TEFCOLD Galaxy+ GP14FGD SS Multideck With Doors

£3,840.00

+vat

- +

Brand:

SKU: 46464

Energy Arrow

Product summary

  • Fully automatic, fan assisted cooling
  • Internal vertical & horizontal LED light
  • Solid 40 mm endwalls with mirrored interior
  • Frameless hinged double glazed self closing doors
  • 5 Adjustable shelves, max weight 160kg/sq metre
  • Shelves can be flat or angled to 7° or 14°
  • EPOS Ticket strips & shelf risers
  • Suitable for fresh meat
  • Can be multiplexed with kit (POA)
  • Door widths match on G14 & G26 & on G10 & G20
  • Delivered without handles and rear stand-offs attached, will fit through 750mm door

Product description

Mirror Stainless Steel Multideck With Doors

The TEFCOLD Galaxy+ FGD (Full Glass Door) range, finished in mirror stainless steel: : part of our popular assortment of plug-in multidecks. We’ve combined an expanded display area and optimised cabinet efficiency with frameless, full-vision glass doors, offering enhanced product visibility that captures customers’ attention. The ultra-low front and slim top canopy provide an extra 100mm of internal height, accommodating up to 5 shelves (plus base) as standard. With a standard depth, the unit fits through most doors for easy installation, yet has deep shelves for maximum stock capacity. Thanks to the carefully designed refrigeration system and optimal airflow throughout the cabinets, all sizes in this range are rated B for energy efficiency. Each unit comes with heavy-duty adjustable shelves that can be tilted if needed, EPOS ticket strips and shelf risers as standard. Optional extras include glass end-walls and multiplexing kits.

The TEFCOLD Galaxy+ GP14FGD SS is a 1330 mm-wide stainless-steel glass-door multideck holding 629 litres across five adjustable shelves behind two hinged glass doors, running at -1 to +5 °C on R290 refrigerant with a class B rating and about £334 a year in electricity at 25p/kWh.

SPECIFICATION 47 facts · tap for all External W × D × H1330 x 750 x 2005 mmWidth1330 mmDepth750 mmGross / net weight369 / 285 kgGross weight369 kgVoltage / frequency220-240/50 V/Hz

Identity6

Brand TEFCOLDsite
GTIN / EAN 5708181726201site
Product code 46464site
Sub title Multideck With Doorscatalogue
Type Glass Door Multideck Fridgescatalogue
Warranty 2 year parts & 1 year labour warranty. Exclusions apply (see terms and conditions) – addcatalogue

Size & weight11

Depth 750 mmsite
External (W×D×H) 1330 × 750 × 2005 mmcatalogue
External W × D × H 1330 x 750 x 2005 mmsite
Gross / net weight 369 / 285 kgsite
Gross weight 369 kgcatalogue
Height 2005 mmsite
Internal (W×D×H) 1250 × 544 × 1562 mmcatalogue
Internal W × D × H 1250 x 544 x 1562 mmsite
Packed (W×D×H) 1350 × 770 × 2320 mmcatalogue
Packed W × D × H 1350 x 770 x 2320 mmsite
Width 1330 mmsite

Capacity4

Display area 1.91 m²site
Doors 2catalogue
Gross volume 1443 litrescatalogue
Shelves 5catalogue

Performance9

Climate class 3site
Controller Electronicsite
Defrost type Automaticsite
Max ambient 25 °Ccatalogue
Maximum ambient +25°C, 60% RHsite
Refrigerant R290site
Refrigerant charge 140 gsite
Temperature range -1 to +5site
Thermometer Yessite

Power & energy6

Annual energy consumption 1336 kWh/yearsite
Energy consumption 3.66 kWh/24hsite
Energy efficiency index 12 %site
Input power 308 Wsite
Noise level 55 dB(A)site
Voltage / frequency 220-240/50 V/Hzsite

