Why this triple door glass door fridge earns its place
Triple layered glass with glass heating
+vat
SKU: 7455.1925
Product summary
Size W/D/H (mm) x x
Product description
Triple layered glass with glass heating
The Combisteel NAP-1200 HT is a three-door black glass-door display refrigerator with heated glass doors, built to merchandise chilled drinks and grab-and-go stock on show in retail and food-service sites.\n\nThe NAP-1200 HT is a three-door upright display refrigerator finished in black, with full-height glazed fronts and heated glass doors. It is a merchandising cabinet spanning 1.6 metres wide and reaching 2.1 metres tall: the glazing puts chilled drinks, snacks and grab-and-go lines on show across three doors, so customers can see and reach stock for themselves. The black finish suits a front-of-shop display built to be seen as part of the interior.\n\nThe heated glass doors are the feature that sets this model apart: they keep the display glass clear and condensation-free during service, so the range stays visible and appetising through the doors throughout the day. It works as a self-service chiller at +2 to +10 °C, with the doors holding the cold while stock stays on show. The cabinet runs quietly at 48 dB and draws 0.8 kW, so it fits most electrical circuits without special provision. Automatic defrost means no manual de-icing cycles.\n\nPlan the delivery route and a level floor position before it arrives. The cabinet is 1.6 metres wide and 2.1 metres tall — measure your doorways and the wall run you have. It weighs 192 kg, so plan for several people and a clear, level route. Confirm the electrical supply with a qualified electrician: it needs 230 V and 0.8 kW capacity. Leave ventilation clearance around the cabinet once it’s sited. Craven Cooling can help plan the siting and install.
Downloads
Nothing matches that.
| Brand | CombiSteelcatalogue |
|---|---|
| GTIN / EAN | 7422242991930catalogue |
| Type | Triple Door Glass Door Fridgescatalogue |
| Depth | 600 mmsite |
|---|---|
| External (W×D×H) | 1600 × 600 × 2100 mmcatalogue |
| Gross / net weight | 192 kgsite |
| Gross weight | 152 kgcatalogue |
| Height | 2100 mmsite |
| Internal (W×D×H) | 1510 × 480 × 1855 mmcatalogue |
| Internal W × D × H | 1510x480x1855site |
| Width | 1600 mmsite |
| Capacity | – Ltrcatalogue |
|---|---|
| Shelves | 15catalogue |
| Controller | Digitalcatalogue |
|---|---|
| Cooling type | R 290site |
| Defrost type | Automaticsite |
| Max ambient | 3232 °Ccatalogue |
| Maximum ambient | 3232site |
| Temperature range | +2/+10site |
| Energy consumption | 0.8site |
|---|---|
| Frequency | 50 Hzcatalogue |
| Noise level | 4848site |
| Rated input | 800 Wcatalogue |
| Rated power | 0.8 kWcatalogue |
| Voltage | 230V / 50Hzcatalogue |
| Voltage / frequency | 23050site |
| Accessories | Triple layered glass with glass heatingcatalogue |
|---|---|
| Colour | Blackcatalogue |
| Doors | Left and right hingedsite |
| Exterior finish | Powder coated steelsite |
| Insulation | 45 mmcatalogue |
| Interior finish | Aluminiumsite |
| Interior light | Yes, LEDsite |
| Reversible doors | Nosite |
| Temperature display | Yes, digitalcatalogue |
| Energy (24h) | 14.9 kWh/24hcatalogue |
|---|---|
| Mobility | Yescatalogue |
Triple layered glass with glass heating
Compare kit side by side and discuss delivery with the Craven team.
CombiSteel Triple Glass Door Display Fridge Black NAP-1200 HT – with Door Heating 7455.1925 Product Data
| Brand | CombiSteel |
|---|---|
| Dimensions (W×D×H) | 1600 × 600 × 2100 mm |
| Interior Dimensions | 1510x480x1855 |
| Capacity | – Ltr |
| Material | Powder coated steel |
| Interior Material | Aluminium |
| Colour / Finish | Black |
| Temperature Range | +2/+10 |
| Max. Ambient Temp. | 32 |
| Refrigerant | R 290 |
| Cooling | Ventilated |
| Defrost | Automatic |
| Number of Doors | 3 |
| Number of Grids/Shelves | 15 |
| Electrical Power | 0.8 kW |
| Energy Use | 14.9 kWh/24h |
| Voltage | 230V / 50Hz |
| Installation | Freestanding |
| Mobile | Yes |
| Lockable | No |
| Noise Level | 48 dB |
| Insulation | 45 mm |
| Weight | 152 kg |
