CombiSteel Single Glass Door Display Freezer 7450.0165

£1,344.96

+vat

- +

SKU: 7450.0165

Product summary

Size W/D/H (mm) x x

Product description

Downloads

SPECIFICATION 32 facts · tap for all Width680 mmDepth700 mmHeight1990 mmGross / net weight138 kgVoltage / frequency23050Voltage230V / 50Hz

Identity3

Brand CombiSteelcatalogue
GTIN / EAN 7435137812838catalogue
Type Single Door Upright Glass Door Freezerscatalogue

Size & weight5

Depth 700 mmsite
External (W×D×H) 680 × 700 × 1990 mmcatalogue
Gross / net weight 138 kgsite
Height 1990 mmsite
Width 680 mmsite

Capacity3

Capacity 578 Ltrcatalogue
Gross volume 578 litrescatalogue
Shelves 5catalogue

Performance6

Controller Digitalcatalogue
Cooling type R 290site
Defrost type Manualsite
Max ambient 3232 °Ccatalogue
Maximum ambient 3232site
Temperature range -18/-24site

Power & energy7

Energy consumption 0.34site
Frequency 50 Hzcatalogue
Noise level 5050site
Rated input 340 Wcatalogue
Rated power 0.34 kWcatalogue
Voltage 230V / 50Hzcatalogue
Voltage / frequency 23050site

Build & fittings6

Colour Whitecatalogue
Doors Rightsite
Exterior finish White painted steelsite
Insulation 60 mmcatalogue
Interior finish Aluminiumsite
Interior light Yes, LEDsite

Other stated facts2

Lockable Yescatalogue
Mobility Nocatalogue
THE WORKING VIEW

Why this single door upright glass door freezer earns its place

The Freezer 1 Glass Door is an upright commercial display freezer with a single glass door. The glass front lets staff and customers see frozen stock without opening the door, so it works both as a self-service retail freezer on the shop floor and as organised, visible frozen storage in a kitchen or back-of-house. At 578 litres, it holds enough product for a working day without dominating the shop floor — a single-door upright suits a convenience store frozen range or a kitchen freezer in a smaller restaurant.

Behind the glass it runs as a frozen-storage cabinet at −18 to −24 °C with static cooling and manual defrost. A glass door does draw a little more temperature pull-down each time it is opened during a busy service, so siting and door discipline matter for holding frozen product reliably. The cabinet stands 1990 mm tall and 680 mm wide with a 700 mm depth, making it a tall, narrow upright for shops with compact floor space. At 138 kg it is a one-person installation on a flat floor.

Confirm the external dimensions, weight and electrical requirements from the spec table before installing, and measure your delivery route, as an upright freezer of this height needs clear access through doorways and any lift. Keep it clear of heat sources and leave the ventilation clearances the manufacturer specifies so the condenser can breathe. The cabinet runs on 230V mains supply and draws 0.34 kW — modest power consumption for the capacity, and the LED interior light runs quietly at 50 dB(A).

BEFORE YOU BUY

Questions, answered straight

It is a freezer — an upright glass-door cabinet built to hold frozen product. The exact operating temperature band is listed in the spec table on this page.

Yes. The single glass door is designed so staff and customers can see what is inside without opening the cabinet, which helps keep the interior at temperature during a busy service.

Confirm the external width, depth and height from the spec table on this page and measure your delivery route before ordering. An upright freezer needs a clear path through doorways, corridors and any lift.

The capacity and internal shelving are listed in the spec table on this page. Our capacity calculator can help you work out how many litres you actually need for your range.

Keep it away from direct heat and sunlight and leave the ventilation clearances the manufacturer specifies so the condenser can breathe and the cabinet holds temperature.

Yes. Craven Cooling services the commercial refrigeration we supply — call the team on 01792 732702 to book a service visit or discuss a fault.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

CombiSteel Single Glass Door Display Freezer 7450.0165 Product Data

Brand CombiSteel
Dimensions (W×D×H) 680 × 700 × 1990 mm
Capacity 578 Ltr
Material White painted steel
Interior Material Aluminium
Colour / Finish White
Temperature Range -18/-24
Max. Ambient Temp. 32
Refrigerant R 290
Cooling Static
Defrost Manual
Number of Doors 1
Number of Grids/Shelves 5x 510×495
Electrical Power 0.34 kW
Voltage 230V / 50Hz
Installation Freestanding
Mobile No
Lockable Yes
Noise Level 50 dB
Insulation 60 mm
Weight 138 kg
If you have any questions about the CombiSteel Single Glass Door Display Freezer 7450.0165 then please get in touch.
