Polar U-Series 2.1 x 2.1m Integral Walk In Freezer Room Brown DS489-FBN

£7,348.76

+vat

Availability: 999 in stock

- +

Brand:

SKU: DS489-FBN

Product summary

2.1 x 2.1m. Capacity: 7677 Ltr. Freezer

Product description

Integral Walk In Room designed to work in 43°C. Internal light & 13amp Plug. 2 Year Full Warranty, 5 Year Panel guarantee.

Operates effectively at high ambient temperatures up to 43°C
Easy clean internal coving and wall panels
Energy efficient LED sealed light fitting
Intuitive digital temperature control and display
Non-slip aluminium floor
High/low temperature alarm
Easy-clean door seal/gasket
Wall panels constructed from 0.6mm thick galvanised steel finished with 200 microns of food safe white plastic
Weather and humidity resistant front control panel
Highly efficient 80mm panel insulation with dovetail joints to prevent air leakage
Lockable self closing door shuts flush against door panels for security and efficiency
7 day warranty cover

Downloads

SPECIFICATION 29 facts · tap for all Width2100 mmHeight2200 mmGross weight450 kgVoltage230VTemperature range-18 to -15 °CCapacity7677Ltr

Identity7

Brand Polarsite
GTIN / EAN 5.05098E+12catalogue
Product code DS489-FBNsite
Range / series U Seriescatalogue
Seo name Polar Integral Walk In Freezer Room Browncatalogue
Type Freezer Roomscatalogue
Warranty 2 Years Parts & Labourcatalogue

Size & weight5

External (W×D×H) 2200 × 2100 × 2100 mmcatalogue
Gross weight 450 kgcatalogue
Height 2200 mmcatalogue
Internal (W×D×H) 2037 × 1880 × 1880 mmcatalogue
Width 2100 mmsite

Capacity5

Capacity 7677Ltrcatalogue
Door type Hingedcatalogue
Doors 1catalogue
Gross volume 7677 litrescatalogue
Product capacity 7677catalogue

Performance3

Cooling Fan Assistcatalogue
Refrigerant R449A / 1500gcatalogue
Temperature range -18 to -15 °Ccatalogue

Power & energy3

Fuel type Single Phasecatalogue
Rated input 1800 Wcatalogue
Voltage 230Vcatalogue

Build & fittings5

Colour Browncatalogue
Colour code Vandyke Browncatalogue
Doorocation Frontcatalogue
Insulation 80 mmcatalogue
Material Galvanised Steel/ Aluminium & Plasticcatalogue

Other stated facts1

Electrical safety notice Yescatalogue
THE WORKING VIEW

Why this freezer room earns its place

The Polar U-Series DS489-FBN is a brown integral walk-in freezer room with 7,677 litres of capacity in a 2.1 x 2.1m footprint. It gives back-of-house a single frozen store to walk into and work from at –15 to –18 °C, keeping bulk frozen stock in one place on shelves and trolleys instead of across a row of cabinets. Inside it's 2.04m x 1.88m, with full-height access for loading and rotation.

Day to day it runs as walk-in frozen holding: product goes in on shelving, stays organised by line and stock level, and stays reachable through service without opening a bank of cabinet doors. The 80mm-thick insulated panels maintain temperature while one room makes rotation, picking and stock checks simpler. It works in ambient temperatures up to 43 °C.

As an integral room, the refrigeration is built into the unit (R449A, 230V, 1800W) rather than run from separate remote plant, so it installs as a self-contained cold room at 450 kg. Panel assembly, doorway access, siting and drainage are all worth planning before delivery. It comes with a 2-year parts and labour warranty plus a 5-year panel guarantee.

BEFORE YOU BUY

Questions, answered straight

It is an integral walk-in room built from 80mm-thick panels (450 kg total), so the access route and final position need checking against your doorways and floor before delivery. Our team can talk you through panel assembly and siting — call 01792 732702.

It depends on how much frozen stock you hold and how often you pick from it. This room holds 7,677 litres in one space (–15 to –18 °C) where you work inside; uprights spread the same capacity across separate cabinets with separate running costs. The cold room vs uprights comparator helps you weigh real litres and energy against your volume.

It arrives as a self-contained unit with the R449A refrigeration built in (230V, 1800W), so there is no separate remote plant to site. Panel assembly, power supply and drainage still need planning, so speak to us about the install before you order.

Frozen storage at –15 to –18 °C should be temperature-monitored and logged as part of your HACCP routine. We can advise on monitoring and logging options suited to a walk-in room.

An 1800W integral system running continuously is often more efficient than multiple uprights, but cost depends on your tariff, the ambient around the room and how hard it works through the day. Use the finance and breakdown-cost tools, or ask us to talk it through for your site.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

Polar U-Series 2.1 x 2.1m Integral Walk In Freezer Room Brown DS489-FBN Product Data

Brand Polar
Type Freezer Rooms
Range U Series
Dimensions 2200(H) x 2100(W) x 2100(D)mm
Capacity 7677Ltr
Material Galvanised Steel/ Aluminium & Plastic
Colour / Finish Brown
Temperature Range -15°C to -18°C
Refrigerant R449A / 1500g
Cooling Fan Assist
Number of Doors 1
Power 1800W
Voltage 230V
Fuel / Supply Single Phase
Warranty 2 Years Parts & Labour
Weight 450kg
If you have any questions about the Polar U-Series 2.1 x 2.1m Integral Walk In Freezer Room Brown DS489-FBN then please get in touch.
