TEFCOLD MCX150M Multideck with shutter

£4,270.00

+vat

Brand:

SKU: 45600

Energy Arrow

Product summary

  • Ideal for impulse buys and promotions
  • Lockable security shutter
  • Ventilated cooling
  • Adjustable shelves
  • Fully automatic
  • Castors with brake
  • LED interior light with switch
  • Digital controller and temperature display
  • Ticket strip included

Product description

The TEFCOLD MCX Range is an open front stainless steel multideck, ideal for grab and go and impulse purchases. It can be set to temperature suitable for drink, dairy or fresh meat to suit your requirements. The MCX also benefits from a rigid lockable security shutter to prevent access to product when food is not being served, it is also supplied on lockable castors to allow movement of the cabinet. This allows the unit to be more versatile as to where it can be utilised to maximise sales.

The MCX Range is is the perfect solution for a wide range of establishments such as cafeterias, hotels, schools, colleges, and university canteens. It caters to the need for a refrigerated multideck during service while also prioritising product security during non-service periods. This feature becomes especially valuable in environments where customers, staff, or students may still have access to the unit.

MCX Range is an open front, stainless steel multideck, ideal for grab and go and impulse purchases. The unit benefits from a rigid lockable security shutter to prevent access to product when food is not being served and lockable castors. The cabinet is the perfect solution for a range of sites such as cafeterias, hotels, colleges, and university canteens. It fulfils the need for multidecks during service while also prioritising product security during non-service periods.

The TEFCOLD MCX150M is a 1512 mm-wide open-fronted multideck holding -1 to +5 °C across 1.72 m² of display on four adjustable shelves, running from a standard 13 A supply on R290 refrigerant with automatic defrost, at about £1693 a year at 25p/kWh.

SPECIFICATION 43 facts · tap for all External W × D × H1512 x 740 x 1994 mmWidth1512 mmDepth740 mmGross / net weight325 / 255 kgGross weight325 kgVoltage / frequency220-240/50 V/Hz

Identity6

Brand TEFCOLDsite
GTIN / EAN 5708181722418site
Product code 45600site
Sub title Multideck with shuttercatalogue
Type Open Fronted Multideck Fridgescatalogue
Warranty 2 year parts & 1 year labour warranty. Exclusions apply (see terms and conditions) – addcatalogue

Size & weight11

Depth 740 mmsite
External (W×D×H) 1512 × 740 × 1994 mmcatalogue
External W × D × H 1512 x 740 x 1994 mmsite
Gross / net weight 325 / 255 kgsite
Gross weight 325 kgcatalogue
Height 1994 mmsite
Internal (W×D×H) 1450 × 436 × 1250 mmcatalogue
Internal W × D × H 1450 x 436 x 1250 mmsite
Packed (W×D×H) 1600 × 790 × 2150 mmcatalogue
Packed W × D × H 1600 x 790 x 2150 mmsite
Width 1512 mmsite

Capacity3

Display area 1.72 m²site
Gross volume 790 litrescatalogue
Shelves 4catalogue

Performance9

Climate class 3site
Controller Electronicsite
Defrost type Automaticsite
Max ambient 25 °Ccatalogue
Maximum ambient +25°C, 60% RHsite
Refrigerant R290site
Refrigerant charge 2 x 150 gsite
Temperature range -1 to +5site
Thermometer Yessite

Power & energy6

Annual energy consumption 6770 kWh/yearsite
Energy consumption 18.55 kWh/24hsite
Energy efficiency index 68.1 %site
Input power 1210 Wsite
Noise level 61 dB(A)site
Voltage / frequency 220-240/50 V/Hzsite

Build & fittings3

Castors Castorssite
Exterior finish SS304site
Interior light LED as optionsite

Other stated facts1

Energy class Fcatalogue
THE WORKING VIEW

Why this open fronted multideck fridge earns its place

The TEFCOLD MCX150M is an open-fronted multideck display fridge built to put chilled stock in front of customers and keep it moving. Its 1.72 m² of vertical display spreads across four adjustable shelves, so grab-and-go lines — chilled drinks, dairy, packaged meat, deli and prepared food — sit at eye level and within reach. The SS304 stainless steel interior and exterior stand up to busy retail traffic and repeated daily cleaning.

The cabinet holds -1 to +5 °C, a band suited to chilled retail stock, and clears frost on an automatic cycle so staff don't need to intervene. An electronic controller governs the temperature, and the cabinet is rated climate class 3 to hold that band on a warm, busy shop floor. The F energy class and 6770 kWh a year work out at about £1693 a year at 25p/kWh, with running noise rated at 61 dB.

The cabinet measures 1512 × 740 × 1994 mm (W×D×H) and runs from a standard 13 A supply on 220-240 V, drawing 1210 W. Net weight is 255 kg (325 kg gross), so plan delivery access and a firm, level floor. For doorway clearance the packed unit is 1600 × 790 × 2150 mm — measure your narrowest opening first. Refrigerant is R290 (150 g charge), a low-GWP hydrocarbon, and capacity is 790 litres gross, 670 litres net.

BEFORE YOU BUY

Questions, answered straight

The cabinet is 1512 mm wide and the packed unit measures 1600 × 790 × 2150 mm. Measure your narrowest doorway, corridor and any lift against the packed dimensions, and clear the delivery route before the day.

It carries an F energy class and uses 6770 kWh a year, about £1693 a year at 25p/kWh. Your actual figure moves with your tariff and how hard the shop floor works the cabinet.

The MCX150M runs from -1 to +5 °C, suited to chilled retail stock such as drinks, dairy, packaged meat and prepared food. An electronic controller and automatic defrost hold the band steady without staff intervention.

A standard 13 A supply on 220-240 V, so it runs from a normal socket circuit, drawing 1210 W. Give it a dedicated socket rather than sharing an already-loaded ring.

Gross volume is 790 litres and net is 670 litres across four adjustable shelves, with 1.72 m² of display area facing the aisle. The shelves adjust to suit tall bottles or shorter packaged lines.

Yes. Craven Cooling services and repairs the refrigeration we sell — call the team on 01792 732702. The MCX150M uses R290 refrigerant and an electronic controller, both standard for our engineers.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

Dimensions

Internal Dimension (WxDxH): 1450 x 436 x 1250 mm
External Dimension (WxDxH): 1512 x 740 x 1994 mm
Packed Dimension (WxDxH): 1600 x 790 x 2150 mm

Cooling and Functions

Type of Controller: Electronic
Type of Defrost: Automatic
Refrigerant: R290
Refrigerant Charge: 2 x 150 g
Thermometer: Yes

Power and Consumption

Energy Consumption: 18.55 kWh/24h
Temperature Range: -1 to +5 °C
Annual Energy Consumption: 6770 kWh/year m³
EEI: 68.1 %
Input Power: 1210 W
Voltage / Frequency: 220-240/50 V/Hz
Noise Level: 61 dB(A)

Measures and Content

Temperature Range: -1 to +5 °C
Climate Class: 3
Gross / Net Weight: 325 / 255 kg
Gross / Net Volume: 790 / 670 l
Max Ambient: +25°C, 60% RH
Total Display Area: 1.72 m² m²

Design and Material

Shelf Color: Stainless steel
Castors: Castors
Exterior Finish: SS304
Interior Finish: SS304
Interior Light: LED as option
If you have any questions about the TEFCOLD MCX150M Multideck with shutter then please get in touch.
