Framec SUPER SUNNY14 Wall Site Multideck With Doors

£3,122.00

+vat

- +

Brand:

SKU: 19309

Energy Arrow

Product summary

  • Fully automatic
  • Fan assisted cooling
  • Lock
  • Adjustable shelves
  • Adjustable feet
  • LED interior light with switch
  • Digital controller and temperature display
  • Ticket strip included
  • Self closing doors with stay open feature for ease of loading
  • Low maintenance spiral condensor for increased efficiency

Product description

The Super Sunny is a sliding door multideck with a generous 5 tier display. Curved corners give the unit a sleek look, sliding doors help save energy while maintaining the visual appeal of a large display. Fully automatic and fan assisted, it ensures even cooling throughout the whole cabinet for drinks and sandwiches as well as milk and other dairy products.

The Framec SUPER SUNNY14 is a 1335 mm wide glass door multideck with 825 litres of net chilled capacity and 2.03 m² of display area at 0 to +8 °C, built for convenience stores, farm shops and supermarkets that need more display than a metre-wide cabinet gives.

SPECIFICATION 45 facts · tap for all External W × D × H1335 x 737 x 1987 mmWidth1335 mmDepth737 mmGross / net weight275 / 247 kgGross weight275 kgVoltage / frequency220-240/50 V/Hz

Identity6

Brand Framecsite
GTIN / EAN 5708181607227site
Product code 19309site
Sub title Wall Site Multideck With Doorscatalogue
Type Glass Door Multideck Fridgescatalogue
Warranty 2 year parts & 1 year labour warranty. Exclusions apply (see terms and conditions) – addcatalogue

Size & weight11

Depth 737 mmsite
External (W×D×H) 1335 × 737 × 1987 mmcatalogue
External W × D × H 1335 x 737 x 1987 mmsite
Gross / net weight 275 / 247 kgsite
Gross weight 275 kgcatalogue
Height 1987 mmsite
Internal (W×D×H) 1295 × 480 × 1380 mmcatalogue
Internal W × D × H 1295 x 480 x 1380 mmsite
Packed (W×D×H) 1440 × 760 × 2150 mmcatalogue
Packed W × D × H 1440 x 760 x 2150 mmsite
Width 1335 mmsite

Capacity3

Display area 2.03 m²site
Doors 2catalogue
Gross volume 940 litrescatalogue

Performance9

Climate class 4site
Controller Electronicsite
Defrost type Automaticsite
Max ambient 30 °Ccatalogue
Maximum ambient +30°C, 55% RHsite
Refrigerant R290site
Refrigerant charge 140 gsite
Temperature range 0 to +8site
Thermometer Yessite

Power & energy6

Annual energy consumption 3266 kWh/yearsite
Energy consumption 8.95 kWh/24hsite
Energy efficiency index 26 %site
Input power 930 Wsite
Noise level 55 dB(A)site
Voltage / frequency 220-240/50 V/Hzsite

Build & fittings5

Exterior finish Greysite
Feet / legs 4 adjustable feetsite
Interior light LEDsite
Max load per shelf 100site
Reversible doors Nosite

Other stated facts1

Energy class Ccatalogue
THE WORKING VIEW

Why this glass door multideck fridge earns its place

The SUPER SUNNY14 is a wall site multideck with doors. It carries 825 litres net (940 litres gross) and 2.03 m² of display area behind two self-closing sliding glass doors, in a cabinet 1335 mm wide. The exterior is grey, the interior white, so stock stands out against the back panel. Because the doors slide rather than swing, the full glass frontage stays visible from across the floor without anything projecting into the walkway.

The operating band is 0 to +8 °C under electronic control, with automatic defrost — no manual routine. It is rated at 55 dB, and climate class 4 means it is built for warm, busy sales floors rather than ideal conditions. On energy it holds a class C rating at 3,266.7 kWh a year, which works out at about £817 a year at 25p/kWh.

External dimensions are 1335 × 737 × 1987 mm, with a packed size of 1440 × 760 × 2150 mm — check corridor widths as well as ceiling heights on the route in. It weighs 247 kg unpacked, so settle the final siting before delivery. Supply is a standard 13 amp plug drawing 930 W at 220-240 V 50 Hz, and the refrigerant is R290 with a 140 g charge.

BEFORE YOU BUY

Questions, answered straight

The cabinet is 737 mm deep, so it passes standard openings on depth; the figures to check are its 1335 mm width on corridors and the 1440 × 760 × 2150 mm packed size against the delivery route and ceiling.

The operating range is 0 to +8 °C, so it can be set at the very bottom of the chilled band. Check the display temperature your product and local guidance call for against that 0 °C floor.

It is rated energy class C at 3,266.7 kWh a year — about £817 a year at 25p/kWh for 825 litres of doored chilled display.

A standard 13 amp plug. It draws 930 W from a 220-240 V 50 Hz supply, so there is no hard wiring or dedicated circuit work.

It is rated at 55 dB with an electronic controller managing the cabinet. Automatic defrost means there is no manual defrost disruption during trading.

It runs on R290 refrigerant with a 140 g charge and automatic defrost. Craven Cooling services what it sells — call 01792 732702 to arrange cover or book an engineer.
See it in our Swansea showroom

Compare kit side by side and discuss delivery with the Craven team.

Dimensions

Internal Dimension (WxDxH): 1295 x 480 x 1380 mm
External Dimension (WxDxH): 1335 x 737 x 1987 mm
Packed Dimension (WxDxH): 1440 x 760 x 2150 mm

Cooling and Functions

Type of Controller: Electronic
Type of Defrost: Automatic
Refrigerant: R290
Refrigerant Charge: 140 g
Thermometer: Yes

Power and Consumption

Energy Consumption: 8.95 kWh/24h
Temperature Range: 0 to +8 °C
Annual Energy Consumption: 3266 kWh/year m³
EEI: 26 %
Input Power: 930 W
Voltage / Frequency: 220-240/50 V/Hz
Noise Level: 55 dB(A)

Measures and Content

Temperature Range: 0 to +8 °C
Climate Class: 4
Gross / Net Weight: 275 / 247 kg
Gross / Net Volume: 940 / 825 l
Max Ambient: +30°C, 55% RH
Total Display Area: 2.03 m² m²

Design and Material

Door Reversible: No
Shelf Color: White
Max load on Shelves: 100 kg/m²
Feet / Legs: 4 adjustable feet
Exterior Finish: Grey
Interior Finish: Grey
Interior Light: LED
If you have any questions about the Framec SUPER SUNNY14 Wall Site Multideck With Doors then please get in touch.
