TEFCOLD IC502SCE-SO Scoop Ice Cream Freezer

£893.00

+vat

- +

Brand:

SKU: 71510

Energy Arrow

Product summary

  • Curved glass canopy
  • LED interior light
  • Angled sliding lids with lock
  • Castors with brake
  • Storage under baskets
  • Great branding possibilities
  • Accepts plastic napoli size tubs. Stainless napoli pans not required
  • Climate class 5 for high performance in warm surroundings

Product description

Scoop ice cream freezer with canopy

The IC-SCE-SO canopy range is an ideal way to add scooping ice cream sales to your business even if you are on a budget. This is one of our most popular ranges. A curved glass canopy with an attractive sloping display for scooping tubs means your customers get a good view of the ice cream in the unit (baskets which fit 5 litre tubs, with the option for 4 ltr baskets/tubs if required). Flat glass sliding lids (with lock) allow access to the ice cream for serving and help insulate the unit when not in use.

SPECIFICATION 44 facts · tap for all External W × D × H1550 x 615 x 1295 mmWidth1550 mmDepth615 mmGross / net weight127 / 117 kgGross weight127 kgVoltage / frequency220-240/50 V/Hz

Identity6

Brand TEFCOLDsite
GTIN / EAN 5708181760878site
Product code 71510site
Sub title Scoop Ice Cream Freezercatalogue
Type Static Cooled Ice Cream Display Freezerscatalogue
Warranty 2 year parts & 1 year labour warranty. Exclusions apply (see terms and conditions) – addcatalogue

Size & weight11

Depth 615 mmsite
External (W×D×H) 1550 × 615 × 1295 mmcatalogue
External W × D × H 1550 x 615 x 1295 mmsite
Gross / net weight 127 / 117 kgsite
Gross weight 127 kgcatalogue
Height 1295 mmsite
Internal (W×D×H) 1420 × 495 × 710 mmcatalogue
Internal W × D × H 1420 x 495 x 710 mmsite
Packed (W×D×H) 1640 × 750 × 1210 mmcatalogue
Packed W × D × H 1640 x 750 x 1210 mmsite
Width 1550 mmsite

Capacity3

Gross volume 427 litrescatalogue
Serving capacity 11 Plastic Tubs (5L) / 8 Napoli Pans (5L) / 16 Plastic Tubs (4L)site
Under-counter storage 22 Plastic Tubs (5L) / 17 Napoli Pans (5L) / 22 Plastic Tubs (4L)site

Performance10

Climate class 5site
Controller Mechanicalsite
Cooling type Staticsite
Defrost type Manualsite
Max ambient 40 °Ccatalogue
Maximum ambient +40°C, 40% RHsite
Refrigerant R290site
Refrigerant charge 110 gsite
Temperature range -24 to -14site
Thermometer Yessite

Power & energy6

Annual energy consumption 1056.675 kWh/yearsite
Energy consumption 2.895 kWh/24hsite
Energy efficiency index 43.9 %site
Input power 350 Wsite
Noise level 45 dB(A)site
Voltage / frequency 220-240/50 V/Hzsite

Build & fittings3

Castors 4 wheels, 2 with brakesite
Exterior finish Whitesite
Interior light LEDsite

Other stated facts1

Energy class Dcatalogue
THE WORKING VIEW

Why this static cooled ice cream display freezer earns its place

The Tefcold IC502SCE-SO is a scoop ice cream display freezer, built so an operator can serve loose scoops straight from an open display well. It presents 427 litres gross of frozen product in a white cabinet with a 1420 mm-wide interior, the width doing the work of putting a full row of tubs on show for scoop-serve. It is a front-of-shop merchandising freezer for a parlour, café or kiosk.

Day to day it holds -24 to -14 °C, runs at 45 dB and is rated to climate class 5. Defrost is manual and control is mechanical. On energy it sits at class D, using 957 kWh a year — about £239 a year at 25p/kWh — with an energy efficiency index of 43.9.

Internally it measures 1420 × 495 × 710 mm (W×D×H) and it draws 350 W from a standard 13 A supply, so it plugs into an ordinary socket rather than needing a dedicated circuit. It runs on R290 refrigerant with a 110 g charge and weighs 127 kg gross. The full external dimensions are in the specification table on this page; Craven Cooling supplies and services the Tefcold range.

BEFORE YOU BUY

Questions, answered straight

It holds -24 to -14 °C. Defrost is manual and the control is mechanical.

It is rated energy class D and uses 957 kWh a year, which is about £239 a year at 25p/kWh, with an energy efficiency index of 43.9. Your figure depends on your tariff.

It draws 350 W from a standard 13 A supply, so it runs from an ordinary socket. It uses R290 refrigerant with a 110 g charge.

It holds 427 litres gross, with an internal well of 1420 × 495 × 710 mm (W×D×H). The external dimensions are in the specification table on this page.

It runs at 45 dB and is rated to climate class 5, so it is specified to cope with a warm shop environment.

Yes. Craven Cooling supplies and services the Tefcold range — call the service team on 01792 732702 to arrange support.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

Dimensions

Internal Dimension (WxDxH): 1420 x 495 x 710 mm
External Dimension (WxDxH): 1550 x 615 x 1295 mm
Packed Dimension (WxDxH): 1640 x 750 x 1210 mm

Cooling and Functions

Type of Controller: Mechanical
Type of Cooling: Static
Type of Defrost: Manual
Refrigerant: R290
Refrigerant Charge: 110 g
Thermometer: Yes

Power and Consumption

Energy Consumption: 2.895 kWh/24h
Temperature Range: -24 to -14 °C
Annual Energy Consumption: 1056.675 kWh/year m³
EEI: 43.9 %
Input Power: 350 W
Voltage / Frequency: 220-240/50 V/Hz
Noise Level: 45 dB(A)

Measures and Content

Temperature Range: -24 to -14 °C
Climate Class: 5
Gross / Net Weight: 127 / 117 kg
Gross / Net Volume: 427 / 398 l
Max Ambient: +40°C, 40% RH

Design and Material

Serving Capacity: 11 Plastic Tubs (5L) / 8 Napoli Pans (5L) / 16 Plastic Tubs (4L)
Storage capacity (under): 22 Plastic Tubs (5L) / 17 Napoli Pans (5L) / 22 Plastic Tubs (4L)
Castors: 4 wheels, 2 with brake
Exterior Finish: White
Interior Finish: White
Interior Light: LED
Lock: Yes
If you have any questions about the TEFCOLD IC502SCE-SO Scoop Ice Cream Freezer then please get in touch.