Build & fittings6

Exterior finish Mirror Stainless Steelsite
Feet / legs 4 adjustable feetsite
Interior light LEDsite
Max load per shelf 160site
Reversible doors Nosite
Shelf dimensions 1250x400mmsite

Other stated facts1

Energy class Bcatalogue
THE WORKING VIEW

Why this glass door multideck fridge earns its place

The TEFCOLD Galaxy+ GP14FGD SS is a compact full-height glass-door multideck built to merchandise chilled stock behind two hinged glass doors. It presents 1.91 m² of display across five adjustable shelves, giving 629 litres of usable net capacity from a 1443-litre gross cabinet. The mirror stainless-steel finish, inside and out, suits front-of-house and premium retail settings where a wide cabinet won't fit.

It holds a -1 to +5 °C band suited to pre-packed chilled food and drink, with automatic defrost and an electronic controller keeping the temperature steady without manual intervention. Rated energy class B with an energy efficiency index of 12.0%, it draws 1335.9 kWh a year — about £334 a year in electricity at 25p/kWh. Running noise is 55 dB, and it is built to climate class 3.

The cabinet measures 1330 mm wide, 750 mm deep and 2040 mm high, and ships at 1350 × 770 × 2320 mm packed, so check your access route against the packed height before delivery. It weighs 285 kg net (369 kg gross), runs on a 220-240 V/50 Hz supply and draws 13 A, so a standard 13 A socket carries it. Cooling uses R290 hydrocarbon refrigerant with a 140 g charge.

BEFORE YOU BUY

Questions, answered straight

The cabinet is 1330 mm wide, 750 mm deep and 2040 mm high, and ships at 1350 × 770 × 2320 mm packed. Measure your access route and doorways against the packed height before delivery; at 369 kg gross it needs clear, level access.

It runs on a 220-240 V/50 Hz supply and draws 13 A, so a standard 13 A socket carries it. No special electrical installation is required beyond a dedicated point.

It's rated energy class B and draws 1335.9 kWh a year, roughly £334 a year in electricity at 25p/kWh. The two hinged glass doors help hold the cold in compared with an open front.

It runs at -1 to +5 °C, suited to pre-packed chilled food and drink. Automatic defrost and an electronic controller hold the band steady without manual intervention.

Net capacity is 629 litres from a 1443-litre gross cabinet, across five adjustable shelves and 1.91 m² of display area.

Yes — Craven Cooling services the cabinets it supplies. Call the team on 01792 732702 to arrange servicing or discuss installation.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

Dimensions

Internal Dimension (WxDxH): 1250 x 544 x 1562 mm
External Dimension (WxDxH): 1330 x 750 x 2005 mm
Packed Dimension (WxDxH): 1350 x 770 x 2320 mm

Cooling and Functions

Type of Controller: Electronic
Type of Defrost: Automatic
Refrigerant: R290
Refrigerant Charge: 140 g
Thermometer: Yes

Power and Consumption

Energy Consumption: 3.66 kWh/24h
Temperature Range: -1 to +5 °C
Annual Energy Consumption: 1336 kWh/year m³
EEI: 12 %
Input Power: 308 W
Voltage / Frequency: 220-240/50 V/Hz
Noise Level: 55 dB(A)

Measures and Content

Temperature Range: -1 to +5 °C
Climate Class: 3
Gross / Net Weight: 369 / 285 kg
Gross / Net Volume: 1443 / 629 l
Max Ambient: +25°C, 60% RH
Total Display Area: 1.91 m² m²

Design and Material

Door Reversible: No
Shelf Color: Stainless steel
Shelf Dimensions: 1250x400mm
Max load on Shelves: 160 kg/m²
Feet / Legs: 4 adjustable feet
Exterior Finish: Mirror Stainless Steel
Interior Finish: Mirror Stainless Steel
Interior Light: LED
If you have any questions about the TEFCOLD Galaxy+ GP14FGD SS Multideck With Doors then please get in touch.
