg gross and arrives as modular panels, so plan doorway access and route in advance. For servicing and support call 01792 732702.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

Dimensions

Internal Dimension (WxDxH): 960 x 2760 x 1960 mm
External Dimension (WxDxH): 1200 x 3000 x 2200 mm
Packed Dimension (WxDxH): 2200 x 1900 x 2400 mm

Cooling and Functions

Type of Controller: Electronic
Type of Defrost: Automatic, hot gas
Refrigerant: R290
Refrigerant Charge: 150 g
Thermometer: Yes

Power and Consumption

Energy Consumption: 27.02 kWh/24h
Temperature Range: -20 to -10 °C
Annual Energy Consumption: 9864 kWh/year m³
Input Power: 1510 W
Voltage / Frequency: 220-240/50 V/Hz
Noise Level: 60 dB(A)

Measures and Content

Internal Volume: 5.19 m³
Wall Thickness: 120 mm
Temperature Range: -20 to -10 °C
Gross / Net Weight: 550 / 520 kg
Max Load on Floor: 2000 kg/m² kg/m²

Design and Material

Door Reversible: Yes
Exterior Finish: White
Interior Finish: White
Interior Light: LED
Lock: Yes
If you have any questions about the TEFCOLD CRNF1230 Freezer Room then please get in touch.
