Polar U-Series 1.5 x 1.2m Integral Walk In Cold Room Brown DS481-CBN

£5,390.62

+vat

Availability: 999 in stock

- +

Brand:

SKU: DS481-CBN

Product summary

1.5 x 1.2m. Capacity: 2843 Ltr. Chiller

Product description

Integral Walk In Room designed to work in 43°C. Internal light & 13amp Plug. 2 Year Full Warranty, 5 Year Panel guarantee.

Operates effectively at high ambient temperatures up to 43°C
Easy clean internal coving and wall panels
Internal light with 18W sealed light fitting
Intuitive digital temperature control and display
Non-slip aluminium floor
High/low temperature alarm
Easy-clean door seal/gasket
Wall panels constructed from 0.6mm thick galvanised steel finished with 200 microns of food safe white plastic
Weather and humidity resistant front control panel
Highly efficient 80mm panel insulation with dovetail joints to prevent air leakage
Lockable self closing door shuts flush against door panels for security and efficiency
7 day warranty cover

Downloads

SPECIFICATION 30 facts · tap for all Width1500 mmDepth1200 mmHeight2200 mmGross weight350 kgVoltage230VTemperature range+2 to +5 °C

Identity7

Brand Polarsite
GTIN / EAN 5.05098E+12catalogue
Product code DS481-CBNsite
Range / series U Seriescatalogue
Seo name Polar Integral Walk In Cold Room Browncatalogue
Type Fridge Roomscatalogue
Warranty 2 Years Parts & Labourcatalogue

Size & weight6

Depth 1200 mmcatalogue
External (W×D×H) 2200 × 1500 × 1200 mmcatalogue
Gross weight 350 kgcatalogue
Height 2200 mmcatalogue
Internal (W×D×H) 2037 × 1280 × 980 mmcatalogue
Width 1500 mmsite

Capacity5

Capacity 2843Ltrcatalogue
Door type Hingedcatalogue
Doors 1catalogue
Gross volume 2843 litrescatalogue
Product capacity 2843catalogue

Performance3

Cooling Fan Assistcatalogue
Refrigerant R449A / 1500gcatalogue
Temperature range +2 to +5 °Ccatalogue

Power & energy3

Fuel type Single Phasecatalogue
Rated input 1800 Wcatalogue
Voltage 230Vcatalogue

Build & fittings5

Colour Browncatalogue
Colour code Vandyke Browncatalogue
Doorocation Frontcatalogue
Insulation 80 mmcatalogue
Material Galvanised Steel/ Aluminium & Plasticcatalogue

Other stated facts1

Plug notice Yescatalogue
THE WORKING VIEW

Why this fridge room earns its place

The DS481-CBN is a walk-in cold room from Polar's U-Series, built to give a busy kitchen a dedicated space for 2,843 litres of chilled stock instead of a row of upright fridges. At 1.5 by 1.2 m (external) it suits back-of-house corners, cellars and prep areas where floor space is at a premium but shelved chilled capacity still has to grow with the operation.

Because it is an integral unit, the refrigeration is built into the room itself — there is no separate condensing unit to site elsewhere, so it arrives as a single, self-contained cold-storage solution you power up and load. The 80mm insulation and integral R449A cooling system hold it at a steady +2 to +5 °C. Walk-in access lets staff wheel in trolleys, rotate stock by date and pick orders without unstacking, which keeps a chilled section organised through service. It carries a 2-year parts and labour warranty plus a 5-year panel guarantee.

Plan the install around the 1.5 by 1.2 m footprint, the 350kg loaded weight and the route to the room's final position, checking doorways and corridors before delivery. The room is finished in a brown exterior and requires a level floor and 230V electrical connection. Full capacity and refrigerant details are in the spec table above, and our team can confirm anything not listed before you order.

BEFORE YOU BUY

Questions, answered straight

No. This is an integral room, so the refrigeration is built in — there is no remote plant to site and no external pipework to run. It arrives as one self-contained unit you power up and load.

The room holds 2,843 litres of chilled storage. To match it to your menu and turnover, use our cold room sizing calculator, which takes your stock volume and works back to the room you need.

Plan around the 1.5 by 1.2 m footprint and measure doorways, corridors and the final siting position before delivery. Our team can talk access through with you if the route is tight.

It depends on your volume and floor space. A walk-in gives you one organised chilled room rather than several separate cabinets; our cold room vs uprights comparator weighs the two for your numbers.

Running cost depends on ambient temperature, door use and how hard the room is worked. The 80mm insulation and integral plant are sized for efficient chilling in UK conditions; our finance calculator shows the monthly and weekly cost over a five-year term to help you budget.

Our service team can advise on installation, planned servicing and cover for the room. Call 01792 732702 to talk it through before or after you order.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

Polar U-Series 1.5 x 1.2m Integral Walk In Cold Room Brown DS481-CBN Product Data

Brand Polar
Type Fridge Rooms
Range U Series
Dimensions 2200(H) x 1500(W) x 1200(D)mm
Capacity 2843Ltr
Material Galvanised Steel/ Aluminium & Plastic
Colour / Finish Brown
Temperature Range 2°C to 5°C
Refrigerant R449A / 1500g
Cooling Fan Assist
Number of Doors 1
Power 13A Plug Fitted – Single Phase
Voltage 230V
Fuel / Supply Single Phase
Warranty 2 Years Parts & Labour
Weight 350kg
If you have any questions about the Polar U-Series 1.5 x 1.2m Integral Walk In Cold Room Brown DS481-CBN then please get in touch.
