DC OXG50A IS D Optima Glasswashers – frontloading 500×500

£2,755.50

+vat

- +

Brand:

SKU: OXG50A IS D

Product summary

Product description

Intuitive TFT touch screen control panel, 4 adjustable cycles + ECO and self-clean cycle, multifunction start button, colour status button, soft start, chemical dosing adjusted from control panel, selectable thermolock, ECO standby mode, temperature read-outs, information and fault logs, engineer diagnostic mode, double skinned and insulated panels and door, insulated boiler, hermetic door seal, superior peristaltic pumps, easy fit large wash and micro filter, partial drain before rinse, moulded hydro dynamic basket slides, quick release wash and rinse arms, 2 glass baskets, break tank, drain pump, integral softener.

A frontloading glasswasher with integrated water softening, ECO cycles and solid insulation—built for pubs, bars and venues that need spotless glasses and low running costs.

Downloads

SPECIFICATION 22 facts · tap for all External W × D × H600x600x725mmWidth600 mmInput power30 ampProduct codeOXG50A IS DBrandDCTypeCommercial Dishwashers

Identity3

Brand DCsite
Product code OXG50A IS Dsite
Type Commercial Dishwasherscatalogue

Size & weight4

External (W×D×H) 600 × 600 × 725 mmcatalogue
External W × D × H 600x600x725mmsite
Height 725 mmsite
Width 600 mmsite

Capacity1

Wash height 300 mmcatalogue

Power & energy4

Input power 30 ampsite
Rinse element 4.5 kWcatalogue
Totaload 6.6 kWcatalogue
Wash element 2 kWcatalogue

Build & fittings2

Double skinned Yescatalogue
Filterount 2catalogue

Other stated facts8

Basket size 500×500catalogue
Boilerapacity 5.5 Lcatalogue
Cycle times s 120 180 240 480 Eco Cyclecatalogue
Placeapacity 30catalogue
Wash tank 12 Lcatalogue
Water flow min 10 l/mincatalogue
Water per cycle 2.5 L litrescatalogue
Water pressure min 2-4 bar (28-56 psi)catalogue
THE WORKING VIEW

Why this commercial dishwasher earns its place

The DC OXG50A IS D Optima Glasswasher is engineered for the hard graft of service—pulling clean, bright glasses without spotting, streaking or film. It's a frontloader at 500×500mm, small enough to fit galley bars and tight bottle-storage setups.

The machine is insulated like a fridge: double-skinned panels, insulated boiler, hermetic door seal. That means consistent wash and rinse temperatures without energy waste, even through long services. Four adjustable cycles let you dial in light polish to heavy carbonised glass; the ECO cycle cuts running costs without cutting clean. A self-clean cycle keeps the machine itself fresh between services—no acid clean needed. The integral water softener prevents limescale, spotting and film, especially critical if your tap water is hard.

Control is intuitive: TFT touch screen, multifunction start button, colour status light. Temperature readouts appear in real time. Information and fault logs live on the display; engineer diagnostic mode troubleshoots problems without mystery calls. The quick-release wash and rinse arms come out in seconds for cleaning or inspection. Moulded hydrodynamic basket slides and the partial-drain-before-rinse cycle mean glasses load and unload fast, and rinsing is thorough without waterlogging the basket.

BEFORE YOU BUY

Questions, answered straight

Two glass baskets load either water glasses or wine glasses efficiently. Exact racks per hour depends on your glass type, washing discipline and cycle choice. Use the glasswasher payback calculator to model your peak-hour throughput and confirm the machine pays for itself in time saved.

No. The integral softener removes hardness so spotting and film don't appear, and limescale won't build up inside the boiler or pipework. If your water is exceptionally hard or soft, ring 01792 732702 to confirm settings during install.

The frontloading 500×500mm format fits galley bar spaces and tight corners. Check your space against a 500mm width and standard counter depth. The break tank is external and small—we can advise on placement during spec. Ring 01792 732702 with your bar layout if you want certainty.

Chemical dosing adjusts from the TFT control panel. Set it once at install and the peristaltic pump delivers the right amount every cycle—no guessing, no waste. Thermolock standby keeps the boiler warm between shifts without power spikes.

The self-clean cycle runs water through the machine at temperature, flushing accumulated deposits. It keeps the machine fresh between services without chemicals. A proper acid descale (every 6 months typically, depending on water) still makes sense for deep cleaning, but the self-clean cuts the frequency and keeps daily running smooth.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

DC OXG50A IS D Optima Glasswashers – frontloading 500×500 Product Data

Dimensions (W×D×H) 600 × 600 × 725 mm
Power supply 30 amp
Basket size 500×500
Capacity (dishes/glasses) 30
Cycle times 120 180 240 480 Eco Cycle
Usable wash height 300 mm
Wash tank capacity 12 L
Boiler 5.5 L
Water consumption 2.5 L
Wash element 2 kW
Rinse element 4.5 kW
Total load 6.6 kW
Double skinned Yes
Counter-balanced door Yes
Filters 2
Supplied baskets/racks 2
Min. flow rate 10 l/min
Min. water pressure 2-4 bar (28-56 psi)
If you have any questions about the DC OXG50A IS D Optima Glasswashers – frontloading 500×500 then please get in touch.
