INFRICO Triple Hinged Glass Door Bottle Cooler ZXS3

£1,419.92

+vat

- +

Brand:

SKU: ZXS3

Product summary

Size: 1350 x 520 x 900

Product description

  • Laminated exterior and interior
  • Internal illumination
  • Wider spaced finner condenser for minimum maintenace
  • Lock as standard
  • Can be built in
  • Double glazed glass door
  • Adjustable feet
  • Replaceable door gasket
SPECIFICATION 24 facts · tap for all External W × D × H1350 x 520 x 900Width1350 mmDepth520 mmHeight900 mmGross weight132 kgVoltage / frequency425W

Manufacturer documents2

Identity3

Brand INFRICOsite
Product code ZXS3site
Type Triple Door Bar Fridgescatalogue

Size & weight6

Depth 520 mmsite
External (W×D×H) 1350 × 520 × 900 mmcatalogue
External W × D × H 1350 x 520 x 900site
Gross weight 132 kgcatalogue
Height 900 mmsite
Width 1350 mmsite

Capacity2

Doors 3catalogue
Gross volume 324 litrescatalogue

Performance6

Climate class 4site
Controller Digital controller with temperature displaysite
Cooling type Fan Assistedsite
Defrost type Automaticsite
Refrigerant R290site
Temperature range +4C/+12Csite

Power & energy3

Input power 13amp supplysite
Rated input 425 Wcatalogue
Voltage / frequency 425Wsite

Build & fittings2

Exterior finish Charcoal with aluminium doorsite
Shelves 6site
THE WORKING VIEW

Why this triple door bar fridge earns its place

The INFRICO ZXS3 is a triple-door bottle cooler built to put chilled stock on show across the front of a busy bar. Its three glass doors turn one run of the cabinet into a display wall, so customers pick by sight and staff restock without hunting. At 1350 mm wide it holds a serious spread of bottled and canned lines within arm's reach of the service point, which makes it a back-bar and hospitality merchandising workhorse rather than a back-of-house store.

Day to day the ZXS3 runs on automatic defrost, so there is no manual routine to schedule around service — the cabinet clears frost without staff intervention. It is rated to climate class 4, meaning it is built to hold temperature in warmer, busier rooms rather than only in cool cellars, which matters behind a bar where the ambient climbs through a shift. Cooling is handled by an R290 system, a low-GWP hydrocarbon refrigerant now standard across modern commercial cooling.

For installation, plan around external dimensions of 1350 × 520 × 900 mm (W×D×H) and a gross weight of 132 kg. Treat it as a two-person lift with a clear route to position, and check the 1350 mm width against your back-bar run and any doorways on the way in; the 520 mm depth keeps it tight to the wall in front-of-house layouts. R290 is a flammable hydrocarbon refrigerant, so keep the specified ventilation clearances around the cabinet and use a competent engineer for any pipework or relocation.

BEFORE YOU BUY

Questions, answered straight

It measures 1350 mm wide, 520 mm deep and 900 mm high (W×D×H). The 1350 mm width is the figure to check against your back-bar run, while the 520 mm depth keeps it close to the wall in front-of-house layouts.

Gross weight is 132 kg, so treat it as a two-person lift and clear a route to its final position before it arrives. Check that the 1350 mm width passes any doorways on the way in.

It runs on R290, a low-GWP hydrocarbon refrigerant now standard on modern commercial coolers. R290 is flammable, so keep the specified ventilation clearances around the cabinet and use a competent engineer for any pipework or relocation.

No. The ZXS3 uses automatic defrost, so the cabinet clears frost on its own and there is no manual routine for staff to schedule around service.

It is rated to climate class 4, meaning it is built to hold temperature in warmer ambient conditions rather than only in cool rooms. That suits a working bar where the room heats up through a shift.

Yes. Craven Cooling supports the cabinets it supplies and can arrange servicing — call the team on 01792 732702 to book or discuss a fault.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

Dimensions

External Dimension (WxDxH): 1350 x 520 x 900

Cooling and Functions

Type of Controller: Digital controller with temperature display
Type of Cooling: Fan Assisted
Type of Defrost: Automatic
Refrigerant: R290

Power and Consumption

Temperature Range: +4C/+12C °C
Input Power: 13amp supply
Voltage / Frequency: 425W

Measures and Content

Temperature Range: +4C/+12C °C
Climate Class: 4
Gross / Net Volume: 324 Bottles l

Design and Material

Shelves Number & Type: 6
Exterior Finish: Charcoal with aluminium door

INFRICO Triple Hinged Glass Door Bottle Cooler ZXS3 Product Data

If you have any questions about the INFRICO Triple Hinged Glass Door Bottle Cooler ZXS3 then please get in touch.
