TEFCOLD EVO1202 Patisserie and Deli Display

£3,317.00 £2,110.00

+vat

- +

Brand:

SKU: 38295

Energy Arrow

Product summary

  • Fully automatic
  • Fan assisted cooling
  • Adjustable feet
  • Interior light with switch
  • Digital controller and temperature display
  • Hinged glass for easy cleaning
  • Individually illuminated glass shelves
  • Glass rear sliding doors

Product description

The EVO range offers 4-tier patisserie display cabinets ideal for showcasing cakes and desserts. Individually illuminated glass shelves enhance the display. Fully automated fan-assisted cooling ensures reliable and even cooling throughout the cabinet. The curved front glass hinges forward for easy cleaning. Additionally, the glass on the unit comes pre-built for hassle-free installation.

Sale!

Downloads

SPECIFICATION 40 facts · tap for all External W × D × H1200 x 755 x 1400 mmWidth1200 mmDepth755 mmGross / net weight155 / 145 kgGross weight155 kgVoltage / frequency220-240/50 V/Hz

Manufacturer documents2

Identity6

Brand TEFCOLDsite
GTIN / EAN 5708181999759site
Product code 38295site
Sub title Patisserie and Deli Displaycatalogue
Type Curved Glass Cake Display Fridgescatalogue
Warranty 2 year parts & 1 year labour warranty. Exclusions apply (see terms and conditions) – addcatalogue

Size & weight11

Depth 755 mmsite
External (W×D×H) 1200 × 755 × 1400 mmcatalogue
External W × D × H 1200 x 755 x 1400 mmsite
Gross / net weight 155 / 145 kgsite
Gross weight 155 kgcatalogue
Height 1400 mmsite
Internal (W×D×H) 1155 × 502 × 790 mmcatalogue
Internal W × D × H 1155 x 502 x 790 mmsite
Packed (W×D×H) 1300 × 840 × 1580 mmcatalogue
Packed W × D × H 1300 x 840 x 1580 mmsite
Width 1200 mmsite

Capacity3

Display area 1.62 m²site
Doors 2catalogue
Gross volume 440 litrescatalogue

Performance9

Climate class 3site
Controller Electronicsite
Defrost type Automaticsite
Max ambient 25 °Ccatalogue
Maximum ambient +25°C, 60% RHsite
Refrigerant R290site
Refrigerant charge 140 gsite
Temperature range +1 to +10site
Thermometer Yessite

Power & energy6

Annual energy consumption 2915 kWh/yearsite
Energy consumption 7.99 kWh/24hsite
Energy efficiency index 36.6 %site
Input power 475 Wsite
Noise level 44 dB(A)site
Voltage / frequency 220-240/50 V/Hzsite

Build & fittings2

Exterior finish Blacksite
Interior light LEDsite

Other stated facts1

Energy class Dcatalogue
THE WORKING VIEW

Why this curved glass cake display fridge earns its place

The Tefcold EVO1202 is a patisserie and deli display cabinet finished in black, built to merchandise cakes, desserts and prepared chilled foods. It presents 1.62 m² of display across three glass shelves plus the base deck, with a grey interior, and it is served through two sliding glass doors so staff can restock from behind without breaking the customer view.

Day to day it holds a +1 to +10 °C band suited to patisserie and deli lines. Automatic defrost and an electronic controller manage the cycle, it works at 44 dB, and it is rated climate class 3. It uses R290 refrigerant and carries energy class D at 2916.3 kWh a year — about £729 a year at 25p/kWh.

The cabinet measures 1200 × 755 × 1400 mm externally with an 1155 × 502 × 790 mm display bay, and it ships packed at 1300 × 840 × 1580 mm — check the packed 1300 mm width and 1580 mm height against your access route. It weighs 145 kg net (155 kg gross), runs from a standard 13 A supply at 220–240 V/50 Hz drawing 475 W, and holds a 140 g charge of R290.

BEFORE YOU BUY

Questions, answered straight

A +1 to +10 °C band, suited to patisserie, desserts and prepared chilled foods. It is rated climate class 3.

The cabinet is 1200 mm wide and ships packed at 1300 × 840 × 1580 mm, so check that the 1300 mm packed width and 1580 mm height clear your route. It stands 1400 mm tall unpacked.

1.62 m² across three glass shelves plus the base deck, with an internal bay 1155 mm wide.

Energy class D at 2916.3 kWh a year, which is about £729 a year at 25p/kWh. Actual cost depends on your tariff and siting.

A standard 13 A supply at 220–240 V/50 Hz drawing 475 W, using R290 refrigerant with a 140 g charge. It runs at 44 dB.

Yes — our engineers cover commercial refrigeration across the region. Call 01792 732702 to arrange servicing or breakdown support.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

Dimensions

Internal Dimension (WxDxH): 1155 x 502 x 790 mm
External Dimension (WxDxH): 1200 x 755 x 1400 mm
Packed Dimension (WxDxH): 1300 x 840 x 1580 mm

Cooling and Functions

Type of Controller: Electronic
Type of Defrost: Automatic
Refrigerant: R290
Refrigerant Charge: 140 g
Thermometer: Yes

Power and Consumption

Energy Consumption: 7.99 kWh/24h
Temperature Range: +1 to +10 °C
Annual Energy Consumption: 2915 kWh/year m³
EEI: 36.6 %
Input Power: 475 W
Voltage / Frequency: 220-240/50 V/Hz
Noise Level: 44 dB(A)

Measures and Content

Temperature Range: +1 to +10 °C
Climate Class: 3
Gross / Net Weight: 155 / 145 kg
Gross / Net Volume: 440 / l
Max Ambient: +25°C, 60% RH
Total Display Area: 1.62 m² m²

Design and Material

Exterior Finish: Black
Interior Finish: Black
Interior Light: LED
If you have any questions about the TEFCOLD EVO1202 Patisserie and Deli Display then please get in touch.
