TEFCOLD UC5360 Low Height Gastronorm Counter

£1,644.00

+vat

Brand:

SKU: 22574

Energy Arrow

Product summary

  • Fully automatic
  • Fan assisted cooling
  • Low height
  • Adjustable feet
  • Digital controller and temperature display
  • High quality catering grade 304 stainless steel
  • Replaceable drawer gasket
  • GN1/1 Drawers

Product description

The UC Low Height Gastronorm Counters offer practical storage with a durable countertop. With drawer options from 4 to 8 enhance kitchen efficiency to fit seamlessly into various spaces and reduce costs. With a digital controller and temperature display. The automatic defrost system prevents ice buildup. Made from 304 stainless steel, these are durable and promote hygiene. Replaceable door gaskets ensure a tight seal, enhancing energy efficiency.

The TEFCOLD UC5360 is a low-height stainless steel gastronorm counter fridge running at +2 to +8 °C with ventilated cooling, R600a refrigerant, automatic defrost and a 13A supply, measuring 1795 × 700 × 680 mm.

SPECIFICATION 37 facts · tap for all External W × D × H1795 x 700 x 680 mmWidth1795 mmDepth700 mmGross / net weight135 / 125 kgGross weight135 kgVoltage / frequency220-240/50 V/Hz

Identity6

Brand TEFCOLDsite
GTIN / EAN 5708181360238site
Product code 22574site
Sub title Low Height Gastronorm Countercatalogue
Type Drawer Fridgescatalogue
Warranty 2 year parts & 1 year labour warranty. Exclusions apply (see terms and conditions) – addcatalogue

Size & weight10

Depth 700 mmsite
External (W×D×H) 1795 × 700 × 680 mmcatalogue
External W × D × H 1795 x 700 x 680 mmsite
Gross / net weight 135 / 125 kgsite
Gross weight 135 kgcatalogue
Height 680 mmsite
Internal W × D × H mmsite
Packed (W×D×H) 1830 × 750 × 720 mmcatalogue
Packed W × D × H 1830 x 750 x 720 mmsite
Width 1795 mmsite

Performance9

Climate class 4site
Cooling type Ventilatedsite
Defrost type Automaticsite
Max ambient 30 °Ccatalogue
Maximum ambient +30°C, 55% RHsite
Refrigerant R600asite
Refrigerant charge 85 gsite
Temperature range +2 to +8site
Thermometer Yessite

Power & energy6

Annual energy consumption 916 kWh/yearsite
Energy consumption 251 kWh/24hsite
Energy efficiency index 42.8 %site
Input power 300 Wsite
Noise level 42 dB(A)site
Voltage / frequency 220-240/50 V/Hzsite

Build & fittings1

Exterior finish Stainless steelsite

Other stated facts1

Energy class Ccatalogue
THE WORKING VIEW

Why this drawer fridge earns its place

The UC5360 is a low-height gastronorm counter fridge built to give you chilled storage where headroom is tight. With a stainless steel exterior and interior, it sits under a low pass or worktop and puts cold stock within reach of the prep line. The low-profile design is the point: a full-length run of refrigeration that clears surfaces and shelving above it.

It holds +2 to +8 °C with ventilated cooling, which keeps temperature even across the cabinet, and uses R600a refrigerant with automatic defrost. It carries a climate class 4 rating, so it holds temperature in warm kitchens, and it is quiet at 42 dB — low enough to sit near front-of-house prep. Rated energy class C at 916 kWh a year, it costs about £229 a year at 25p/kWh.

The cabinet measures 1795 × 700 × 680 mm and ships packed at 1830 × 750 × 720 mm, so check your worktop clearance and access route first — gross weight is 135 kg. It runs from a standard 13A supply at 220-240V 50Hz, drawing 300W, with an 85 g charge of R600a.

BEFORE YOU BUY

Questions, answered straight

The cabinet is 680 mm high with a 1795 × 700 mm footprint, and ships packed at 1830 × 750 × 720 mm. Measure your worktop clearance and access route before delivery.

It runs at +2 to +8 °C with ventilated cooling for even distribution across the cabinet, and carries a climate class 4 rating for warm kitchens.

It is energy class C and rated at 916 kWh a year, which is about £229 a year at 25p/kWh. Your actual figure depends on tariff, ambient temperature and door use.

Measured noise output is 42 dB, which is low enough to sit near a customer-facing prep area rather than tucked away in the back.

No. It runs from a standard 13A supply at 220-240V 50Hz and draws 300W, so it connects to an ordinary commercial socket.

It uses R600a with an 85 g charge and automatic defrost. For servicing, call Craven Cooling on 01792 732702.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

Dimensions

Internal Dimension (WxDxH): mm
External Dimension (WxDxH): 1795 x 700 x 680 mm
Packed Dimension (WxDxH): 1830 x 750 x 720 mm

Cooling and Functions

Type of Cooling: Ventilated
Type of Defrost: Automatic
Refrigerant: R600a
Refrigerant Charge: 85 g
Thermometer: Yes

Power and Consumption

Energy Consumption: 251 kWh/24h
Temperature Range: +2 to +8 °C
Annual Energy Consumption: 916 kWh/year m³
EEI: 42.8 %
Input Power: 300 W
Voltage / Frequency: 220-240/50 V/Hz
Noise Level: 42 dB(A)

Measures and Content

Temperature Range: +2 to +8 °C
Climate Class: 4
Gross / Net Weight: 135 / 125 kg
Gross / Net Volume: / 138 l
Max Ambient: +30°C, 55% RH

Design and Material

Exterior Finish: Stainless steel
Interior Finish: Stainless steel
If you have any questions about the TEFCOLD UC5360 Low Height Gastronorm Counter then please get in touch.
