TEFCOLD TFW100-S Wine Cooler

£419.00

+vat

Brand:

SKU: 34135

Energy Arrow

Product summary

  • Single temperature zone
  • Stainless steel door frame and handle
  • Energy efficient cooling system
  • Low noise level
  • LED interior light with switch
  • Reversible glass door
  • High/low temperature alarm
  • Wooden shelves

Product description

Wine cooler with stainless steel door frame

The TFW-S range of stainless steel wine display coolers provides a stylish solution for showcasing and storing wine bottles. With a sleek black interior, stainless steel door frame and handle, soft LED lighting, and slide-out wooden shelves, this cooler offers an elegant design. Its modern cooling system is highly efficient, minimising noise, heat, and energy consumption.

The TEFCOLD TFW100-S is a compact under-counter wine cooler that holds +5 to +18 °C behind a single hinged glass door, with an 80-litre gross / 57-litre net capacity, a black finish, energy class F and R600a refrigerant, running on a standard 13 A supply.

SPECIFICATION 47 facts · tap for all External W × D × H295 x 570 x 860 mmWidth295 mmDepth570 mmGross / net weight31 / 26 kgGross weight31 kgVoltage / frequency220-240/50 V/Hz

Identity6

Brand TEFCOLDsite
GTIN / EAN 5708181995133site
Product code 34135site
Sub title Wine Coolercatalogue
Type Under Counter Wine Coolerscatalogue
Warranty 2 year parts & 1 year labour warranty. Exclusions apply (see terms and conditions) – addcatalogue

Size & weight11

Depth 570 mmsite
External (W×D×H) 295 × 570 × 860 mmcatalogue
External W × D × H 295 x 570 x 860 mmsite
Gross / net weight 31 / 26 kgsite
Gross weight 31 kgcatalogue
Height 860 mmsite
Internal (W×D×H) 227 × 492 × 658 mmcatalogue
Internal W × D × H 227 x 492 x 658 mmsite
Packed (W×D×H) 340 × 650 × 920 mmcatalogue
Packed W × D × H 340 x 650 x 920 mmsite
Width 295 mmsite

Capacity4

750ml wine bottles 19site
Doors 1catalogue
Gross volume 80 litrescatalogue
Shelves 6catalogue

Performance10

Climate class 4site
Controller Electronicsite
Cooling type Fan assistedsite
Defrost type Automaticsite
Max ambient 30 °Ccatalogue
Maximum ambient +30°C, 55% RHsite
Refrigerant R600asite
Refrigerant charge 25 gsite
Temperature range +5 to +18site
Thermometer Yessite

Power & energy6

Annual energy consumption 98 kWh/yearsite
Energy consumption 0.27 kWh/24hsite
Energy efficiency index 124 %site
Input power 90 Wsite
Noise level 40 dB(A)site
Voltage / frequency 220-240/50 V/Hzsite

Build & fittings5

Exterior finish Blacksite
Feet / legs 4 adjustable feetsite
Interior light LEDsite
Lock Nosite
Max load per shelf 35site

Other stated facts1

Energy class Fcatalogue
THE WORKING VIEW

Why this under counter wine cooler earns its place

The TFW100-S is a slim under-counter wine cooler with a single hinged glass door and a black exterior, built to store and show bottles rather than hide them. Its 80-litre gross volume gives 57 litres of usable space, and the black ABS interior with a glass front keeps a tidy, low-profile look wherever it sits behind a bar or in a back-of-house prep area.

The cabinet runs a wide +5 to +18 °C band, so it can be set for reds, whites or a mixed rack, with automatic defrost and an electronic controller doing the day-to-day work. It draws 90 W, sits in energy class F and runs at 40 dB, quiet enough for a customer-facing spot, at a running cost of about £25 a year at 25p/kWh.

Internally it measures 227 × 492 × 658 mm (W×D×H) and ships at 340 × 650 × 920 mm, weighing 31 kg gross and 26 kg net, so it is a one-person install through a standard doorway. It uses R600a refrigerant with a 25 g charge and connects to an ordinary 13 A, 220–240 V socket, so no special electrics are required.

BEFORE YOU BUY

Questions, answered straight

It holds a +5 to +18 °C band, wide enough to set for reds, whites or a mixed rack. Defrost is automatic and the set point is held by an electronic controller.

Gross volume is 80 litres with 57 litres of usable net capacity behind the single hinged glass door.

It is rated at 98.6 kWh a year, about £25 a year at 25p/kWh, drawing 90 W. It sits in energy class F.

The interior measures 227 × 492 × 658 mm (W×D×H) and it ships at 340 × 650 × 920 mm, weighing 31 kg gross. It runs off a standard 13 A, 220–240 V socket.

It uses R600a with a 25 g charge, a natural hydrocarbon refrigerant, paired with automatic defrost.

Yes. Craven Cooling installs and services the range — call 01792 732702 to book a visit or ask about a maintenance plan.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

Dimensions

Internal Dimension (WxDxH): 227 x 492 x 658 mm
External Dimension (WxDxH): 295 x 570 x 860 mm
Packed Dimension (WxDxH): 340 x 650 x 920 mm

Cooling and Functions

Type of Controller: Electronic
Type of Cooling: Fan assisted
Type of Defrost: Automatic
Refrigerant: R600a
Refrigerant Charge: 25 g
Thermometer: Yes

Power and Consumption

Energy Consumption: 0.27 kWh/24h
Temperature Range: +5 to +18 °C
Annual Energy Consumption: 98 kWh/year m³
EEI: 124 %
Input Power: 90 W
Voltage / Frequency: 220-240/50 V/Hz
Noise Level: 40 dB(A)

Measures and Content

Wine Bottles 750 ml: 19 pcs
Temperature Range: +5 to +18 °C
Climate Class: 4
Gross / Net Weight: 31 / 26 kg
Gross / Net Volume: 80 / 57 l
Max Ambient: +30°C, 55% RH

Design and Material

Door Reversible: Yes
Max load on Shelves: 35 kg/m²
Feet / Legs: 4 adjustable feet
Exterior Finish: Black
Interior Finish: Black
Interior Light: LED
Lock: No
If you have any questions about the TEFCOLD TFW100-S Wine Cooler then please get in touch.
